Test Menu
Figure 12 represents the TSI-MUX Test Menu. This
screen allows the user to perform various loopback
tests. This option will be read only as long as the
module is in the "In Service" state. Although
loopbacks can be performed in both the "Out Of
Service, Maintenance" and "Out Of Service,
Shelf:100 Slot:
Unacknowledged Alarms:
Shelf:100 Slot:
Unacknowledged Alarms:
61182022L1-5A
All manuals and user guides at all-guides.com
A Total Access System
MINOR
Test
1. TSI Loopbacks
2. Contiguous TSI Tests
3. Non-Contiguous TSI Tests
Selection:
'?' - System Help Screen

Figure 12. Test Menu Screen

A Total Access System
MINOR
Performance Monitoring
1. Daily
2. Quarter Hourly
3. Reset Performance Registers
Selection:
'?' - System Help Screen

Figure 13. Performance Monitoring Screen

Section 61182022L1-5, Issue 1
Unassigned" states, the user is recommended to
perform the loopbacks in the "Out Of Service,
Maintenance" state.
Performance Monitoring Menu
Figure 13 represents the TSI-MUX Performance
Monitoring Menu.
06/27/01 17:39
Active
06/27/01 17:40
Active
