Owner's Guide and Installation Manual
Attach sales receipt to this card and retain as your proof of purchase
DATE OF PURCHASE:
MODEL NUMBER:
To register your fixture, please visit our website www.montecarlofans.com
3ALBR60XXXD Series Fan
cETL Model NO. : 3ALBR60XXD
RETAILER NAME:
RETAILER ADDRESS:
8.17 kg
17.97 lbs
Total fan weight with light
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Monte Carlo Fan Company 3ALBR60 D Series
Summary of Contents for Monte Carlo Fan Company 3ALBR60 D Series
- Page 1 Owner’s Guide and Installation Manual 3ALBR60XXXD Series Fan cETL Model NO. : 3ALBR60XXD Attach sales receipt to this card and retain as your proof of purchase DATE OF PURCHASE: RETAILER NAME: RETAILER ADDRESS: MODEL NUMBER: To register your fixture, please visit our website www.montecarlofans.com 8.17 kg 17.97 lbs Total fan weight with light...
-
Page 2: Cautions And Warnings
Cautions and Warnings WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70) including fire-rated construction. - Page 3 Mounting bracket Canopy Decorative ring Before you begin installing the fan, Switch Before installing this fan make sure the Remove decorative ring from canopy by turning counterclockwise. power off at Service panel and lock outlet box is properly installed to the service disconnecting means to prevent house structure.
-
Page 4: Safety Cable Installation
Canopy Decorative ring Downrod sleeve Top cover Cross pin Keeper pin Slot Thread lead wires and safety cable from Place top cover, downrod sleeve, Install ball end of downrod into mounting motor assembly through downrod. decorative ring and canopy over downrod, bracket opening. - Page 5 Decorative ring Blade Plate on motor Groove Light plate Raise canopy to mounting bracket, Insert blade into the slot on flywheel. Install a light plate onto the plate on aligning loosened screws in mounting motor. Install blade with screws and washers bracket with slotted holes in canopy.
- Page 6 Remote Controller Operation Remove the battery cover from the remote control transmitter and install batteries. Replace the cover. This remote uses 2 1.5V/AAA batteries. DIM (D) Note: If not using for long periods of time, remove battery to prevent ON/OFF (O) damage to remote transmitter, and store the remote transmitter away from excess heat or humidity Dimming, Non Dimming Setting (Only available for fans with light)
- Page 7 Install Transmitter wall mount cradle with 2 screws provided. Useful tips: Take remote transmitter up by pushing it at lower area of the transmitter. The remote transmitter can be held on magnetic metal materials by a magnet built in the transmitter. Wall mount cradle The receiver provides the following protective functions Lock protection- The DC motor has a build-in safety feature...
-
Page 8: Troubleshooting
5.Remove light kit and check the plug connections if they are present. 6.If this fan uses remote controller, make sure dip switches are setting properly and make CAUTION: Make sure main power is turned off before entering switch housing and/or canopy. © 2019 Monte Carlo Fan Company 12/2019... - Page 9 Feb.2021...
