For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM3626T
DIFFICULT
Tools Required For Assembly:
Allen Wrench
2 PERSONS RECOMMENDED
Page 1 of 6
(Included)
Rev: 18-01-2 9
Advertisement
Related Manuals for Furniture of America CM3626T
Summary of Contents for Furniture of America CM3626T
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3626T ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 24pcs Table Top Bolt Ø1/4x2-1/4" #2 x 1pc #B x 24pcs Laminates Lock Washer Ø1/4"...
- Page 4 Align connecting panel (#5) to the holes of the table top (#1), then secure by using bolts (#A) with washers (#B,C). #A x 8pcs #B x 8pcs #C x 8pcs Align legs (#4) to the holes of the connecting panel (#5), then secure by using bolts (#A) with washers (#B,C).
- Page 5 Align laminates (#2) to the holes of the legs (#4), then secure by using bolts (#A) with washers (#B,C). Do not fully tighten bolts (#A). #A x 4pcs #B x 4pcs #C x 4pcs Align floor (#3) to the holes of the legs (#4), then secure by using bolts (#A) with washers (#B,C).
- Page 6 Use the lever to open and extend table top to remove table leaf. OPEN Close table top, then turn the lever to lock. LOCK Page 6 of 6...
