Furniture of America FOA7039Q Assembly Instructions Manual

Hide thumbs

page of 27

/ 27
Bookmarks

Quick Links

Download this manual

VERSION # 20-02-25

1 / 9

MODEL #

FOA7039Q

CM7049Q

Questions?

GIVE US A CALL: 1-888-980-5122

MON – FRI 8:30AM – 5:30PM (PST)

TOOLS REQUIRED

Philips

Screwdriver

(Not Included)

2 - People

Recommended

ASSEMBLY RATING

EASY

The Assembly Rating is a

5-point system showing the

level of effort needed to

assemble a specific product.

DIFFICULT

Need help?

Do you have a question about the FOA7039Q and is the answer not in the manual?

Questions and answers

Summary of Contents for Furniture of America FOA7039Q

Page 1 MODEL # FOA7039Q CM7049Q Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PST) TOOLS REQUIRED Philips Screwdriver (Not Included) 2 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
Page 2 Furniture America FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
Page 4 4 / X X X X X X X 9...
Page 5 QUEEN BED FOA7039Q CM7049Q Please keep instructions for future reference. Check the quantity and irregularity of parts and hardware before you start. #3 2pcs #2 1pc Headboard Bed Slat Side Rail Bed Slat Support -18 x 45 x 1545mm -30 x 30 x 125mm...
Page 7 Align side rails (#3) to the bolts of the headboard (#1) and footboard (#2). Fully tighten the bolts. Part #1 x1pc Part #2 x1pc Part #3 x2pcs Once hooked,tighten bolts using the Allen wrench (A). Part #4 x4pcs Part #5 x4pcs adjustable glider Attach support legs (#5) to the slats (#4), then adjust the leveler according to ground level.
Page 8 Align slats (#4) evenly to the side rails, then secure by using screws (#B) Hardware #B x8pcs PLEASE REMOVE THE PROTECTIVE FILM BEFORE USE Hardware #C x1pc To Active Attach adaptor (#C). Switch on Button Back View 8 / 9...
Page 9 9 / 9...
Page 10: Tools Required
MODEL # FOA7039CK-R CM7049CK-R Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PST) TOOLS REQUIRED Philips Screwdriver (Not Included) 3 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
Page 11 Furniture America FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
Page 12 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
Page 13 4 / X X X X X X X 9...
Page 14 CALIFORNIA KING BED FOA7039CK-R CM7049CK-R Please keep instructions for future reference. Check the quantity and irregularity of parts and hardware before you start. #B 8pcs Pan Head Screw L-Bracket m3.5 x 16mm 5 / 9...
Page 15 FOA7039K-HB CM7049K-HB FOA7039K-FB CM7049K-FB FOA7039CK-R CM7049CK-R...
Page 16 Hardware #A x8pcs Hardware #B x8pcs Attach L bracket (#B) to the slats(#4)then secure by using Panhead screw (#A) Attach support legs (#5) to the slats (#4), then adjust adjustable glider the leveler according to ground level. 7 / 9...
Page 17 Align slats (#4) evenly to the side rails, then secure by using screws (#A) Hardware #A x8pcs PLEASE REMOVE THE PROTECTIVE FILM BEFORE USE Hardware #C x1pc To Active Attach adaptor (#C). Switch on Button Back View 8 / 9...
Page 18 9 / 9...
Page 19 MODEL # FOA7039EK CM7049EK Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PST) TOOLS REQUIRED Philips Screwdriver (Not Included) 3 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
Page 20 Furniture America FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
Page 21 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
Page 22 4 / X X X X X X X 9...
Page 23 EASTERN KING BED FOA7039EK CM7049EK Please keep instructions for future reference. Check the quantity and irregularity of parts and hardware before you start. #3 2pcs #2 1pc Headboard Side Rail Bed Slat Bed Slat Support -18x45x1951mm -30x30x125mm #B 8pcs Adaptor Allen Key M5 CSK m4 x 32mm 5 / 9...
Page 24 FOA7039K-HB CM7049K-HB FOA7039K-FB CM7049K-FB FOA7039EK-R CM7049EK-R...
Page 25 Align side rails (#3) to the bolts of the headboard (#1) and footboard (#2). Fully tighten the bolts. Part #1 x1pc Part #2 x1pc Part #3 x2pcs Once hooked,tighten bolts using the Allen wrench (A). Part #4 x4pcs Part #5 x8pcs adjustable glider Attach support legs (#5) to the slats (#4), then adjust the leveler according to ground level.
Page 26 Align slats (#4) evenly to the side rails, then secure by using screws (#B) Hardware #B x8pcs PLEASE REMOVE THE PROTECTIVE FILM BEFORE USE Hardware #C x1pc To Active Attach adaptor (#C). Switch on Button Back View 8 / 9...
Page 27 9 / 9...

This manual is also suitable for:

Cm7049q
