The supplier neither guarantees that the graphic operator terminal is suitable for your
particular application, nor assumes responsibility for your product design, installation or
operation.
1.3

During Installation


The graphic operator terminal is designed for stationary installation on a plane surface, where
the following conditions are fulfilled:
– no high explosive risks
– no strong magnetic fields
– no direct sunlight
– no large, sudden temperature changes

Install the product according to the accompanying installation instructions.

Ground the product according to the accompanying installation instructions.

Only qualified personnel may install the graphic operator terminal.

Separate the high voltage, signal and supply cables.

Make sure that the voltage and polarity of the power source is correct before connecting the
product to the power outlet.

Peripheral equipment must be appropriate for the application and location.
1.4

During Use


Keep the graphic operator terminal clean.

Emergency stop and other safety functions may not be controlled from the graphic operator
terminal.

Do not use too much force or sharp objects when touching the touch screen etc.
1.5

Service and Maintenance


Only qualified personnel should carry out repairs.

The agreed warranty applies.

Before carrying out any cleaning or maintenance operations, disconnect the equipment from
the electrical supply.

Clean the display and surrounding front cover with a soft cloth and mild detergent.

Replacing the battery incorrectly may result in explosion. Only use batteries recommended by
the supplier
Graphic Operator Terminal / CONSIDERATIONS AND SAFETY PRECAUTIONS
5
