- Page 1 Industrial 4G Modem GTM-204M Series User Manual Version 1.3.0 March 2018 保固說明...
- Page 2 GTM-204M-4G Series User’s Manual v1.3 Warranty All products manufactured by ICP DAS are under warranty regarding defective materials for a period of one year, beginning from the date of delivery to the original purchaser. Warning ICP DAS assumes no liability for any damage resulting from the use of this product.
- Page 3 GTM-204M-4G Series User’s Manual v1.3 Symbol description RoHS Manufacture of this product strictly abide by the rules of lead-free and does not contain any harmful substances. WEEE This symbol means this product must be collected at the time of discarding in the EU. HOT SURFACE DO NOT TOUCH This symbol means this product’s enclosure may be with high temperature, do not touch before cooling or...
-
Page 4: Table Of Contents
GTM-204M-4G Series User’s Manual v1.3 Table of Contents 1. Introduction ................1 2. Hardware Specifications ............2 3. Hardware Appearance ............... 4 3.1 View of the GTM-204M-4G Panel ............4 3.2 Pin Assignments ..................4 3.3 LED Indicators ..................5 4. -
Page 5: Introduction
GTM-204M-4G Series User’s Manual v1.3 1. Introduction The GTM-204M-4GE is an industrial 4G LTE and Quad-band GSM modem with RS-232 and USB interfaces that work at frequencies of FDD LTE B1/B3/B5/B7/B8/B20 and WCDMA 850/900/2100 MHz and GSM 850 MHz, EGSM 900 MHz, DCS 1800 MHz , PCS 1900 MHz. -
Page 6: Hardware Specifications
GTM-204M-4G Series User’s Manual v1.3 2. Hardware Specifications Item GTM-204M-4GE GTM-204M-4GC GSM System Frequency Band 850/900/1800/1900 MHz 900/1800MHz GPRS Connectivity GPRS class 12; GPRS station class B DATA GPRS Downlink transfer: Max. 85.6 kbps; Uplink transfer: Max 42.8kbps 3G System WCDMA 900/2100 WCDMA TD-SCDMA 1900/2100... - Page 7 GTM-204M-4G Series User’s Manual v1.3 Casing Metal Dimensions (W x L x H) 28 mm x 78.5 mm x 100 mm Installation DIN-Rail Environment Operation Temperature -25℃ to 70℃ Storage Temperature -40℃ to 80℃ Humidity 5~90% RH, non-condensing - 3/35 -...
-
Page 8: Hardware Appearance
GTM-204M-4G Series User’s Manual v1.3 3. Hardware Appearance 3.1 View of the GTM-204M-4G Panel 3.2 Pin Assignments - 4/35 -... -
Page 9: Led Indicators
GTM-204M-4G Series User’s Manual v1.3 3.3 LED Indicators There are two LED indicators to help users to judge the various conditions of GTM-204M-4G. The description is as follows： PWR(Red)：The PWR LED can indicate the status of Power module. Power normal Power fail Always ON Always OFF... -
Page 10: Hardware Wire Connection
GTM-204M-4G Series User’s Manual v1.3 4. Hardware Wire Connection 4.1 Reset Wire Connection Input Type Reset State Reset State Reset Input Reset Input Voltage Level +3.5 V ~ +30 V Voltage Level +1 V max. - 6/35 -... -
Page 11: Installation
GTM-204M-4G Series User’s Manual v1.3 4.2 Installation GTM-204M-4G should be installed by technical person who should be with the proper authorization. GTM-204M-4G should install on the location that general person will not be touch. SIM card and 4G antenna installation WARNING! HOT SURFACE DO NOT TOUCH The product’s enclosure may be with high temperature, do not touch before cooling or else will be burned. -
Page 12: Quick Test
GTM-204M-4G Series User’s Manual v1.3 4.3 Quick Test 4.3.1 Hardware installation - 8/35 -... -
Page 13: Software Installation (Hyper Terminal)
GTM-204M-4G Series User’s Manual v1.3 4.3.2 Software installation (Hyper terminal) Step 1：Start → All Programs → Accessories → Communications → Hyper Terminal Step 2 ： If there is a pop-up form that says “Default Telnet Program?”, please select “Yes” - 9/35 -... - Page 14 GTM-204M-4G Series User’s Manual v1.3 Step 3：Input new connection name → Click “OK” Step 4：Select your PC serial port → Click “OK” - 10/35 -...
- Page 15 GTM-204M-4G Series User’s Manual v1.3 Step 5：Please refer to the following settings Bits per second 115200 Data bits Parity None Stop bits Flow control None Step 6：File → Properties - 11/35 -...
- Page 16 GTM-204M-4G Series User’s Manual v1.3 Step 7：Settings → Click “ASCII Setup…” Step 8：Select “Echo typed characters locally” → Click “OK” - 12/35 -...
- Page 17 GTM-204M-4G Series User’s Manual v1.3 Step 9：Input “AT” and press “Enter”, then you will receive “AT OK” - 13/35 -...
-
Page 18: Gprs Connection
GTM-204M-4G Series User’s Manual v1.3 5. GPRS Connection 5.1 XPAC-8000 (Microsoft Windows XP) 5.1.1 GTM-204M-4G Hardware Requirement GTM-204M-4G (Please install USB driver first) XPAC-8000 C. USB cable - 14/35 -... -
Page 19: Create A New Modem
GTM-204M-4G Series User’s Manual v1.3 5.1.2 Create a New Modem Step 1：Control Panel → Double-click “Phone and Modem Options” Step 2：Set the area code for the first time → Click “OK” - 15/35 -... - Page 20 GTM-204M-4G Series User’s Manual v1.3 Step 3：Control Panel → Double-click “Phone and Modem Options” → Modem → Click “Add” Step 4：Select “Don‘t detect my modem; I will select it from a list.” → Click “Next” - 16/35 -...
- Page 21 GTM-204M-4G Series User’s Manual v1.3 Step 5：Select “Standard Modem Types” → Select “Standard 19200 bps Modem” → Click “Next” Step 6：Select your COM Port to connect to the modem → Click “Next” - 17/35 -...
- Page 22 GTM-204M-4G Series User’s Manual v1.3 Step 7：Click “Finish” to finish the install new modem. Step 8：Control Panel → Double-click “Phone and Modem Options” → Modem → Select “Standard 19200 bps Modem” → Click “Properties” - 18/35 -...
- Page 23 GTM-204M-4G Series User’s Manual v1.3 Step 9：Modem → Maximum Port Speed → 115200 Step 10：Advanced → Extra initialization commands Note：GPRS’s APN must be provided from your Telecom. CO., LTD. For example in Taiwan: AT+CGDCONT=1,”IP”,”INTERNET” For example in China: AT+CGDCONT=1,”IP”,” CMNET” - 19/35 -...
- Page 24 GTM-204M-4G Series User’s Manual v1.3 Step 11：Diagnostics → Query Modem → Click “OK” Note：If user queries modem that gets an Error, Please try again. Step 12：Click “OK” - 20/35 -...
-
Page 25: Create A New Dial-Up And Networking Connection
GTM-204M-4G Series User’s Manual v1.3 5.1.3 Create a New Dial-up and Networking Connection Step 1：Control Panel → Network Connections → Click “Create a new connection” Step 2：Click “Next” - 21/35 -... - Page 26 GTM-204M-4G Series User’s Manual v1.3 Step 3：Select “Connect to the Internet” → Click “Next” Step 4：Select “Connect using a dial-up modem” → Click “Next” - 22/35 -...
- Page 27 GTM-204M-4G Series User’s Manual v1.3 Step 5：ISP Name → Your GPRS‘s name → Click “Next” Step 6：Phone Number: → Click “Next” Note：Phone Number must be provided from your Telecom. CO., LTD. For example in Taiwan: *99***1# - 23/35 -...
- Page 28 GTM-204M-4G Series User’s Manual v1.3 Step 7：GPRS‘s User name and GPRS‘s Password → Click “Next” Note：GPRS’s User name and GPRS’s Password must be provided from your Telecom. CO., LTD. Step 8：Click “Finish” - 24/35 -...
- Page 29 GTM-204M-4G Series User’s Manual v1.3 Step 9：Control Panel → Network Connections → Click “Your GPRS‘s name” → File → Properties Step 10：General → Select “Standard 19200 bps Modem” → Click “Configure” - 25/35 -...
- Page 30 GTM-204M-4G Series User’s Manual v1.3 Step 11：Maximum speed(bps) → Select “115200” → disable “Enable hardware flow control”(Note) → Click “OK” Note：Please don‘t select “Enable hardware flow control” Step 12：Click “OK” - 26/35 -...
- Page 31 GTM-204M-4G Series User’s Manual v1.3 Step 13：Control Panel → Network Connections → Double-Click “Your GPRS‘s name” Step 14：Click “Dial” - 27/35 -...
- Page 32 GTM-204M-4G Series User’s Manual v1.3 Step 15：If you connect to internet successfully, your toolbar has new logo Step 16：You can Double-Click the new logo → Click “Details” → Get your IP address - 28/35 -...
-
Page 33: Usb Driver Installation
GTM-204M-4G Series User’s Manual v1.3 6. USB Driver Installation 6.1 XPAC-8000 (Microsoft Windows XP) Step 1：Double Click “GTM-204M-4G USB driver V1.00.exe” to install the driver. Step 2：Click “Next”. Step 3：Click “Next” - 29/35 -... - Page 34 GTM-204M-4G Series User’s Manual v1.3 Step 4：Select “Install” Step 5：Click “Finish” - 30/35 -...
- Page 35 GTM-204M-4G Series User’s Manual v1.3 Step 6：Connect the USB of GTM-204M-4G with the PC Step 7：The “Found New Hardware Wizard” window for “Quectel LTE Module” will pop-out. Please click “Next”. - 31/35 -...
- Page 36 GTM-204M-4G Series User’s Manual v1.3 Step 7-1：Click “Continue Anyway”. Step 7-2：Click “Finish” if you got a success message. - 32/35 -...
- Page 37 GTM-204M-4G Series User’s Manual v1.3 Step 7-3：Click “Back” if you got a fail message, and then choose “Install from a list or specific location” in all install steps. Step 7-4：Click “Browse” to choose your installing folder, and Click “Next”. - 33/35 -...
- Page 38 GTM-204M-4G Series User’s Manual v1.3 Step 8：The “Hardware Installation” window for “GTM-204M-4G Wireless Ethernet Adapter” will pop-out. Please click “Continue Anyway”. Step 9：The “Hardware Installation” window for “GTM-204M-4G USB AT Port” will pop-out. Please click “Continue Anyway”. - 34/35 -...
- Page 39 GTM-204M-4G Series User’s Manual v1.3 Step 10：The “Hardware Installation” window for “GTM-204M-4G USB NMEA Port” will pop-out. Please click “Continue Anyway”. Step 11：The “Hardware Installation” window for “GTM-204M-4G USB DM Port” will pop-out. Please click “Continue Anyway”. - 35/35 -...
- Page 40 GTM-204M-4G Series User’s Manual v1.3 Step 12：Finish the all install steps. Please open “Device manager”, and you will found new 8 items in your computer. The “GTM-204M-4G USB Modem” is a Modem for dial-up to 4G/3G/GPRS Network. The “GTM-204M-4G USB AT Port” is an “AT command port” for GSM library. - 36/35 -...
-
Page 41: Revision History
GTM-204M-4G Series User’s Manual v1.3 7. Revision History Revision Date Author Description 2016/06/14 Eddie First Release 2016/09/09 Eddie Modify Hardware Specifications 2017/08/15 Eddie Update Hardware Specifications 2017/09/05 Eddie Update Hardware Specifications - 37/35 -...
