Page 9: General
Remote Management Module GENERAL This practice is an installation and maintenance guide for the ADTRAN Total Access 3000/ 3010 Remote Management Module (P/N 1181019L1). Figure 1 illustrates the Remote ® Management Module (RMM) front panel. 1181019L1 Figure 1. Remote Management Module... -
Page 10: Description
• Six external alarm inputs for EMS or NMA notification through the six loop pairs normally used for service delivery • Six external alarms, sent via TL1 and SNMP, (two alarms in a Total Access 3000 High Cap shelf; P/N 1181001L2) have programmable severity •... -
Page 11: Compliance
1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by ADTRAN could void the user’s authority to operate this equipment. Shipping Contents The contents include the following items: •... -
Page 12: Installation
The RMM plugs directly into the Total Access 3000 (23-inch) shelf or the Total Access 3010 (19-inch) shelf. Both are rack mounted chassis, with 28 access module slots on the Total Access 3000 and 22 access module slots on the Total Access 3010. -
Page 13: Instructions For Installing The Module
To install the Remote Management Module, perform the following steps: 1. If present, remove the Access Module Blank (P/N 1181953L1) from the appropriate access module slot of the Total Access 3000 chassis. 2. Pull the ejector tab on the bottom of the RMM into the down (open) position. -
Page 14: Front Panel Leds
Remote Management Module Installation and Maintenance Practice Front Panel LEDs The RMM provides front panel LEDs to display status information. Table 2 lists the LEDs and status descriptions. Table 2. Front Panel LEDs Indication Description Lack of power or power failure Green Power up and initialization OK Flashing... -
Page 15: Wiring
Installation Wiring Table 4 lists the necessary RMM pinout information. Table 4. RMM DIN Connections Connection Connection Connection FR_GND –48VDCA PWR_RET FR_GND –48VDCA ALM_4_B ALM_4_A ALM_2_B ALM_3_B ALM_3_A ALM_2_A ALM_1_B ALM_1_A SENSE GROUP HSMC_CLK_FRM_SCU F_ALM CARD MAINT IRQS SC_BUS MUXB_TC MUXB_TD MUXB_RD MUXB_RC... -
Page 16: Operation
The RMM can occupy any access module slot and terminates a DS1 signal in the Total Access 3000/3010 system. Power Interface The RMM receives power from the Total Access 3000/3010 system. SCU User/Supervisory Interface User access to the RMM is through the SCU via the system bus present on the Total Access backplane. -
Page 17: Alarms
Each of the six (two on the Total Access 3000 High Cap) Loop I/O connectors provides a single loop to each access module slot in the chassis. The “ring” side is associated with pins 1–28 on the connector, and the “tip”... -
Page 18: Loopbacks
Remote Management Module Installation and Maintenance Practice Loopbacks The following loopback options are supported by the RMM module. • Manual Loopbacks • In-Band Loopbacks • Loopback Timeouts Manual Loopbacks CAUTION Do not invoke a DS1 loopback if the RMM is being configured remotely and the management link is provided by the RMM. -
Page 19: Menu Structure
Menu Structure MENU STRUCTURE The SCU provides a menu system for the Total Access 3000 shelf. All system-related menus are controlled by the SCU. Each access module has its own user menu structure supported by the module. The menu structure for the RMM is a layered menu tree. Each menu level consists of submenus and/or menu items. -
Page 20: Figure 2. Remote Management Module Menu Tree
Remote Management Module Installation and Maintenance Practice Unit Name: CLEI Code: Part Number: Main 1. Configuration Serial Number: Menu Product Revision: Software Revision: Boot Software Rev: MAC Address: 1. Enabled 1. CSU Loop Code Detect 2. Disabled 2. Provisioning 1. Recovered 2. -
Page 21: Main Menu
Menu Structure Main Menu Figure 3 illustrates the RMM Main menu. Shelf: Slot: Total Access System 10/20/05 11:32 Unacknowledged Alarms: Circuit ID : Remote Management Module Configuration Provisioning Status Alarms Test Circuit ID Selection : '?' - System Help Screen Figure 3. -
Page 22: Configuration
Remote Management Module Installation and Maintenance Practice Configuration Figure 4 illustrates the RMM Configuration screen. Shelf: Slot: Total Access System 06/10/04 19:54 Unacknowledged Alarms: Circuit ID : Configuration Unit Name : TA3000 RMM CLEI Code : SILC209DAA Part Number : 1181019L1 Serial Number Product Revision Software Revision... -
Page 23: Provisioning
Menu Structure Provisioning Figure 5 illustrates the RMM Provisioning menu. Use this screen to make provisioning changes to module performance parameters. Provisioning changes can be made when the unit is in any of its three service states. CAUTION Some provisioning changes can momentarily disrupt traffic. If a selected change has the potential to be service affecting, a system prompt for confirmation is displayed. -
Page 24: Csu Code Loop Detect
Remote Management Module Installation and Maintenance Practice CSU Code Loop Detect CSU Code Loop Detect provisions if the unit responds to CSU loopback codes. • Enabled: Unit responds to CSU loopback codes • Disabled: Unit does not respond to CSU loopback codes DS1 Timing Source DS1 Timing supports the following two options: •... -
Page 25: External Alarms
Menu Structure External Alarms External Alarms lists Alarm #1 – #6. Select an alarm to provision it individually. The following options are supported for each of the alarm inputs: • Name: (Text string up to 40 characters long) • Enable: (Yes, No) •... -
Page 26: Software Update
Remote Management Module Installation and Maintenance Practice Software Update Use Software Update to download new software to the RMM, as available. Software Update supports two transfer protocols: TFTP or YModem. YModem Update To update software via YModem: 1. From the Software Upgrade menu, select , and press YModem Update NTER... -
Page 27: Figure 7. Confirm Software Update
Menu Structure 4. From the YModem Software Update menu, select (this option is Restart Card with Latest Code not available until a transfer is completed), and press NTER A confirmation prompt appears. Figure 7 illustrates the Software Update confirmation prompt. Shelf: Slot: Total Access System... -
Page 28: Tftp Update
Remote Management Module Installation and Maintenance Practice TFTP Update To update software via TFTP: 1. From the Software Upgrade menu, select , and press TFTP Update NTER The TFTP Software Update screen (Figure 8) appears. Shelf: Slot: Total Access System 10/21/05 10:26 Unacknowledged Alarms: Circuit ID :... -
Page 29: Status
Menu Structure Status Figure 9 illustrates the RMM Status menu. The screen is read-only, displaying module status information. Shelf: Slot: Total Access System 10/20/05 13:32 Unacknowledged Alarms: Circuit ID : RMM Status WAN Status Ethernet Status External Alarm Status Selection : '?' - System Help Screen Figure 9. -
Page 30: Wan Status
Remote Management Module Installation and Maintenance Practice WAN Status WAN Status (Figure 10) reports DS1 interface status, including Framing, Alarm, Loopback, and Protocol states. Shelf: Slot: Total Access System 12/16/05 11:54 Unacknowledged Alarms: Circuit ID : WAN Status DS1 Status Line Status : Normal CSU Loop Detect : Enabled... -
Page 31: Table 7. Ppp Lcp/Bcp Status Definitions
Menu Structure The Typical Status states appear under normal operational circumstances. Negotiation states normally occur in rapid succession during the negotiation phase and may only be briefly visible. Link Closure states occur when the connection is terminated, and only appear if the PPP link is incorrectly configured on the far end. -
Page 32: Ethernet Status
Remote Management Module Installation and Maintenance Practice Ethernet Status The RMM Ethernet Status screen (Figure 11) reports Link Status, Speed, Duplex Mode, MAC Address, and Packet Counters. Shelf: Slot: Total Access System 12/16/05 11:55 Unacknowledged Alarms: Circuit ID : RMM Ethernet Status Link Status : Up Link Speed... -
Page 33: External Alarm Status
Menu Structure External Alarm Status The RMM External Alarm Status screen (Figure 12) reports External Alarm Input State, Level, and Enable status. Shelf: Slot: Total Access System 12/16/05 11:58 Unacknowledged Alarms: Circuit ID : RMM External Alarm Status Name Enable Level Detect Status... -
Page 34: Alarms
Remote Management Module Installation and Maintenance Practice Alarms Figure 13 illustrates the RMM Alarms screen. This screen displays real time alarms for the RMM. The date, time, port, alarm level, a brief description, and the alarm status is displayed. NOTE This is not an alarm history log. -
Page 35: Test
Menu Structure Test Figure 14 illustrates the RMM Test menu. Select DS1 Testing to perform various loopback tests at the DS1 level. The loopback options are outlined in Table 6 on page 10. Shelf: Slot: Total Access System 10/20/05 13:37 Unacknowledged Alarms: Circuit ID : RMM Test... -
Page 36: Circuit Id
The Total Access 3000 Remote Management Module does not require routine maintenance for normal operation. ADTRAN does not recommend that repairs be attempted in the field. Repair services may be obtained by returning the defective unit to ADTRAN. Refer to “Appendix A, Warranty”... -
Page 37: Specifications
Specifications SPECIFICATIONS Specifications for the Total Access 3000 Remote Management Module are detailed in Table Table 8. Remote Management Module Specifications Specification Description Mechanical Size: 5.5 inches H × 10.5 inches D × 0.6 inches W Weight: 0.35 pound (5.6 ounces) Mounting: Total Access 3000 shelf;... - Page 38 Remote Management Module Installation and Maintenance Practice This page is intentionally blank. 61181019L1-5C...
-
Page 39: Warranty
Appendix A Warranty WARRANTY AND CUSTOMER SERVICE ADTRAN will replace or repair this product within the warranty period if it does not meet its published specifications or fails while in service. Warranty information can be found at www.adtran.com/warranty. Refer to the following subsections for sales, support, Customer and Product Service (CAPS) requests, or further information. - Page 40 ® Carrier Networks Division 901 Explorer Blvd. Huntsville, AL 35806...
