SETUP GUIDE
SMART ROOM SYSTEM WITH SKYPE FOR BUSINESS
To configure a SMART Board 8084i-G4 interactive flat panel
a. Press the Input Select button
input source is HDMI3/PC.
b. Press MENU on the interactive flat panel's remote control.
c. Press the down arrow until you highlight the OPTION menu, and then press OK.
d. Press the down arrow until you highlight Lync Room Reset, and then press OK.
e. Press the left arrow to highlight Reset, and then press OK.
NOTE
Completing steps b through e configures the interactive flat panel for use with the room
system. In addition, completing these steps disables the volume and input select controls
on the front control panels.
f. Press INPUT, and then press the red button (below the BACK button).
The Input Label menu appears.
g. Using the left and right arrow buttons, highlight HDMI3/PC, and then press OK.
h. Using the left, right, up and down arrow buttons, highlight PC, and then press OK.
i. Press the down arrow to highlight Close, and then press OK.
In the Input List menu, the computer input's icon indicates that its operating mode is PC.
IMPORTANT
If you do not complete steps f through i, the following could occur:
The interactive flat panel might not display the outer edges of the interactive flat
o
panel's display.
Users might notice higher than normal video latency.
o
j. Press MENU.
k. Press the down arrow until you highlight the PICTURE menu, and then press OK.
l. Press the down arrow until you highlight Picture Mode, and then press OK.
8
on the interactive flat panel's front control panel until the
1026558 Rev 03
