Main Menu
Figure 3 represents the TSI-MUX Main Menu screen.
This screen allows the user access to the controlling
functions of the module.
Shelf: 1 Slot:
Unacknowledged Alarms:
Shelf: 1 Slot:
Unacknowledged Alarms:
61182022L1-5A
All manuals and user guides at all-guides.com
B Total Access System
Adtran TSI DS0 Mux
1. Configuration
2. Provisioning
3. Inband Management
4. Status
5. Alarms
6. Test
7. Performance Monitoring
8. Protection Configuration
9. Display Options
Selection:
'?' - System Help Screen

Figure 3. TSI-MUX Main Menu Screen

B Total Access System
Configuration
Unit Name
CLEI Code
Part Number
Serial Number
Product Revision
Software Revision : A01
'?' - System Help Screen

Figure 4. Configuration Menu Screen

Section 61182022L1-5, Issue 1
Configuration Menu
Figure 4 represents the TSI-MUX Configuration
Menu screen. This screen is a read only display. It
displays configuration data pertaining to the MUX
module and cannot be changed. Information such as
software revision will change and reflect the new
software as the upgrades are performed.
: TSI MUX
:
: 1182022L1
: 06/22/01
: A
08/08/02 15:47
Active
08/08/02 15:47
Active
