2.2 PCM6xx0Q1EVM-PDK Hardware Settings
The PCM6xx0Q evaluation module has several input configuration options and offers extensive flexibility
that allows the user to evaluate the device in multiple operation modes. The different operation modes are
highlighted in this section.
MK1
J37
J36
Figure 7. PCM6xx0EVM Input Architecture for Channels 1 and 2
The IN1 and IN2 input architecture allows these two channels to be quickly configured to support any of
the supported operation modes. The IN1P and IN1M pins of the PCM6xx0 can optionally connect to an
onboard microphone for quick evaluation of a microphone in AC- or DC-coupled modes. Jumper
configuration details can be found in
As shown in Figure
These channels support only AC-coupled line inputs by default, however DC-coupled line and Mic inputs
are supported though the removal or replacement of R34-R45.
bias resistors for AC-coupled inputs across the MICBIAS voltage and input swing.
IN3P
MICBIAS
R34
J16
J15
+
Figure 8. PCM6xx0Q1EVM Input Architecture for Channels 3-6
SBAU341B – January 2020 – Revised June 2020
Submit Documentation Feedback
Figure 7 shows the architecture of the inputs to the evaluation module.
IN1P IN1M
MICBIAS
J11
4.7k
J7 J8
J3
IN1
J1
-
+
Table 2.
8, the input architecture for channels 3-6 of the PCM6xx0Q1EVM is streamlined.
PCM6xx0Q1
IN3M IN4P IN4M
MICBIAS
R35 R36
R42
DNP
GND
J17 J19
IN3 IN4
J18
- -
+
Copyright © 2020, Texas Instruments Incorporated
PCM6xx0Q1
IN2P
MICBIAS
J12
4.7k 4.7k
J13
J9
1k
J5
J4
GND
J2
+
Table 2
PCM6x60Q1EVM Only
IN5P IN5M
MICBIAS MICBIAS
R37 R38 R39
R43 R44
DNP DNP
GND GND
J20 J22 J23
IN5
J21
-
+
PCM6xx0Q1EVM-PDK Evaluation Module
Hardware Overview
IN2M
MICBIAS
4.7k
J14
J10
1k
J6
GND
IN2
-
lists the recommended values for
IN6P IN6M
MICBIAS
R40 R41
R45
DNP
GND
J26
J25
IN6
J24
-
+
