INSTALLATION
3.1
Space Requirements
•
Maximum installation plate thickness: 11 mm
•
Space requirements in millimeters when installing the operator panel:
50 mm
Note:
The dimensions on the drawing are not proportional.
100 mm
100 mm
204
ky
AKI-CDB-MOD-07T | INSTALLATION
50 mm
Kollmorgen | October 2014
100 mm
8
