Scanomat TopBrewer Cleaning Manual

Hide thumbs Also See for TopBrewer:

Advertisement

Quick Links

Download this manual
Cleaning Manual
TopBrewer Pro & Compact
1. Brewer Cleaning (daily)
2.
Milk Cleaning (3 times weekly)
3. Choco Cleaning (2 times weekly)
10/2021

Advertisement

loading
Need help?

Need help?

Do you have a question about the TopBrewer and is the answer not in the manual?

Questions and answers

Related Manuals for Scanomat TopBrewer

Summary of Contents for Scanomat TopBrewer

  • Page 1 Cleaning Manual TopBrewer Pro & Compact 1. Brewer Cleaning (daily) Milk Cleaning (3 times weekly) 3. Choco Cleaning (2 times weekly) 10/2021...
  • Page 2 In general Milk Choco Milk Choco Milk Cleaning Cloth and Paper Towel In our webshop you have the opportunity to purchase the used cleaning buy at shop.scanomat.com products in this guide and a wide array of other assecories for your TopBrewer.
  • Page 3 BREWER CLEANING PERFORM DAILY USING YELLOW TABS...
  • Page 4 COMPACT OPEN THE STAINLESS STEEL DOOR The machine goes into neutral mode with the bottom piston raised, ready for cleaning when the door is opened. PRO: Open the hinged door by pushing the right side until it pops out and pull it towards you. COMPACT: Open the door by pivoting it outwards from the bottom and sliding it into a horizontal hold position.
  • Page 5 REMOVE CASING REMOVE PLACE AND HOUSEING MILK FOAMER CLEANING HEAD Gently remove the outer Unscrew the milk foamer (A). Fit the Cleaning Head (A) metal casing (A) of the Seperate the two parts of the onto the faucet by sliding it milk foamer by twisting foamer unscrewing it clock- onto the milk foamer.
  • Page 6 MOVE SCRAPER REMOVE GROUND COFFEE The scraper can be moved freely to allow Brush around the grey base plate in order to access to all components. remove any ground coffee deposits. Start by pulling out the scraper arm (black) Brush the deposits into the dreg bin. on the brewing unit.
  • Page 7 Having removed most of the coffee grounds, Push the scraper back into the position as wipe the top piston sieve (underside) as well shown. Place a TopBrewer Yellow cleaning as around the top piston O-ring (white ring). tablet inside the scraper.
  • Page 8 REMOVE CLEANING HEAD Gently remove the outer metal casing (A) of the milk foamer by twisting the metal head clockwise. Remove the cleaning head (B) from the faucet. CLOSE DOOR AND START CLEANING PROCESS Close the door on the machine and push the faucet all the way down the the dip- tray.
  • Page 9 Then re-attach the outer metal casing by twisting the metal head anti-clockwise (B). PRIME WITH ESPRESSO DRINK Prior to use, prime the TopBrewer by dispensing one espresso or coffee drink. Discard the drink. Now the brewer is clean and ready for use.
  • Page 10 CLEANING PERFORM 3 TIMES A WEEK Before the milk clean, please ensure that you have done the brewer cleaning. This is the optimal way to maintain your TopBrewer. We recommend doing the milk clean 3 times a week. Use the blue alkaline milk fat remover 4 times as offen as the green descaler.
  • Page 11 Fill another jug with 600 ml of hot/ Push the faucet all the way down tap water, approx. 300 ml. steaming water from the TopBrewer, or to the diptray to away liquid splash hot tap water. during the cleaning process.
  • Page 12 RINSE WITH COLD WATER RINSE WITH CLEANING LIQUID Place the jug inside the fridge and insert the milk Replace the jug in the fridge with the hot water jug. line(s) into the water. Insert the milk line(s) into the water. Select “Cold Milk”...
  • Page 13 CUSTOMISE SIZE AND CUPS RINSE WITH COLD WATER Slide the size and number of cups to maximum and Replace the jug in the fridge with the cold water jug. select “Start now”. Insert the milk line(s) into the water. Repeat untill the jug is empty. Select “Cold Milk”...
  • Page 14 WIPE FRIDGE AND ADD MILK PRIME WITH MILK DRINK Remove the jug and wipe the fridge inside with a Prior to use, prime the TopBrewer milk system by damp cloth. dispensing a small cup of milk. Place the milk can or container, add the milk lines Discard the drink.
  • Page 15 CHOCO CLEANING PERFORM TWICE A WEEK USING CHOCO CLEANING SYSTEM...
  • Page 16 OPEN PREPARE CHOCO CLEANING CONNECT CLEANING CAN Mix 400 ml of hot tap water with 20 ml of milk fat Place the cleaning can on the table, with the black stud cleaning liquid (blue) in a jug and add it to the choco facing down (avoid spilling the liquid) and connect the cleaning can (make sure the lever is closed on the tube).
  • Page 17 OPEN START CLEANING CLEANSE WITH WATER RECONNECT & PRIME Select the hot chocolate drink Add 400 ml clean cold water to Disconnect the cleaning can tube. from the menu on the iPad. the cleaning can. Select the hot Wipe off the connector on the rack. chocolate drink, maximise the size Maximise the size and cup and cup numbers, select “Start...
  • Page 18 COMPACT IMPROVING TASTE EXPERIENCE REMOVING COFFEE WASTE Remove lid from bean hopper and wipe with a In the status bar of the app, the machine will damp cloth prior to filling it with beans. notify you when the coffee dreg bin is full. When removing the bin (keep switched on) the unit will Fresh Amokka®...
