- Page 1 TRX950;XT90S PROFESSIONAL REMOTE CAR STARTER WITH ALARM SYSTEM & 2-WAY LCD COMMUNICATION OPERATION MANUAL THIS PRODUCT IS DESIGNED FOR PROFESIONAL INSTALLATION ONLY...
-
Page 2: Table Of Contents
TABLE OF CONTENTS: LCD REMOTE TRANSMITTER: A. REMOTE TRANSMITTER OPERATION… … … … … … … … … … … .… 4 B. BATTERY REPLACEMENT … … … … … … … … … … … … … … … ..… .. 5 C. - Page 3 M. PANIC FUNCTION .… … … … … … … … .… … … … … ..… .… … … .… .… .16 N. TRIGGER THE SYSTEM ..… … ..… … … … … … ..… … … … .… .… … ...17 Clear The Trigger Icons and Melody Sound Stop The Melody Sound Only Noise Abatement Circuit...
- Page 4 WARNINGS: As with any product that performs automatic functions, there are certain safety precautions that you must practice and be aware of. 1. Keep the transmitter out of children’s reach. 2. Do not leave anyone in the vehicle while running on remote control. 3.
-
Page 5: Battery Replacement
A. BATTERY REPLACEMENT: This transmitter uses one (1) 3-volt lithium ion battery (#CR2032) that is placed with the (+) side facing upward. To replace the battery, you will need to use a small flat blade screwdriver and a small Philips screwdriver. Remove the small Philips head screw. -
Page 6: The Remote Lcd Icons With Function
B. THE REMOTE LCD ICONS WITH FUNCTION: Door Lock Door Unlock Your vehicle doors are Your vehicle doors are locked unlocked and the system is Disarmed Armed Mode Valet Mode Your vehicle is in armed All the function shall be mode temporarily on hold. -
Page 7: Clear The Flash Icon And Melody Sound
C: PROGRAMMING OF THE LCD REMOTE TRANSMITTER: Transmitter Button Description Operation LCD screen lamp turns on Press and hold for 1 second (1 second) 1 melody sound to confirm 5 seconds. enters. Timer Programming Mode. Press hold (3 seconds) seconds 2-melody sounds to confirm enter. -
Page 8: Vibration / Melody Mode
times within 3 seconds will clear the flash icon and melody sound o n the LCD screen transmitter 4. Stop The Trigger Melody Sound: While triggering the alarm the LCD screen will alert user through melody sound and flashing trigger icon, press any button on the LCD remote transmitter to stop melody sound only. -
Page 9: D.clock & Timer Setting
2. Press the ) button again showing next order time on the screen (ie.0: 20), press them again (ie.0: 30)… and so on. 3. Leave the buttons starting count down then icon flashes Note: 1.The count down period is fixed as 10 minutes, 20 minutes, 30 minutes, 1 hour, 1.5 hours and 2 hours maximum. - Page 10 1. Clock Setting: Example to AM10:30 1. Press & hold the button for 3 seconds, with two-melody sound and the “Hours” digit flashes for adjusting. 2. Press the button to decrease or increase the “Hour” digit until AM10:xx 3. Press the button once again then the “Minute”...
-
Page 11: Time Set-Up For "Daily Timer Start
“Hours” digit is flashes for adjusting. 3.Press the button to decrease or increase the “Hour” digit until 2:xx 4.Press the button once again then the “Minutes” digit flashes for adjusting. 5. Press the button to decrease or increase the “Minute” digit until 2:30 6. -
Page 12: Button Lock
Silent Arming / Disarming Ignition in "off" position. Active Anti Car-Jacking Ignition in "on" position press and hold for Mode 2 seconds Unlock Doors & Disarm System Two Steps Door Unlock & Press twice within 3 seconds. Disarm System Trunk Release (Channel 3) Press and Hold for 2 seconds Passive Arming By-pass While the system Disarmed. -
Page 13: Led Display
1. The XT-85s Standard transmitter: Press the button first, within 3 seconds press and hold the button for 2 seconds to activate or cancel the button lock function. The “Red LED” will pause flash for few seconds to indicate the remote control transmitter is on “Button Lock”... -
Page 14: Active Arming - Arm & Lock
Light Slow 1. Arming 1 or 3 Chirps 1 Flash Locking Disable Flash 2 or 3 Turns on for 30 2. Disarming 2 or 4 Chirps Unlocking Flashes -second Slow 3. Trigger Alarming Flashes Disable Flashes Flash 4. Passive Fast Starter Disable Flash... -
Page 15: Passive Arming With Passive Door Locking
Arming feature, which allows the security system to arm 30 seconds after the last door is closed. Operation is as follows. 1. Turn the ignition to the “OFF” position and exit the vehicle. 2. After all entrances are closed, the security system LED will flash fast for 30 seconds. -
Page 16: Two Steps Door Unlock
TWO STEPS DOOR UNLOCK: This feature will independently unlock the driver’s door only when disarming the security system. Pushing the button a second time within 3 seconds will unlock the other doors. AUTOMATIC RE-ARM: If this feature is selected, the security system will automatically re-arm itself in 60 seconds after disarming with remote transmitter. -
Page 17: Valet Mode
K. VALET MODE: (System in Disarm or Valet mode) The valet switch allows you to temporarily bypass all alarm function, eliminating the need to hand your transmitter to parking attendants or garage mechanics. When the system is in valet mode, all alarm functions and remote start functions are bypassed, however the remote panic feature and remote door locks will remain operational. -
Page 18: Trigger The System
If the button is not pressed, the alarm will automatically stop after 30 seconds. N. TRIGGER THE SYSTEM When armed, your vehicle is protected as follows: 1. Light impact will trigger the warn-away signal. 2. Heavy impacts / Doors open / Hood open / Trunk open / Turning on the ignition key will trigger the programmed sequence. -
Page 19: Passive Anti Car Jacking
1. Press and hold the trans mitter button at the same time for 2 seconds while the vehicle’s ignition is ON. The parking lights will turns on for 1.5 seconds to indicate this enter. 2. Once the system is armed, If you are forced from the vehicle, the system will trigger when the door is opened and closed while the ignition is “ON”. -
Page 20: System's Status Check
Q. SYSTEM’S STATUS CHECK When you want to check the system’s present status through the LCD screen, Press the transmitter button twice, within 3 seconds press (C) button. It responds with one melody sound. R. DRIVER PAGING It is useful the event that someone wants to page the driver of the parked vehicle. -
Page 21: Ignition Control The Door Lock/Unlock
Note: Turn on the ignition switch or arm the alarm will turn off the dome light. T. IGNITION CONTROL DOOR LOCK/UNLOCK. If the vehicles door locks have been interfaced to the security system, the system will automatically lock the vehicle's doors when the ignition is turned “ON”... -
Page 22: Power On Memory
Your 5-button remote transmitter can be utilized to control a second vehicle security system, To program the remote control transmitter to a second vehicle, follow the instructions for Transmitter programming. Programming the Transmitter to 2 Enter: Turn the ignition key ON 3 times. (Finishing in the ON position) Press valet switch 2 times, holding in on the 2 push, you will hear a long siren chirp. -
Page 23: Remote Start Operation
REMOTE START OPERATION: A. TO REMOTE START THE VEHICLE: When you want to start your vehicle, Activate Remote Start 1. Press button once on the transmitter. 2. The parking light will activate to indicate the remote start received the signal. 3. -
Page 24: Timer / Temperature Start
to exit and lock the vehicle for short periods of time, but would like to leave the motor running and the climate control on. 1.Before turning off the engine, press the button twice on the transmitter and the LED indicator will flash 3 times to confirm enter. 2.Turn the ignition key to OFF position. -
Page 25: Daily Timer Start
Daily Timer Start: The feature is very useful for the driver who wants to run the vehicle punctually at the same time next morning. Before set-up of the “Daily Timer Start”, you should set you time for engine start.( see Timer Setting / Timer set-up for “Daily Timer Start, page 16) ENTER: 1. -
Page 26: Shut-Down Input For Remote Starter
H. SHUT-DOWN INPUT FOR REMOTE STARTER: If any of the following conditions exist while the system is operating, the engine will not start or will shut down immediately: 1. The hood is opened. 2. The brake pedal is pressed. 3. Engine is over-revved. {“Tachometer checking type” only} 4. - Page 27 LIMITED LIFETIME WARRANTY PROVISIONS ( U.S. ,Continental U.S. and Canada Only) Auto Page, Inc. WARRANTS that this new unit has been thoroughly in spected and tested at the factory prior to delivery. Your Auto Page equipment is guaranteed for “life” to the original purchaser/user of the equipment and the original vehicle in which it was installed by an authorized installer under the following conditions: If the product proves defective (according to Auto Page's testing) within the first year, the defective unit may be exchanged or repaired free of charge.
- Page 28 Auto Page will void the product’s limited lifetime warranty. This WARRANTY CARD is for your record. However, Autopage reserves the right to request you to submit this WARRANTY CARD, which must have complete information to receive warranty service. Please keep this card in a secured place .
- Page 29 City, State, Zip Code City, State, Zip Code ___________________________ ________________________________ Telephone Number Dealer’s Telephone Number ___________________________ ________________________________ Year / Make / Model of Vehicle Date of Installation / Purchase ________________________________ Dealer’s Signature “Proof of Purchase” which includes the store name and date of purchase must accompany all warranty returns.
- Page 30 960 Knox Street Unit B Torrance, California 90502 Main Office: 310-323-1800 Customer Service: 800-262-2527 Ext. 462 www.autopageusa.com...
