TX-10
Digital Proportional R/C
Thank you for purchasing this Microprocessor based Electronic Speed Control
THE TX-10 IS FOR USE WITH RCS OMEGA-3v7 ECS's THAT USE OPERATING PROGRAM Av1
THE TX-10 HANDPIECE HAS A CENTRE OFF DÉTENTE ON SPEED CONTROLLER KNOB.
THAT ALSO MAKES THE TX-10 SUITABLE FOR USE WITH MOST CENTRE OFF ESC's
THESE INSTRUCTIONS REFER SPECIFICALLY TO THE TX-10 HANDPIECE (SAME AS THE TX-20+).
PLEASE NOTE: THE PLASTIC HANDPIECE ENCLOSURES MAY DIFFER FROM PICTURES BELOW.
"CENTRE OFF Speed Control
CENTRE OFF LARGE KNOB WITH
DÉTENTE FOR 150º CONTROL.
EITHER SIDE OF NEUTRAL.
You will supply a locomotive or trail car, the 14 – 20 volt traction batteries (depending on ESC), a fuse,
ON-OFF switch and wires where necessary, to connect the ESC to the battery and motor(s).
Where soldering is necessary, we recommend a low wattage soldering iron and resin core solder.
TO AVOID CONFUSION WITH OTHER OPERATORS, WE SUGGEST YOU MARK THE TX TO SHOW WHICH LOCO IT IS OPERATING.
DO NOT ATTEMPT TO ALTER THE TUNING OF THE RADIO EQUIPMENT.
DO NOT USE RADIO CONTROL EQUIPMENT IN THUNDERSTORMS.
CHILDREN UNDER 12:
RCS TX & RX PRODUCTS MUST NOT BE USED FOR CONTROLLING RIDE ON LOCOMOTIVES CAPABLE OF
FOR
# VIPER-10 SERIES FOR
INSTRUCTION MANUAL
They should be read in conjunction with the RCS ESC you are using.
"LOW OFF" Speed Control
SWITCH FOR DIRECTION SETTING.
300º KNOB FOR LOW OFF CONTROL
THE TX-10 IS GUARANTEED FOR ONE YEAR.
CAUTION
ADULT SUPERVISION RECOMMENDED DURING USE.
CARRYING MEMBERS OF THE GENERAL PUBLIC.
TABLE OF CONTENTS
PROVIDED IN INSTRUCTIONS.
Page # 1 Introduction.
Page # 2 Preparing the TX-10. Binding.
Page # 3 Using TX-10 with a LOW off ESC.
Page # 4 Using TX-10 with a CENTRE off ESC.
Specific instructions for operating an RCS ESC
are found with the supplied ESC
Eg Speed & Direction control.
Using Sound Trigger functions.
Programming the ESC
Trouble shooting etc
PLEASE NOTE. PDF WIRING INSTRUCTIONS ARE HERE:
http://www.rcs-rc.com/pages/instructions
LOW OFF
CONTROL.
INCLUDING
CENTRE OFF
OF SPEED.
(ESC)
CONTROL.
Battery Replacement
INSERT THE 9 VOLT BATTERY.
DO NOT ALLOW BATTERY TO GO FLAT
BY LEAVING THE TX SWITCHED ON.
