Rankam SMOKE CANYON SC2000301-SC-00 Instruction Manual page 18

Burner Cleaning
Before cleaning, make sure the gas supply and control knobs are in the "OFF" position and the
burners have cooled.
To remove the main burners for cleaning:
1. Open lid. Remove the cooking grate and
flame tamer.
2. Remove the screws and ignition electrode
wire, lift the burner out of the firebox to clean
the grill burners.
3. Clean the exterior of the burner with a wire
brush. Use a metal scraper for stubbed stains
or debris.
4. Clear clogged ports with straightened paper
clip. Never use a wooden toothpick as it may
break off and clog the port.
5. Check and clean burner / venturi tubes for insects and insect nests. A clogged tube can
lead to a fire beneath and behind the main control panel.
To reinstall the main burners:
1. Insert the burner over the main burner gas valve.
2. Make sure the orifice spud (A) is inside the burner venturi
(B)
3. Align the burner screw hole with the firebox hole, insert
screw and tighten.
Should you encounter any problem, need assistance with assembly, have
questions about this product or have missing or defective parts,
Rankam Metal Products Manufactory Limited
Monday thru Friday 8 A.M. to 5 P.M. Western Standard Time
customerservice@rankam.com
SC2000301-SC-00 - ENG
Please contact Customer Service at
1-888-837-1380
or by email
WE CAN HELP.
Made in China
Orifice spud (A)
Burner Venturi (B)
18 of 19
Burner
Screw
Clean the
burner
Control Valve
