Assembly Instructions
CM7009Q
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
Phillips Screwdriver
products, two persons are recommended.
(Not Included)
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 10
Rev.14-09-09
Advertisement
Related Manuals for Furniture of America CM7009CK
Summary of Contents for Furniture of America CM7009CK
- Page 1 Assembly Instructions CM7009Q ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
- Page 2 Page 2 of 10...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List #2 x 2 pcs #1 x 1 pc Side Rail Headboard #4 x 1 pc #3 x 1 pc Center Support Rail Footboard...
- Page 4 Due to the size and/or weight of this product, it is highly recommended that the assembly should be done near the area of its intended location. Make sure you have enough space to move around during the assembly. ALWAYS have at least two people to help with transporting and assembling the product to avoid any potential injury and/or damage, especially with the fragile nature of the mirror.
- Page 5 Align the drawer right side (#13) and the drawer left side (#14) with the pre-drilled holes on the drawer front (#12). Secure 3 screws (#I) each into the drawer right side (#13) and the drawer left side (#14) using a Phillips screwdriver to tighten them to the drawer front (#12).
- Page 6 Align the drawer sliding rail (#6) with the pre-drilled holes on the bottom of the drawer rear (#15) and the drawer front (#12). Secure 3 screws (#J) into the drawer sliding rail (#6) using a Phillips screwdriver to tighten them to the drawer rear (#15) and the drawer front (#12).
- Page 7 Align the two side rail legs (#9) with the pre-drilled holes underneath the two side rails (#2). Prepare 2 bolt assemblies by inserting FIRST the lock washer (#E) onto the bolt (#C) and then the flat washer (#D) onto the SAME bolt (#C), in that order. III.
- Page 8 Align the two center support legs (#5) with the pre-drilled holes underneath the center support rail (#4). Prepare two bolt assemblies by inserting FIRST the lock washer (#E) onto the bolt (#B) and then the flat washer (#D) onto the SAME bolt (#B), in that order.
- Page 9 Turn right (clockwise) to tighten #K x 6 pcs Aligned the assembled side rail support (#7) with the pre- drilled holes on each side of the side rails (#2). Secure two screws (#K) into each end of the side rail support (#7) using a Phillips screwdriver to tighten them with the two side rails (#2).
- Page 10 Prepare a bed slat using two slats (#11), one center connector (#F) and two end caps (#G). See diagram below for the correct sequence in connecting those parts. Align the end caps (#G) with the pre-drilled holes on each side of the side rails (#2) and press firmly down on both end caps (#G) to lock with the side rails (#2).
- Page 11 For more information contact our team: service.ec@foagroup.com Rev: 17-08-11...
- Page 15 Align drawer right side panel (#13) and left side panel (#14) to the holes of the drawer front panel (#12). Secure by using screws (#I). Slide drawer bottom panel (#16) through the thin line gaps of the side panels (#13,14). Align drawer back panel (#15) to the back of the drawer.
- Page 16 Secure drawer back panel (#15) by using screws (#I). Align drawer sliding rail (#6) to the bottom of the drawers. Secure sliding rail (#6) to drawer front (#12) by using screws (#I), then secure sliding rail (#6) to drawer back (#15) by using screws (#J).
- Page 17 Prepare 4 bolts assembly by inserting lock washer (#E), then flat washer (#D) onto bolts (#C). Align HB/ FB legs (#8) to the bottom holes of the headboard (#1) and footboard (#3). Secure by using bolts (#C). Prepare 2 bolts assembly by inserting lock washer (#E), then flat washer (#D) onto bolts (#C).
- Page 18 Attach support leg (#10) to each side rail support (#7). Prepare 2 bolts assembly by inserting lock washer (#E), then flat washer (#D) onto bolts (#B). Align center support legs (#5) to the holes of the center support rail (#4). Secure by using bolts (#B).
- Page 19 Prepare 8 bolts assembly by inserting lock washer (#E), then flat washer (#D) onto bolts (#A). Align side rails (#2) to the holes of the headboard (#1) and footboard (#3). Secure by using bolts (#A). Align side rail support (#7) to the side rails (#2), then secure by using screws (#K).
- Page 20 Prepare 4 bolts assembly by inserting lock washer (#E), then flat washer (#D) onto bolts (#B). Align center support slat (#4) to the holes of the headboard (#1) and footboard (#3). Secure by using bolts (#B).
- Page 21 Assembly Instructions CM7009F ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
- Page 22 Page 2 of 10...
- Page 23 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List #2 x 2 pcs #1 x 1 pc Side Rail Headboard #4 x 1 pc #3 x 1 pc Center Support Rail Footboard...
- Page 24 Due to the size and/or weight of this product, it is highly recommended that the assembly should be done near the area of its intended location. Make sure you have enough space to move around during the assembly. ALWAYS have at least two people to help with transporting and assembling the product to avoid any potential injury and/or damage, especially with the fragile nature of the mirror.
- Page 25 Align the drawer right side (#13) and the drawer left side (#14) with the pre-drilled holes on the drawer front (#12). Secure 3 screws (#I) each into the drawer right side (#13) and the drawer left side (#14) using a Phillips screwdriver to tighten them to the drawer front (#12).
- Page 26 Align the drawer sliding rail (#6) with the pre-drilled holes on the bottom of the drawer rear (#15) and the drawer front (#12). Secure 3 screws (#J) into the drawer sliding rail (#6) using a Phillips screwdriver to tighten them to the drawer rear (#15) and the drawer front (#12).
- Page 27 Align the two side rail legs (#9) with the pre-drilled holes underneath the two side rails (#2). Prepare 2 bolt assemblies by inserting FIRST the lock washer (#E) onto the bolt (#C) and then the flat washer (#D) onto the SAME bolt (#C), in that order. III.
- Page 28 Align the two center support legs (#5) with the pre-drilled holes underneath the center support rail (#4). Prepare two bolt assemblies by inserting FIRST the lock washer (#E) onto the bolt (#B) and then the flat washer (#D) onto the SAME bolt (#B), in that order.
- Page 29 Turn right (clockwise) to tighten #K x 6 pcs Aligned the assembled side rail support (#7) with the pre- drilled holes on each side of the side rails (#2). Secure two screws (#K) into each end of the side rail support (#7) using a Phillips screwdriver to tighten them with the two side rails (#2).
- Page 30 Prepare a bed slat using two slats (#11), one center connector (#F) and two end caps (#G). See diagram below for the correct sequence in connecting those parts. Align the end caps (#G) with the pre-drilled holes on each side of the side rails (#2) and press firmly down on both end caps (#G) to lock with the side rails (#2).
