Modem to USB/RS-232 Converter
GTM-200M
User Manual
Version 1.0.1 Sep 2022
保固說明

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GTM-200M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ICP DAS USA GTM-200M

Summary of Contents for ICP DAS USA GTM-200M

  • Page 1 Modem to USB/RS-232 Converter GTM-200M User Manual Version 1.0.1 Sep 2022 保固說明...
  • Page 2 GTM-200M User’s Manual v1.0.1 Warranty All products manufactured by ICP DAS are under warranty regarding defective materials for a period of one year, beginning from the date of delivery to the original purchaser. Warning ICP DAS assumes no liability for any damage resulting from the use of this product.
  • Page 3 GTM-200M User’s Manual v1.0.1 Symbol description RoHS Manufacture of this product strictly abide by the rules of lead-free and does not contain any harmful substances. WEEE This symbol means this product must be collected at the time of discarding in the EU.

  • Page 4: Table Of Contents

    2.1 Hardware Specifications ................ 2 2.2 Accessories Specifications ..............3 2.3 Assembly process ................. 4 3. Hardware Appearance ............... 6 3.1 View of the GTM-200M Panel ............... 6 3.2 Pin Assignments ..................6 3.3 LED Indicators ..................7 4. Hardware Wire Connection ............8 4.1 Reset Wire Connection .................

  • Page 5: Introduction

    Customers can choose to match different communication modules according to the needs of the field, which can support different frequency bands. The GTM-200M also provides an integrated Library, allowing customers to focus on and speed up the development of applications without having to deal with the command problems of different communication modules.

  • Page 6: Hardware Specifications

    GTM-200M User’s Manual v1.0.1 2. Hardware Specifications 2.1 Hardware Specifications Item GTM-200M Comm. Interface COM Port RxD, TxD, GND COM Port Baud Rate 9600 bps ~ 115200 bps (default：115200 bps) USB 2.0 (high speed) USB Driver Support Windows 10 LED Indicators...

  • Page 7: Accessories Specifications

    GTM-200M User’s Manual v1.0.1 2.2 Accessories Specifications Module (Optional) EC25-E EC20-CE LE910C4-WWX category LTE CAT.4 Frequency band FDD LTE: FDD LTE: B1/B3/B8/ B1/B2/B3/B4/B5/B7/B8/B B1/B3/B5/B7/B8/B20 12/B13/B14/B19/B20/B26 TDD LTE: /B28 TDD LTE: B38/B39/B40/B41 B38/B40/B41 WCDMA:B1/B8 WCDMA: B1/B5/B8 B1/B2/B4/B5/B8/B19 TD-SCDMA:B34/B39 CDMA2000:BC0 900/1800MHz B3/B8...

  • Page 8: Assembly Process

    When the communication module is purchased, please refer to the following installation method for installation : ※Please refer to the order information at the bottom of the GTM-200M order page for optional communication modules. Step 1 : Remove the side panel , there are 6 black screws.
  • Page 9 GTM-200M User’s Manual v1.0.1 Step 3 : Connect the 4G IPEX plug to the communication module (Main) position ※Note: The main position of different modules is different, and the main contact of communication module can be referred to Appendix 7.1...

  • Page 10: Hardware Appearance

    GTM-200M User’s Manual v1.0.1 3. Hardware Appearance 3.1 View of the GTM-200M Panel 3.2 Pin Assignments - 6/35 -...

  • Page 11: Led Indicators

    GTM-200M User’s Manual v1.0.1 3.3 LED Indicators There are two LED indicators to help users to judge the various conditions of GTM-200M. The description is as follows： PWR(Red)：The PWR LED can indicate the status of Power module. Power normal Power fail...

  • Page 12: Hardware Wire Connection

    GTM-200M User’s Manual v1.0.1 4. Hardware Wire Connection 4.1 Reset Wire Connection Input Type Reset State Reset State Reset Input Reset Input Voltage Level +3.5 V ~ +30 V Voltage Level +1 V max. - 8/35 -...

  • Page 13: Installation

    GTM-200M User’s Manual v1.0.1 4.2 Installation The GTM-200M should be installed by a properly authorized technician in a location that is out of the reach of the general public. ➢ SIM card and 4G antenna installation WARNING! HOT SURFACE DO NOT TOUCH The product’s enclosure may be with high temperature, do not touch before...

  • Page 14: Quick Test

    GTM-200M User’s Manual v1.0.1 4.3 Quick Test 4.3.1 Hardware installation GTM-200M - 10/35 -...

  • Page 15: Software Installation (Hyper Terminal)

    GTM-200M User’s Manual v1.0.1 4.3.2 Software installation (Hyper terminal) Step 1：Start → All Programs → Accessories → Communications → Hyper Terminal Step 2：If there is a pop-up form that says “Default Telnet Program?”, please select “Yes” - 11/35 -...
  • Page 16 GTM-200M User’s Manual v1.0.1 Step 3：Input new connection name → Click “OK” Step 4：Select your PC serial port → Click “OK” - 12/35 -...
  • Page 17 GTM-200M User’s Manual v1.0.1 Step 5：Please refer to the following settings Bits per second 115200 Data bits Parity None Stop bits Flow control None Step 6：File → Properties - 13/35 -...
  • Page 18 GTM-200M User’s Manual v1.0.1 Step 7：Settings → Click “ASCII Setup…” Step 8：Select “Echo typed characters locally” → Click “OK” - 14/35 -...
  • Page 19 GTM-200M User’s Manual v1.0.1 Step 9：Input “AT” and press “Enter”, then you will receive “AT OK” - 15/35 -...

  • Page 20: Gprs Connection

    GTM-200M User’s Manual v1.0.1 5. GPRS Connection 5.1 XPAC-8000 (Microsoft Windows XP) 5.1.1 GTM-200M Hardware Requirement GTM-200M (Please install USB driver first) XPAC-8000 C. USB cable GTM-200M - 16/35 -...

  • Page 21: Create A New Modem

    GTM-200M User’s Manual v1.0.1 5.1.2 Create a New Modem Step 1：Control Panel → Double-click “Phone and Modem Options” Step 2：Set the area code for the first time → Click “OK” - 17/35 -...
  • Page 22 GTM-200M User’s Manual v1.0.1 Step 3：Control Panel → Double-click “Phone and Modem Options” → Modem → Click “Add” Step 4：Select “Don‘t detect my modem; I will select it from a list.” → Click “Next” - 18/35 -...
  • Page 23 GTM-200M User’s Manual v1.0.1 Step 5：Select “Standard Modem Types” → Select “Standard 19200 bps Modem” → Click “Next” Step 6：Select your COM Port to connect to the modem → Click “Next” - 19/35 -...
  • Page 24 GTM-200M User’s Manual v1.0.1 Step 7：Click “Finish” to finish the install new modem. Step 8：Control Panel → Double-click “Phone and Modem Options” → Modem → Select “Standard 19200 bps Modem” → Click “Properties” - 20/35 -...
  • Page 25 GTM-200M User’s Manual v1.0.1 Step 9：Modem → Maximum Port Speed → 115200 Step 10：Advanced → Extra initialization commands Note：GPRS’s APN must be provided from your Telecom. CO., LTD. For example in Taiwan: AT+CGDCONT=1,”IP”,”INTERNET” For example in China: AT+CGDCONT=1,”IP”,” CMNET” - 21/35 -...
  • Page 26 GTM-200M User’s Manual v1.0.1 Step 11：Diagnostics → Query Modem → Click “OK” Note：If user queries modem that gets an Error, Please try again. Step 12：Click “OK” - 22/35 -...

  • Page 27: Create A New Dial-Up And Networking Connection

    GTM-200M User’s Manual v1.0.1 5.1.3 Create a New Dial-up and Networking Connection Step 1：Control Panel → Network Connections → Click “Create a new connection” Step 2：Click “Next” - 23/35 -...
  • Page 28 GTM-200M User’s Manual v1.0.1 Step 3：Select “Connect to the Internet” → Click “Next” Step 4：Select “Connect using a dial-up modem” → Click “Next” - 24/35 -...
  • Page 29 GTM-200M User’s Manual v1.0.1 Step 5：ISP Name → Your GPRS‘s name → Click “Next” Step 6：Phone Number: → Click “Next” Note：Phone Number must be provided from your Telecom. CO., LTD. For example in Taiwan: *99***1# - 25/35 -...
  • Page 30 GTM-200M User’s Manual v1.0.1 Step 7：GPRS‘s User name and GPRS‘s Password → Click “Next” Note：GPRS’s User name and GPRS’s Password must be provided from your Telecom. CO., LTD. Step 8：Click “Finish” - 26/35 -...
  • Page 31 GTM-200M User’s Manual v1.0.1 Step 9：Control Panel → Network Connections → Click “Your GPRS‘s name” → File → Properties Step 10：General → Select “Standard 19200 bps Modem” → Click “Configure” - 27/35 -...
  • Page 32 GTM-200M User’s Manual v1.0.1 Step 11：Maximum speed(bps) → Select “115200” → disable “Enable hardware flow control”(Note) → Click “OK” Note：Please don‘t select “Enable hardware flow control” Step 12：Click “OK” - 28/35 -...
  • Page 33 GTM-200M User’s Manual v1.0.1 Step 13：Control Panel → Network Connections → Double-Click “Your GPRS‘s name” Step 14：Click “Dial” - 29/35 -...
  • Page 34 GTM-200M User’s Manual v1.0.1 Step 15：If you connect to internet successfully, your toolbar has new logo Step 16：You can Double-Click the new logo → Click “Details” → Get your IP address - 30/35 -...

  • Page 35: Usb Driver Installation

    6. USB Driver Installation 6.1 Microsoft Windows 10 OS Step 1：Double Click “GTM-200M USB driver V1.00.exe” to install the driver. ※If you have purchased GTM-205M and GTM-204M series devices, it is recommended to remove the device driver before installing the GTM-200M USB driver.
  • Page 36 GTM-200M User’s Manual v1.0.1 Step 5：Click “Finish” Step 6：Connect the USB of GTM-200M with the PC Step 7：Finish the all install steps. Please open “Device manager”, and you will found new device items in your computer, as shown below: ⚫...
  • Page 37 GTM-200M User’s Manual v1.0.1 ⚫ EC25 Module ⚫ LE910C4-WWX Module - 33/35 -...

  • Page 38: Appendix

    GTM-200M User’s Manual v1.0.1 7. Appendix 7.1 Communication Module Reference Contact EC20-CE EC25-E LE910C4-WWX Main -- Main -- Main -- 8. Revision History Revision Date Author Description 1.0.0 2016/06/14 Eddie First Release 1.0.1 2022/09/20 Patty Modify Installation Process and add Appendix 7.1...
