Assembly Instructions
CM7060IV-F/Q
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 6
Rev.14-03-19
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7060IV-F
Summary of Contents for Furniture of America CM7060IV-F
- Page 1 Assembly Instructions CM7060IV-F/Q ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List Due to the size and/or weight of this product, it is highly recommended that the assembly should be done near the area of its intended location.
- Page 4 Align the foot (#5) onto the pre-drilled holes on the bottom corner of the headboard (#1). Prepare two bolt assemblies by inserting FIRST the lock washer (#E) Step 1 onto the bolt (#C) and then the flat washer (#D) onto the SAME bolt (#C), in that order.
- Page 5 Align the two slat support legs (#7) with the pre-drilled holes of the central support rail (#4). Step 3 Prepare 2 bolt assemblies by inserting FIRST the lock washer (#E) onto the bolt (#B) and then the flat washer (#D) onto the SAME bolt (#B), in that order.
- Page 6 Prepare a complete bed slat by inserting one center Step 5 plastic connector (#F) onto the ends of two bed slats (#6). Then connect two end caps (#G) onto the other ends of the bed slats (#6). Align the end caps (#G) with the pre-drilled holes on each side of the side rails (#2) and snap both ends to lock in place.
