Lincoln Electric
This manual applies to
Part No.
Code
K32048-1
70169
K32049-1
70170
K32049-2
70171
K32050-1
70172
K32050-2
70173
Safety Depends on You
Lincoln Electric welders are designed and built with
safety in mind. However, your overall safety can be
increased by proper installation and thoughtful operation
on your part. Read and observe the general safety
precautions on page 2 and follow specific installation
and operating instructions included in this manual.
Most importantly, think before you act and be careful.
IM6015
October 2008
IM6015
®
Australasia
Description
Volts
®
REDI-MIG
210c
240
®
REDI-MIG
250c
240
®
REDI-MIG
250s
240
®
REDI-MIG
325c
415
REDI-MIG
®
325s
415
REDI-MIG
REDI-MIG
250s, 325c & 325s
Operator's Manual
Warranty Registration
www.mylincolnwarranty.com.au
®
210c, 250c, 250s, 325c, 325s
®
210c, 250c,
Complete your warranty registration
online for your chance to win a Lincoln
Electric welding helmet valued at $299
– one winner drawn each month – and
the chance to win a Hot Lap with V8
Supercar driver Jason Bright*.
*Competition terms and conditions can be viewed at:
www.mylincolnwarranty.com.au
Page 1
Advertisement
Related Manuals for Lincoln Electric REDI-MIG 210c
Summary of Contents for Lincoln Electric REDI-MIG 210c
- Page 1 *Competition terms and conditions can be viewed at: Safety Depends on You www.mylincolnwarranty.com.au Lincoln Electric welders are designed and built with safety in mind. However, your overall safety can be increased by proper installation and thoughtful operation on your part. Read and observe the general safety precautions on page 2 and follow specific installation and operating instructions included in this manual.
- Page 2 INDEX ARC WELDING SAFETY PRECAUTIONS WELDING, EMF & PACEMAKERS INSTRUCTIONS FOR ELECTROMAGNETIC COMPATIBILITY Section 1 INSTALLATION Location Connection to Mains Supply Shielding Gas Supply (for the Gas Metal Arc Welding Process) Gun and Cable Installation Output Polarity Connection Section 2 OPERATING INSTRUCTIONS Duty Cycle Control Panel...
-
Page 3: Arc Welding Safety Precautions
PROTECT YOURSELF AND OTHERS FROM POSSIBLE SERIOUS INJURY OR DEATH. READ AND UNDERSTAND BOTH THE SPECIFIC INFORMATION GIVEN IN THE OPERATING MANUAL FOR THE WELDER AND/OR OTHER EQUIPMENT TO BE USED AS WELL AS THE FOLLOWING GENERAL INFORMATION. ARC WELDING SAFETY PRECAUTIONS ARC RAYS can burn ELECTRIC SHOCK can kill 1. -
Page 4: Installation
3. Should the primary cord be damaged, a special cord is required, and is available from Lincoln Electric. 4. Parts should be ordered from Lincoln, its offices or the nearest Authorised Field Service Shop. (The “Lincoln Service Directory”... - Page 5 WELDING, EMF & PACEMAKERS All welders should follow safe practices that minimise their Welders with pacemakers exposure to electric and magnetic fields (EMF). There is no question that the fields in arc welding can interfere For welders wearing implanted pacemakers, safe welding with a pacemakers function.
-
Page 6: Mains Supply
British Standard EN 50199) occurs, it may be necessary to take additional precautions such • for using with other Lincoln Electric/LiquidArc equipment. as filtering the mains supply. Consideration should be given • designed for industrial and professional use. - Page 7 QUALITY product by Lincoln Electric. We want you to take pride in operating this Lincoln Electric Company product - as much pride Thank You as we have in bringing this product to you! Please record your equipment identification information below for future reference. This information can be found on your machine nameplate.
