Mocka Bronte Buffet Assembly Instructions Manual

Bronte Buffet
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A B C
screw screw screw
x24 x4 x12
H I J
screw allen key screw
x8 x1 x5
O P Q
rail guide left rail
x3 x3 x3
Ha rdware Supplied
Phillips screwdriver
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
D E F
handle screw bolt
x5 x24 x36
K L M
screw locking nut brace
x14 x36 x24
R S X
right rail hinge screw
x3 x4 x10
G T U
dowel screw screw
x28 x2 x2
N V
screw wall plug
x24 x2
Y W
foot wall strap
x1 x2
Wall
attachment
WARNING: Any furniture that is not anchored to a wall
has the potential to tip over in certain circumstances, ie. if a
child attempts to climb on the furniture or in the event
of an earthquake. Accordingly, we recommend that all
furniture is anchored to a wall. We supply a free safety wall
anchor with all furniture sold and we recommend these are
used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that
different wall materials may require different fixing devices
from those supplied.
