Default Settings
IP Address:
192.168.1.1
Subnet mask:
255.255.255.0
Default gateway:
192.168.1.254
Username:
admin
Password:
admin
Troubleshooting
If no LEDs light, verify that the power supply
connections are solid and that power is present
on the output of the power supply.
Use the LED table to verify that power is
present, a link is established, data is being
transmitted, and to verify port speed.
If data does not pass and cable connections
have been verified, contact your Network
Administrator to validate that the network
connection is good.
The user manual can be found in the
documentation and download section of the
product web page.
-- First, go to www.advantech-bb.com.
-- Second, search for the model number.
-- Finally, go to the documentation/download
section of that product page to download
files.
Product Information
MODEL
DESCRIPTION
#
16-port 10/100Mbps Industrial
SE416
Managed Ethernet Switch
16-port 10/100Mbps Industrial
SE416-T
Managed Ethernet Switch
16-port 10/100Mbps
SE416-
EtherNet/IP Industrial Managed
EI-T
Ethernet Switch
16-port 10/100Mbps
SE416-
PROFINET Industrial Man-
PN-T
aged Ethernet Switch
Document number – SE416-x_4216qsg
Recommended Accessories
MDR-40-24
Power Supply
C5UMB3FBG
Ethernet Cables
TEMP
RATING
-10 ~ 60°C
-40 ~ 75°C
-40 ~ 75°C
-40 ~ 75°C
1-888-948-2248 | Europe: +353 91 792444
707 Dayton Road | PO Box 1040 | Ottawa, IL 61350
Phone: 815-433-5100 | Fax: 815-433-5109
www.advantech-bb.com | E-mail: support@advantech-bb.com
advantech-bb.com
QUICK START
GUIDE
SE416-x
Industrial Ethernet Switch
Before you begin, be
sure you have the following:
+ Ethernet Switch
+ DIN Rail Mount Bracket (Installed)
+ Wall Mount Bracket
+ Power Supply (Required not inluded)
www.advantech-bb.com
