Specifications
Monitor Specifications
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
Display Colours
Synchronization Range Horizontal:
DVI Digital Input
Viewing Angle
Image Formation Time
Resolutions Supported Landscape:
Active Display
Area (Lanscape)
Power Supply
Current Rating
Dimensions
Weight
EnvironmentalConsiderations
Operating Temperature:
Storage Temperature:
MultiSync LCD1535VI
(NL1502)
(LCD1535VI-BK) Monitor
38 cm/15 inches
Diagonal:
38 cm/15 inches
1024 x 768
Video:
DVI-I (TMDS)
Sync:
Separate sync.TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Compostite sync. Positive/Negative
Analog input:
16,777,216
30 kHz to 60 kHz
Vertical:
50 Hz to 75 Hz
TMDS, 80 MHz max., Single Link
±75°
Left/Right:
Up/Down:
-60° to + 50°
25ms (Typ.) tr=6 ms,tf=19ms
640 x 350 at 31.5 to 70.1 Hz
640 x 480 at 35 Hz to 75 Hz
720 x 400 at 31.5 Hz to 70.1 Hz
800 x 600 at 35.2 Hz to 75 Hz
832 x 624 at 49.7 Hz to 74.5 Hz
1024 x 768 at 48.4 Hz to 75Hz
Horizontal:
304 mm/12.0 inches
Vertical:
228 mm/9.0 inches
AC 100-240 V , 50-60 Hz
1 A @ 100-240 V
Landscape:
345.2 mm (W) x 361.1 mm (H) x 160.7 mm (D)
13.6 inches (W) x 14.2 inches (H) x 6.3 inches (D)
4.8 kg (10.6 lbs)
5 °C to 35 °C
Humidity:
30% to 80%
Altitude:
0 to 3,050 m
-20 °C to +60 °C
Humidity:
10% to 85%
Altitude:
0 to 14,000 m
English-20
Notes
Active matrix; thin film
transistor (TFT) liquid
crystal display (LCD);
0.297 mm dot pitch;
2
300cd/m
white luminence,
typical; 350:1 contrast ratio,
typical
Depends on display card
used.
Automatically
Automatically
Some systems may not
support all modes listed.
Dependent upon signal
timing used, and does not
include border area.
