- Page 1 ASSEMBLY INSTRUCTIONS Page 1 of 5...
- Page 2 Page 2 of 5...
- Page 3 Page 3 of 5...
- Page 4 Prepare 3 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#A). Align chair seat (#2) to the holes of the chair back (#1). Secure middle 3 holes of the chair seat (#2) by using bolts (#A). Prepare 4 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#C).
- Page 5 1) Prepare 4 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#B). Align front legs (#3R/L) to the holes of the chair seat (#2). Secure by using bolts (#B), but do not fully tighten. 2) Align and attach stretchers (#4,5) to the gaps of the legs. Secure by using screws (#F), then fully tighten bolts (#B) on the front legs.
