6. Installing the Mounting Bracket

Remember to disconnect the power at the circuit breaker.
1. Remove 1 of 2 screws from the bottom of the mounting
bracket and save for use in section 11. Loosen the other
screw (FIG.5).
2. Pass the 120-volt supply wires through the center hole in the mount-
ing bracket as shown (FIG.6).
3. Secure the mounting bracket to the ceiling outlet box with the screws
and washers provided with your outlet box.
NOTE: Make sure that mounting screws are tight.
FR -W 1 92 2- 56 L
UL/Cul Listed
Electrical Box
Mounting Bracket
Mounting Screws
Mounting Bracket
Screw
FIG.5
120V Wire
FIG.6
9
