Status Menu
Figure 11 represents the TSI-MUX Status Menu.
This screen is read only and gives the user status
information.
Alarms Menu
The TSI-MUX Alarms Menu Screen displays
currently active alarms for the MUX module. The
date, time and a brief description of the alarm is
included. The alarm is displayed until the condition is
cleared.
Shelf: Slot:
Unacknowledged Alarms: None
14
All manuals and user guides at all-guides.com
A Total Access System
Service State
System Clock Mode
External BITS Clock Mode : Primary
Selection:
'?' - System Help Screen

Figure 11. Status Menu Screen

Section 61182022L1-5, Issue 1
This is not an alarm history log. All alarms are
logged into an alarm history buffer within the
SCU.
Status
: Out Of Service, Unassigned
: Local
NOTE
09/12/01 08:31
Active
61182022L1-5A
