- Page 1 IM3057 02/2021 REV04 SPEEDTEC 215C OPERATOR’S MANUAL ENGLISH Lincoln Electric Bester Sp. z o.o. ul. Jana III Sobieskiego 19A, 58-260 Bielawa, Poland www.lincolnelectric.eu...
-
Page 2: Table Of Contents
12/05 THANKS! For having choosen the QUALITY of the Lincoln Electric products. Please Examine Package and Equipment for Damage. Claims for material damaged in shipment must be notified immediately to the dealer. For future reference record in the table below your equipment identification information. Model Name, Code &... -
Page 3: Technical Specifications
Technical Specifications NAME INDEX SPEEDTEC 215C K14146-1 INPUT Input Voltage U 230 Vac ± 10%, 1-phase 115 Vac ± 10%, 1-phase Frequency 50/60 Hz Input Amperes I 1max Input Power at Rated Cycle (40°C) 6,2kVA @ 25% Duty Cycle 2,6kVA @ 40% Duty Cycle cos φ... -
Page 4: Eco Design Information
Efficiency and idle power consumption: Efficiency when max power Index Name Equivalent model consumption / Idle power consumption K14146-1 SPEEDTEC 215C 80,7% / 47W No equivalent model Idle state occurs under the condition specified in below table IDLE STATE Condition Presence... - Page 5 Typical gas usage for MIG/MAG equipment: DC electrode positive Wire Wire Feeding Gas flow Material type diameter Shielding Gas Current Voltage [m/min] [l/min] [mm] Carbon, low 0,9 ÷ 1,1 95 ÷ 200 18 ÷ 22 3,5 – 6,5 Ar 75%, CO alloy steel Aluminium 0,8 ÷...
-
Page 6: Electromagnetic Compatibility (Emc)
Lincoln Electric. Before installing the machine, the operator must check the work area for any devices that may malfunction because of electromagnetic disturbances. -
Page 7: Safety
Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or damage to this equipment. Read and understand the following explanations of the warning symbols. Lincoln Electric is not responsible for damages caused by improper installation, improper care or abnormal operation. - Page 8 WELDING SPARKS CAN CAUSE FIRE OR EXPLOSION: Remove fire hazards from the welding area and have a fire extinguisher readily available. Welding sparks and hot materials from the welding process can easily go through small cracks and openings to adjacent areas. Do not weld on any tanks, drums, containers, or material until the proper steps have been taken to insure that no flammable or toxic vapors will be present.
-
Page 9: Introduction
Verify the connection of ground wires from the machine to the input source. The welding machine SPEEDTEC 215C must be connected to a correctly installed plug-in socket with an earth pin. Input voltage is 115Vac 50/60Hz or 230Vac 50/60Hz. For... - Page 10 Left Knob: The value of parameter in the upper left 11. Gas Connector: Connection for gas line side of display [2] is adjusted. 12. Power Lead with Plug (3m): Power lead with plug is Display: Parameters of welding process are shown. a standard equipment.
- Page 11 If the welding polarity has to be changed, user should: Switch off the machine. Determine the wire polarity for the wire to be used. Consult the electrode data for this information. Take off the terminal block’s shield [17]. ...
- Page 12 Table 2 WORK LEAD English English...
- Page 13 Loading the Electrode Wire Adjusting of Force of Pressure Roll Force Turn the machine off. Open the side cover of the machine. The pressure arm controls the amount of force the drive Unscrew the locking nut of the sleeve. rolls exert on the wire.
- Page 14 Changing Driving Rolls Welding GMAW, FCAW-SS Process SPEEDTEC 215C can be used to welding GMAW and FCAW-SS process. It has been provided with synergic WARNING GMAW process. Turn the input power off of the welding power source SPEEDTEC 215C packaging does not include the gun before installation or changing drive rolls.
- Page 15 Welding SMAW (MMA) Process In synergic mode, the welding load voltage is not set by SPEEDTEC 215C does not include the electrode holder user. The correct welding load voltage will set by the with lead necessary for SMAW welding, but the one can machine’s software.
- Page 16 Welding GTAW Process Sleep Mode SPEEDTEC 215C can be used to GTAW process with When the machine is turned on but not in use for longer DC (-). Arc ignition can be achieved only by lift TIG than 10 minutes, sleep mode is actrivated to save method (contact ignition and lift ignition).
- Page 17 Guide’s Marking Interface SPEEDTEC 215C Description of the user interface in "Quick Guide" chapter Select Welding Process SMAW (MMA) Welding Basic menu GMAW (MIG/MAG) Burnback Brightness Level Manual Welding View Software and FCAW- Self shielded Run-in WFS Hardware Version Manual Welding...
- Page 18 Lincoln Electric is not in a position to warrant or guarantee such advice, and assumes no liability, with Any noticeable damage should be reported immediately respect to such information or advice.
-
Page 19: Weee
12/05 Part List reading instructions Do not use this part list for a machine if its code number is not listed. Contact the Lincoln Electric Service Department for any code number not listed. Use the illustration of assembly page and the table below to determine where the part is located for your particular code machine. -
Page 20: Quick Guide
Quick Guide English English... - Page 21 English English...
- Page 22 English English...
-
Page 23: Accessories
Accessories K10429-15-3M The gas-cooled gun LGS 150 G-3.0M MIG GUN - 3m. KP10461-1 Gas nozzle conical Ø12mm. KP10440-06 Contact Tip M6x25mm ECu 0.6mm KP10440-08 Contact Tip M6x25mm ECu 0.8mm KP10440-09 Contact Tip M6x25mm ECu 0.9mm KP10440-10 Contact Tip M6x25mm ECu 1.0mm KP10440-10A Contact Tip M6x25mm Al 1.0mm KP10468...
