8 Burners Event Grill
Model: ST1017-012939
For Outdoor Use Only
Thank you for purchasing this outdoor cooking appliance.
Please read Safety and Precaution statements, Grill Maintenance, Leak Testing Regulator /
Cylinder connection and Lighting Grill before using grill for first time,
This instruction manual contains important information necessary for the proper assembly
and safe use of the appliance.
Read and follow all warnings and instructions before assembling and using the appliance.
Follow all warnings and instructions when using the appliance.
Keep these manual for further reference.
As RanKam we 're the experts on this product and trained to help you with:
Assembly Questions
Grill operation
Replacements of damaged or missing parts, please contact
OPERATOR'S MANUAL
Toll Free 1-888-837-1380
Advertisement
Table of Contents
Related Manuals for Rankam ST1017-012939
Summary of Contents for Rankam ST1017-012939
- Page 1 Read and follow all warnings and instructions before assembling and using the appliance. Follow all warnings and instructions when using the appliance. Keep these manual for further reference. As RanKam we ‘re the experts on this product and trained to help you with: Assembly Questions Grill operation...
- Page 2 DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your gas supplier or your fire department. WARNING FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance.
- Page 3 Grill Installation Codes The installation and pressure regulator must conform with local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or the Natural Gas and Propane Installation Code, CSA B149.1, as applicable, including: The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5 kPa).
- Page 4 Product Diagram...
-
Page 5: Parts List
Parts List Part Number Part Description DQ08A-01-00 Wind shield back panel DQ08A-03-46 Cooking Grid DQ08A-01-02 Wind Shield, right panel DQ08A-03-44 Flame Tamer DQ08A-03-04 Grill Body, back panel DQ08A-03-41 Lead Fire Slot Assy DQ08A-03-02 Grill Body, right panel DQ08A-03-47 Body Post Assy DQ08A-02-01 Side handle DQ08A-02-11... -
Page 6: Component List
Component List A: Grill Cart B: Grill Body C: Directional Caster 1 piece 1 piece 2 pieces D: Universal Caster E: Grease Receptacle F: Towel Rack 2 pieces 1 piece 2 pieces G: Side Handle H: Flame Tamer J: Grease Tray 2 pieces 8 pieces 2 pieces... - Page 7 2. Assemble Cart With an assistant of some person again, turn the cart up-side-down. Unfold the Cart Legs and align the Cart Frame Bracket to the legs. Then tighten the bracket with bolt #3. CAUTION: Do not stand, lean or apply pressure to the Cart Frame Bracket once assembly. 3.
- Page 8 4. Assemble and Install Grease Receptacle and Grease Tray Position Grease Receptacles E to the Holders on the left and right upper bar of cart. Slide the Grease Tray J to the slots underneath Grease Receptacle E. The Grease Tray is required to be present and centered for safety.
- Page 9 6. Install Grill Body With an assistant of other person, lift and position Grill Bowl body to the Cart. Make sure that bottom four corners of grill body must be sitting on the SEAT on each leg. Then lock each leg by closing the latch of each buckle on legs and grill body. Warning: Always keep the latches locked.
- Page 10 8. Install Heat Plates Place the Flame Tamer on the grill and make sure that each tamer will be place over the burner. 9. Install Cooking Grid Place the cooking grid inside the grill body. P 10...
- Page 11 10. Install Hanger Install towel rack to left and right side shelf and secure with bolt #4. 11. Install Ignitor Batteries Unscrew Ignitor Cap from Control Panel Place an AA battery into the igniter body with +VE outward and –VE inward. Position the Cap and Spring over the +VE end and tightly screw it onto the control panel.
- Page 12 Be sure all Control Knobs are set to “OFF” and open the Grill Lids Have your assistant stand behind to the right of the grill and look toward the front of the grill bowl. Never put your face inside the Grill Head. Press the Igniter Cap, You should hear a “clicking”...
- Page 13 Use and Care Instructions Correct LP Gas Tank Use LP Gas grill models are designed for use with two standard 20 lb. Liquid Propane Gas (LP Gas) tanks, not included with grill. Never connect your gas grill to an LP Gas tank that exceeds this capacity.
- Page 14 WARNING A. Do not store a spare LP-Gas tank under or near this appliance. B. Never fill the tank beyond 80 percent full; and C. If the information in “(a)” and “(b)” is not followed exactly, a fire causing death or serious injury may occur.
- Page 15 How to leak Test your LP Gas tank For your safety: All leak tests must be repeated each time your LP Gas tank is exchanged of refilled. When checking for gas leaks do not smoke. Do not use an open flame to check for gas leaks Your grill must be leak tested outdoors in a well-ventilated area, away from ignition sources such as gas fired or electrical appliances.
- Page 16 Connect the regulator assembly to the tank valve and HAND TIGHTEN nut clockwise to a full stop. DO NOT use a wrench to tighten because it could damage the Quick Coupling Nut and result in a hazardous condition. Open the tank valve fully (counterclockwise) and use a soapy water solution to check all connections for leaks before attempting to light your grill.
-
Page 17: Grill Lighting Instructions
CAUTION Always open both left and right Lids as shown before lighting your grill. Lock the wheels to prevent movement while the appliance is in use Wind shield must be properly installed while the appliance is in use Grill Lighting Instructions NOTE: This gas grill is designed to be used with two 20lb LP Gas tanks (not included) for 8 burner operation. - Page 18 Set all Control Knobs to OFF and open the right-side tank valve SLOWLY 1/4 of a turn. To light the four right-side burners, push and turn the forth Control Knob from the right to HIGH. This is considered the middle right Control Knob. Immediately press the right-side Electric Igniter for 3-4 seconds to light the Burner.
- Page 19 WARNING Failure to replace a faulty hose, secure gas supply connections or to open the Lids before proceeding to the Lighting Procedures could result in a fire or explosion could result in a fire or explosion that could cause serious bodily injury, death, or property damage. Manually Lighting Your Grill By Paper Match To light your gas grill by match, insert a match into the Lighting Stick and follow steps 1...
- Page 20 WARNING Failure to comply with these instructions could result in a fire or explosion that could cause serious bodily injury, death or property damage. Keep grill area clear and free from combustible materials, gasoline and other flammable vapors and liquids. Do not obstruct the flow of air for combustion and ventilation.
- Page 21 8. Check each Spark Electrode, adjusting as needed. The space between the Spark Electrode Tip and Spark Receiver should be approximately 3/16”. 9. Replace the Burners and adjust the Gas Collector Box. The edge of the collector box should be overlapping the Burner Port. 10.
- Page 22 METHOD 1: Bend a stiff wire or wire coat hanger into a small hook as shown and run the hook through the Burner Tube and inside the Burner several times to remove debris. METHOD 2: Use a bottle brush with a flexible handle and run the brush through the Burner Tube and inside the Burner several times to remove any debris.
- Page 23 P 23...
- Page 24 This warranty gives you specific legal rights and you may also have other rights which may vary from state to state. For further information or replacement parts, repair and maintenance, please contact manufacturer, Toll Free # 1-888-837-1380 customerservice@rankam.com Rankam Metal Products Manufactory Ltd. 1322 Rankin Drive, Troy, MI 48083. P 24...
