Graphic Operator Terminal
Installation Manual
Edition B, October 2014
AKI-CDB-MOD-12T 12.1" Touchscreen HMI
Keep all manuals as a product component during the life span of the product.
Pass all manuals to future users / owners of the product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AKI-CDB-MOD-12T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kollmorgen AKI-CDB-MOD-12T

  • Page 1 Graphic Operator Terminal Installation Manual Edition B, October 2014 AKI-CDB-MOD-12T 12.1” Touchscreen HMI Keep all manuals as a product component during the life span of the product. Pass all manuals to future users / owners of the product.
  • Page 2 Technical changes which improve the performance of the device may be made without prior notice! Printed in the United States of America. This document is the intellectual property of Kollmorgen™. All rights reserved. No part of this work may be reproduced in any form (by photocopying, microfilm or any other method) or stored, processed, copied or distributed by electronic means without the written permission of Kollmorgen™.
  • Page 3: Table Of Contents

    6.3 AKI-CDB-MOD-12T Outline ........
  • Page 4: General

    The Advanced Kollmorgen Interfaces works primarily in an object-oriented way, making it easy to understand and use. Configuration is carried out on a PC using the Kollmorgen Visualization Builder configuration tool. The project can then be transferred and stored in the operator panel itself.
  • Page 5: Safety Precautions

    AKI-CDB-MOD-12T | SAFETY PRECAUTIONS SAFETY PRECAUTIONS Both the installer and the owner and/or operator of the operator panel must read and understand this installation manual. General • Read the safety precautions carefully. • Check the delivery for transportation damage. If damage is found, notify the supplier as soon as possible.
  • Page 6: During Installation

    AKI-CDB-MOD-12T | SAFETY PRECAUTIONS Do not replace expansion unit unless power has been switched off or the area is known to be non-hazardous. NE REMPLACEZ L'UNITÉ D'EXTENSION QUE SI LE COURANT A ÉTÉ COUPÉ OU SI LA ZONE EST JUGÉE NON DANGEREUSE.
  • Page 7: During Use

    AKI-CDB-MOD-12T | SAFETY PRECAUTIONS • Make sure that the voltage and polarity of the power source is correct before connecting the HMI panel to the power outlet. • Peripheral equipment must be appropriate for the application and location. During Use •...
  • Page 8: Installation

    AKI-CDB-MOD-12T | INSTALLATION INSTALLATION Space Requirements • Maximum installation plate thickness: 8 mm • Space requirements in millimeters when installing the operator panel: 100 mm 50 mm 50 mm 100 mm 100 mm 340 mm Note: The dimensions on the drawing are not proportional.
  • Page 9: Installation Process

    AKI-CDB-MOD-12T | INSTALLATION Installation Process The following is needed: • A Torx TX7 screwdriver 1. Unpack and check the delivery. If damage is found, notify the supplier. Note: Place the HMI panel on a stable surface during installation. Dropping the HMI panel or letting it fall may cause damage.
  • Page 10: Connections To The Controller

    AKI-CDB-MOD-12T | INSTALLATION 4. Connect the cables in the specified order, according to the drawing and steps below. Caution: • The HMI panel must be brought to ambient temperature before it is started up. If condensation forms, ensure that the HMI panel is dry before connecting it to the power outlet.
  • Page 11: Technical Data

    AKI-CDB-MOD-12T | TECHNICAL DATA TECHNICAL DATA Parameter AKI-CDB-MOD-12T Front panel, 340 × 242 × 79 mm W × H × D Cut out dimensions, 324 × 226 mm W × H Mounting depth 72 mm (172 mm including clearance) Standalone VESA 75 ×...
  • Page 12 AKI-CDB-MOD-12T | TECHNICAL DATA Parameter AKI-CDB-MOD-12T Power supply +24 V DC (18 to 32 V DC) CE: The power supply must conform with the requirements according to IEC 60950 and IEC 61558-2-4. UL and cUL: The power supply must conform with the requirements for class II power supplies.
  • Page 13: Chemical Resistance

    AKI-CDB-MOD-12T | CHEMICAL RESISTANCE CHEMICAL RESISTANCE Metal Casing The frame and casing material is powder-coated aluminum. This powder paint withstands exposure to the following chemicals without visible change: Acetic acid 10% Phosphoric acid 4% Citric acid 10% Phosphoric acid 10%...
  • Page 14: Touch Screen And Overlay

    AKI-CDB-MOD-12T | CHEMICAL RESISTANCE Touch Screen and Overlay 5.2.1 Autoflex EBA 180L Autoflex EBA 180L covers the overlay surrounding the screen. Solvent Resistance Autoflex EBA 180L withstands exposure of more than 24 hours duration under DIN 42 115 Part 2 to...
  • Page 15: Touchkeyboard And Screen Protection Film

    5.2.3 TouchKeyboard and Screen Protection Film Autoflex EBA 180L It is recommended to use the Autoflex EBA 180L protection film that can be ordered from Kollmorgen. Solvent Resistance The chemical resistance for Autoflex EBA 180L is described in section Autoflex EBA 180L.
  • Page 16: Operator Panel Drawings

    AKI-CDB-MOD-12T | OPERATOR PANEL DRAWINGS OPERATOR PANEL DRAWINGS Connectors Pos. Connector Description Power supply +24 V DC (18-32 V DC) COM 1/2 Communication Ports LAN (Port 2) 1 × 10/100 Base-T (shielded RJ45) 2 × USB Host 2.0, max output current 500 mA...
  • Page 17: Aki-Cdb-Mod-12T Outline

    AKI-CDB-MOD-12T | OPERATOR PANEL DRAWINGS AKI-CDB-MOD-12T Outline max. 8 mm Kollmorgen | October 2014...
  • Page 18: Additional Installation Tips

    AKI-CDB-MOD-12T | ADDITIONAL INSTALLATION TIPS ADDITIONAL INSTALLATION TIPS When experiencing communication problems in for example noisy environments or when operating close to temperature limits, the following recommendations are to be noticed. Grounding the Operator Panel Door Mounting plate in the cabinet...
  • Page 19: Ethernet Connection In The Operator Panel

    AKI-CDB-MOD-12T | ADDITIONAL INSTALLATION TIPS Ethernet Connection in the Operator Panel Industrial Ethernet RJ45 RJ45 RJ45 RJ45 Operator panel RJ45 Operator panel RJ45 Short and Operator panel unshielded Shielded RJ45 Operator panel RJ45 0.1 μF 250 V In some industrial units for Ethernet, the RJ45 contact’s shield is connected to the chassis via a capacitor, see 1 in drawing above.
  • Page 20: To Achieve Better Emc Protection

    AKI-CDB-MOD-12T | ADDITIONAL INSTALLATION TIPS To Achieve Better EMC Protection Use shielded cables for RS232 communication. • • Use twisted pair and shielded cabling for RS422 and RS485. • Use the cabling intended for the bus type; Ethernet, Profibus, CC-Link, CAN, Device Net etc.
  • Page 21: Ambient Temperature

    AKI-CDB-MOD-12T | ADDITIONAL INSTALLATION TIPS Ambient Temperature The maximum ambient temperature for the operator panel is provided in the specifications. The ambient temperature refers to the temperature in the device cabinet which cools the operator panel’s electronics. 50 °C inside...
  • Page 22: Safety

    AKI-CDB-MOD-12T | ADDITIONAL INSTALLATION TIPS Safety Most of the operator panels are fed with 24 V DC. Power supply 230 V AC to 24 V DC Operator panel +24 V Power supply 230 V AC to 24 V DC Operator panel...
  • Page 23: Galvanic Isolation

    AKI-CDB-MOD-12T | ADDITIONAL INSTALLATION TIPS Galvanic Isolation Internal electronic Ethernet DC/DC galvanic isolation Filter DC/AC +24 V DC 0 V (GND) 1.5 m RS422/485 RS232 The operator panel has galvanic isolation against the 24 V DC feed but no galvanic isolation between the communication ports for RS232, RS422/485 and USB.
  • Page 24: Cable And Bus Termination Rs485

    AKI-CDB-MOD-12T | ADDITIONAL INSTALLATION TIPS Cable and Bus Termination RS485 If maximum transfer distance and maximum transfer speed is needed, shielded and twisted pair • cable should be used. The mutual capacitance may not exceed 52.5 pF/m, and the cable area should be at least 0.25 mm...
  • Page 25 AKI-CDB-MOD-12T | ADDITIONAL INSTALLATION TIPS Kollmorgen | October 2014...
  • Page 26 5. Press finger on screen again to enter the service menu. The Service Menu displays: Note: Additional information about the Service Menu options are available in the Kollmorgen Visualization Builder (KVB) online help: HMI Panel System Software/Service Menu HMI to PDMM Connection and Programming Modbus TCP is used to communicate from the Ethernet port of an AKI panel to the X32 connector on the top of an AKD PDMM, also referred to as an Ethernet service port.
  • Page 27 KAS IDE by right-clicking on the System option in the Project Explorer and select “Add HMI Device” to display a list of HMI panels that Kollmorgen has available. Double- click on the project to launch KVB and automatically import tags and the target IP address for the KAS controller.
  • Page 28 About KOLLMORGEN Kollmorgen is a leading provider of motion systems and components for machine builders. Through worldclass knowledge in motion, industry-leading quality and deep expertise in linking and integrating standard and custom products, Kollmorgen delivers breakthrough solutions that are unmatched in performance, reliability and ease-of-use, giving machine builders an irrefutable marketplace advantage.
