Furniture of America CM3600T Assembly Instructions

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

For more information contact our team: service.ec@foagroup.com

DIFFICULT

CM3600T

Tools Required For Assembly:

Allen Wrench

2 PERSONS RECOMMENDED

Page 1 of 5

(Included)

Rev: 16-12-13

Table of Contents

Do you have a question about the CM3600T and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3600T ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Table Top Bolt Ø5/16" x 2" #2 x 2pcs #B x 8pcs Lock Washer Ø5/16"...
Page 4 1) Prepare 8 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align legs (#3) to the holes of the table top (#1), then secure with bolts (#A). #A x 8PCS #B x 8PCS #C x 8PCS 2) Flip the switch to extend the table top (#1).
Page 5 Flip the switch to lock the table top. LOCK ASSEMBLY IS COMPLETED Page 5 of 5...
