C38 HANDPIECE CONTROLS.
POWER ON - OFF.
CHANNEL # 1 Speed Regulator.
CHANNEL # 2 Injector trigger.
CHANNEL # 3 Reverser and Inertia control.
CHANNEL # 4 All aboard call trigger.
CHANNEL # 5 Bind button & Whistle control.
EXCEPT WHEN BINDING,
ALWAYS SWITCH TX ON
BEFORE
THE LOCO.
REGULATOR KNOB MUST BE FULLY CCW
REVERSER KNOB MUST BE IN THE MIDDLE.
(See pic to the left)
# OMEGA-10 speed curves available
Advertisement
Table of Contents
Related Manuals for Remote Control Systems ARGYLE C38
Summary of Contents for Remote Control Systems ARGYLE C38
- Page 1 C38 HANDPIECE CONTROLS. POWER ON - OFF. CHANNEL # 1 Speed Regulator. CHANNEL # 2 Injector trigger. CHANNEL # 3 Reverser and Inertia control. CHANNEL # 4 All aboard call trigger. CHANNEL # 5 Bind button & Whistle control. EXCEPT WHEN BINDING, ALWAYS SWITCH TX ON BEFORE THE LOCO.
- Page 2 PLACING SPEAKER, COVER & POWER MODULE. REAR MOUNTED ON - OFF SWITCH POWER & SOUND MODULE.
- Page 3 CABLING & SWITCH PLACEMENT. ON - OFF Switch Charge Jack Polyswitch fuse From Battery TO ESC INSTALLING THE SWITCH. It will be simpler to install the ON - OFF switch if it is disconnected from the loom. All connections are labelled for easy reassembly. Remove the two switch screws and cover plate.
- Page 4 WIRING COMPONENTS IN POWER MODULE. To front LED in Loco Switch Charge Jack Motor Battery Speed inside AB-RA controller loco 6ch RX Fuse BINDING. The C38 battery R/C installation tray will have the Rx pre-bound (paired) to the Tx handpiece. Binding will be required if the Rx is to be bound to a different Tx.
- Page 5 DETAILS OF # OMEGA-10 ESC The C38 battery R/C installation kit is supplied with the Rx bound (paired) to the # BASIC+ Tx handpiece. The # EVO-BASIC+ handpiece has been set up for Low OFF ESC control. Likewise the # OMEGA-10 ESC has been calibrated for optimum performance.
- Page 6 DRIVING THE C38 SWITCH Tx ON. Make sure knobs are correctly set as in pic top right. REVERSER. Set forward direction. Twist small knob to the right. Fully CW = No Inertia. Part CW = Max Inertia. Inertia is variable between the two points during use. REGULATOR.
- Page 7 MyLocoSound in the C38 CONTROLLING SOUNDS The soundcard generates sound for the NSW 38 class locomotives. Three of the sounds can be triggered using the transmitter buttons: * The whistle * The brake compressor * The guards whistle The remaining sounds are set to occur automatically. When you power up the locomotive you will hear a gentle steam hiss and the electric generator.
- Page 8 BUTTON 2 – Brake Pump. This will operate in two ways: 1 beep – Manual. Sounds only if the 2 button on the IR or the R/C is pressed. (Default) 2 beeps – Automatic. Sounds whenever the locomotive is stationary. BUTTON 3 - Guards Whistle.
