SETUP GUIDE
SMART ROOM SYSTEM WITH SKYPE FOR BUSINESS
l. Press Calibrate.
The calibration screen appears. This can take a few moments.
NOTE
If the calibration screen doesn't appear on the selected interactive flat panel, move it to the
selected interactive flat panel by pressing the spacebar on the keyboard.
m. Follow the on-screen instructions to calibrate and orient the interactive flat panel.
n. If you're configuring a room system with two interactive flat panels, repeat steps i to m for the
second interactive flat panel.
NOTE
You don't need to calibrate or orient the console.
o. Continue to step p.
To optimize the camera
p. If SMART Settings isn't open from the previous steps, click OEM Settings, and then click
SMART Settings.
SMART Settings appears.
q. Click SMART Hardware Settings.
r. Click the camera's icon.
s. Click Preview.
The Camera Configuration window opens.
t. Select the mains power line frequency for your country (50 Hz or 60 Hz), set the pan, tilt and
zoom as appropriate for the meeting room's size, make any other necessary changes to the
camera settings, and then click OK.
NOTES
Avoid using digital zoom unless necessary because it can reduce the perceived quality
o
of the video.
Physically tilt the camera lens before using the digital tilt settings.
o
Digital pan and tilt options are available only when the camera is zoomed in.
o
u. Click OK.
SMART Settings closes.
v. Continue to Procedure 9: Testing Skype for Business account settings on the facing page.
20 1026558 Rev 03
