TECHNICAL DATA
Parameter
Front panel,
W × H × D
Cut out dimensions,
W × H
Mounting depth
Standalone
mounting
Front panel seal
Rear panel seal
Touch screen
material
Touch screen
operations
Reverse side
material
Frame material
Weight
Serial port for
COM1 RS232 and
COM2
RS422/RS485
Serial port for
COM3 RS232 and
COM4
RS422/RS485
Ethernet
USB
Processor
External storage
media
Memory RAM
LED
Real time clock
Battery
Power consumption
at rated voltage
Fuse
204 × 143 × 7 mm
187 × 126 mm
43 mm (143 mm including clearance)
VESA 75 × 75
Note: Maximum screw length for VESA mounting is 4 mm. Usage of longer screws
may lead to damage.
IP 65
IP 20
Polyester on glass, resistive.
Overlay: Autoflex EBA 180L
1 million finger touch operations
Powder-coated aluminum
Powder-coated aluminum
1.010 kg
9-pin D-sub contact with RS232 RTS/CTS, chassis-mounted female with standard
locking screws 4-40 UNC
9-pin D-sub contact with RS232 RTS/CTS, chassis-mounted female with standard
locking screws 4-40 UNC
1 x 10/100/1000 Base-T (shielded RJ45)
3 × USB Host 2.0, max output current 500 mA
Intel® Atom
1 × SD card (optional). Only compatible with the standard SD format with up to 2 GB
storage capacity.
1 GB
1 × multi-color
Yes (on chip)
Lithium battery type BR 2032 (or CR 2032), exchangeable
14 W
3.15 A Slow
ky
AKI-CDB-MOD-07T | TECHNICAL DATA
AKI-CDB-MOD-07T
(1)
.
Kollmorgen | October 2014
11
