Autopage RS-725LCD Operation Manual

Autopage RS-725LCD Operation Manual

Professional remote car starter with alarm system & 2-way lcd communication
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
RS-725LCD
PROFESSIONAL REMOTE CAR STARTER
WITH ALARM SYSTEM
&
2-WAY LCD COMMUNICATION
OPERATION MANUAL
THIS PRODUCT IS DESIGNED FOR PROFESIONAL INSTALLATION ONLY
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS-725LCD and is the answer not in the manual?

Questions and answers

Related Manuals for Autopage RS-725LCD

Summary of Contents for Autopage RS-725LCD

  • Page 1 RS-725LCD PROFESSIONAL REMOTE CAR STARTER WITH ALARM SYSTEM & 2-WAY LCD COMMUNICATION OPERATION MANUAL THIS PRODUCT IS DESIGNED FOR PROFESIONAL INSTALLATION ONLY...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS: LCD REMOTE TRANSMITTER: BATTERY REPLACEMENT THE REMOTE LCD ICONS WITH FUNCTION PROGRAMMING OF THE LCD REMOTE TRANSMITTER 1. Screen Lamp ON 2. Power Save Mode 3. Clear The Flash Icon and Melody Sound 4. Stop The Melody Sound. 5.
  • Page 3 Exit the Timer Start TEMPERATURE CHECK TO TURN OFF THE REMOTE START SHUT-DOWN INPUT FOR REMOTE STARTER DISABLING THE REMOTE START SYSTEM Congratulations on your purchase of the RS725LCD remote start vehicle security system. We sincerely hope the purchase of the RS725 remote start security system gives peace of mind to you.

  • Page 4: Transmitters

    TRANSMITTERS The RS725 comes with two transmitters. The XT72LCD is a 2-way transmitter and receiver, also referred to as a transceiver. The XT-33 is a mini-size 1-way transmitter. Both operate on the AM band with a code-rolling feature that will prevent any illegal use of a code-grabber attempting to record and steal the codes of your transmitter.

  • Page 5: Lcd Remote Transmitter

    WARNINGS: As with any product that performs automatic functions, there are certain safety precautions that you must practice and be aware of. 1. Keep the transmitter out of children’s reach. 2. Do not leave anyone in the vehicle while running on remote control. 3.

  • Page 6: Bthe Remote Lcd Icons With Function

    B. THE REMOTE LCD ICONS WITH FUNCTION: Door Lock Your vehicle doors are locked Armed Mode Your vehicle is in armed mode Remote Transmission You are transmitting the signal to control unit Door Open Warning Doors are illegally opened (Zone 3) Shock Sensor Trigger Trigger on Shock Sensor (Zone 4)

  • Page 7: Cprogramming Of The Lcd Remote Transmitter

    C. PROGRAMMING OF THE LCD REMOTE TRANSMITTER: Transmitter Button Description LCD screen lamp turns on for (1 second) 5 seconds. Timer Programming Mode. (3 seconds) Power Save Mode (5 seconds) Clear the Flash Icon and Melody Sound on the LCD Screen Transmitter Button Lock (2-second)

  • Page 8: Vibration / Melody Mode

    6. Vibration / Melody Mode: This is useful when you are in a noisy place and it is difficult to hear the beep sound from the remote control. In this mode, the remote control vibrates itself if your security system is triggered.

  • Page 9: Dclock & Timer Setting

    D. CLOCK & TIMER SETTING: Transmitter Button Press & Hold button for 3 seconds Press button once Press button Alert Alarm Time Setting (Hour) once. Alert Alarm Time Setting (Minute) Press button once Press button once Alert Alarm Setting ON / OFF Count Down Timer Setting Press button once...

  • Page 10: Count Down Timer Setting

    3. Count Down Timer Setting: Example- Set the countdown timer at 2:30 1. Press & hold the button for 3 seconds, two-melodies will sound and the “Hours” digit will flash for adjustment. 2. Press the button 5 times, the LCD screen will show the “Hours”...

  • Page 11: Blcd Display Transmitter Operation

    Passive Arming By-pass Activate or Turn Off The Remote Start Channel # 4 Timer Output (4) Switching code For 2nd Car Operation. B. LCD DISPLAY TRANSMITTER OPERATION ONLY: Transmitter Button System Function System’s Trigger Record System’s Status Check Optional Driving Pager Monitor Indoor Temperature Daily Timer Start LCD screen lamp turns on...

  • Page 12: Gactive Arming - Arm & Lock

    4. Passive Starter Disable 5. Panic Alarming Flashes 6. Car-Jacking Alarming Flashes 7. Car Locator 6 Chirps 12 Flashes G. ACTIVE ARMING – LOCK & ARM: button 1. Press on the transmitter. The siren will chirp once and parking light will flash once indicating that the system is now armed.

  • Page 13: Iactive Disarming - Unlock & Disarm

    by-pass, press the transmitter status. I. ACTIVE DISARMING – UNLOCK & DISARM: 1. Press button on the transmitter. 2. The siren will chirp twice and the parking lights will flash twice indicating that the security system is now disarmed. The vehicle’s doors will unlock and the dome light will turn on for 30 seconds upon disarming.

  • Page 14: Overrides The Alarm With Password Pin Code

    4. Within 15 seconds, enter your chosen second digit code by pressing and releasing the Valet Switch. 5. Turn the ignition switch “OFF” position. 4 Chirps from siren/horn and 3 flashes from the parking lights will indicate the system has disarmed. Note 1: You must override the alarm within 60 seconds.

  • Page 15: Trigger The System

    2. During panic mode, the normal function of this transmitter button will be disabled. The transmitter can be used to lock and unlock the door (if the option is installed), however once the button is pressed, the vehicle’s starter disable device, (where installed) will be disengaged allowing the vehicle to start.

  • Page 16: Oanti Car- Jacking

    O. ANTI CAR- JACKING Warning: If you don't need the car jacking function in this alarm system, be sure to set car jacking feature “OFF”. This system is default setting all car jacking “OFF”. ACTIVE ANTI CAR JACKING: 1. Press and hold the transmitter while the vehicle’s ignition is ON.

  • Page 17: Sdome Light Convenience Delay & Supervision

    Out of Car Driver Paging (Optional Feature) If someone tries to page you by tapping the paging (knock) sensor (OPTIONAL) which is usually mounted on the bottom part of front window, the paging melody sound continues sounding from you Remote LCD Transmitter and the “ flash on the LCD screen.

  • Page 18: Xsecond Vehicle Security System Operation

    X. SECOND VEHICLE SECURITY OPERATION: Your 5-button remote transmitter can be utilized to control a second vehicle security system, To program the remote control transmitter to a second vehicle, follow the instructions for Transmitter programming. Programming the Transmitter to 2 Enter: 1.

  • Page 19: Remote Start Operation

    REMOTE START OPERATION: A. TO REMOTE START THE VEHICLE: When you want to start your vehicle, 1. Press button once on the transmitter. 2. The parking light will activate to indicate the remote start received the signal. 3. The engine will start in approximately 5 seconds. 4.

  • Page 20: (2) Hours Timer Start With Temperature-Control Off

    2. Before turning off the engine, press and release time. -- The LED will flash indicating the remote start has entered the turbo charge mode. 3. Take the “Ignition Key” from the key cylinder. -- Engine keeps running. -- 4. Exit and secure the vehicle. -- Engine continues running until the pre-programmed time elapsed.

  • Page 21: Ftemperature Check

    The vehicle will shut down and turn off the parking light to indicate engine stopped. H. SHUT-DOWN INPUT FOR REMOTE STARTER: If any of the following conditions exist while the system is operating, the engine will not start or will shut down immediately: 1.
  • Page 22 LIMITED LIFETIME WARRANTY PROVISIONS ( U.S. ,Continental U.S. and Canada Only) Auto Page, Inc. WARRANTS that this new unit has been thoroughly inspected and tested at the factory prior to delivery. Your Auto Page equipment is guaranteed for “life” to the original purchaser/user of the equipment and the original vehicle in which it was installed by an authorized installer under the following conditions: If the product proves defective (according to Auto Page's testing) within the first year, the defective unit may be exchanged or repaired free of charge.
  • Page 23 This WARRANTY CARD is for your record. However, Auto Page reserves the right to request you to submit this WARRANTY CARD, which must have complete information to receive warranty service. Please keep this card in a secured place. AUTOPAGE WARRANTY SERVICE CARD _______________ Model: Serial # _______________...
  • Page 24 960 Knox Street Unit B Torrance, California 90503 Main Office: 310-323-1800 Customer Service: 800-262-2527 Ext. 462 www.autopageusa.com...
