Assembly Instructions
CM7017Q
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
Allen Wrench
shows the degree of effort needed in
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
Wrench
products, two persons are recommended.
(Not Included)
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 6
Rev.14-09-30
Advertisement
Related Manuals for Furniture of America CM7017Q
Summary of Contents for Furniture of America CM7017Q
- Page 1 Assembly Instructions CM7017Q ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Wrench products, two persons are recommended.
- Page 2 Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 24 pcs Headboard Bolt 5/16”x1-1/2” #B x 24 pcs #2 x 2 pcs Lock Washer Side Rail...
- Page 4 Remove the cushions (#4) and the slats (#6) from behind the zipper of the back of the headboard (#1). Align the 2 support rail legs (#7) with the pre-drilled holes of the support rail (#5). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then the flat washer (#C) onto the SAME bolt (#A), in that order.
- Page 5 Align the round holes of the #A x 8 pcs 2 corner brackets (#I) with #B x 8 pcs #C x 8 pcs the pre-drilled holes of the #I x 4 pcs side rail (#2). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then the flat washer (#C) onto the SAME...
- Page 6 Align the assembled support rail (#5) with the pre-drilled holes on the center of the headboard (#1) and the footboard (#3). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then the flat washer (#C) onto the SAME bolt (#A), in that order.
- Page 7 Assembly Instructions CM7017CK/EK ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Wrench products, two persons are recommended.
- Page 8 Page 2 of 6...
- Page 9 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 32 pcs Headboard Bolt 5/16”x1-1/2” #B x 32 pcs #2 x 2 pcs Lock Washer Side Rail...
- Page 10 Remove the cushions (#4) and the slats (#6) from behind the zipper of the back of the headboard (#1). Align the 2 support rail legs (#7) with the pre-drilled holes of the support rail (#5). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then the flat washer (#C) onto the SAME bolt (#A), in that order.
- Page 11 Align the round holes of the #A x 8 pcs 2 corner brackets (#I) with #B x 8 pcs #C x 8 pcs the pre-drilled holes of the #I x 4 pcs side rail (#2). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then the flat washer (#C) onto the SAME...
- Page 12 Align the 2 assembled support rail (#5) with the pre-drilled holes on the headboard (#1) and the footboard (#3). Prepare 8 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then the flat washer (#C) onto the SAME bolt (#A), in that order.
