READ THIS MANUAL CAREFULLY!
It contains important safety information.
OWNER'S MANUAL
YXM700PE
YXM700PHE
1XP-F8199-7A

Advertisement

Table of Contents
loading

Related Manuals for Yamaha VIKING YXM700PE

Summary of Contents for Yamaha VIKING YXM700PE

  • Page 1 READ THIS MANUAL CAREFULLY! It contains important safety information. OWNER’S MANUAL YXM700PE YXM700PHE 1XP-F8199-7A...
  • Page 2 Read this manual carefully before operating this vehicle. This manual should stay with this ve- hicle if it is sold. EC Declaration of Conformity conforming to Directive 2006/42/EC We, YAMAHA MOTOR CO., LTD. 2500 Shingai, Iwata, Japan, declare in sole responsibility, that the product YXM700E (YXM700PE) (5Y4AM63W0D0500101–) (YXM700PHE) (5Y4AM65W0D0500101–)
  • Page 3 Congratulations on your purchase of the Yamaha YXM700PE/YXM700PHE. It represents the re- sult of many years of Yamaha experience in the production of fine sporting, touring, and pace-set- ting racing vehicles. With the purchase of this Yamaha, you can now appreciate the high degree of craftsmanship and reliability that have made Yamaha a leader in these fields.
  • Page 4 EVU00021 IMPORTANT MANUAL INFORMATION FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SE- RIOUS INJURY OR DEATH. Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
  • Page 5 ● It is illegal to operate this vehicle on public lands where vehicles its size are prohibited. YXM700PE/YXM700PHE OWNER’S MANUAL ©2013 by Yamaha Motor Co., Ltd. 1st edition, June 2013 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd.

  • Page 6: Table Of Contents

    EVU00050 Adjusting the driver seat position...4-19 CONTENTS Seat belts ........4-20 Glove compartment .......4-21 LOCATION OF THE WARNING Storage compartments ....4-21 AND SPECIFICATION LABELS..1-1 Cup holders........4-22 Cargo bed ........4-23 SAFETY INFORMATION....2-1 The front and rear shock absorber assemblies ........4-26 DESCRIPTION .........
  • Page 7 LEARNING TO OPERATE YOUR VEHICLE ........7-14 OPERATION........6-1 Personal protective equipment..7-14 Engine break-in....... 6-1 Practice for new Yamaha Viking Starting the engine......6-2 users ..........7-15 Drive select lever operation and Getting ready to ride ...... 7-16 reverse driving....... 6-4 Turning...........7-16...
  • Page 8 Rough terrain......... 7-24 Cleaning the spark arrester ...8-30 Pavement ........7-24 Valve clearance ......8-31 Water ..........7-24 Brakes..........8-32 Loose terrain/slippery terrain..7-25 Checking the front and rear brake Brush or wooded areas ....7-26 pads ..........8-32 Encountering obstacles....7-26 Checking the parking brake pads ..........8-33 PERIODIC MAINTENANCE AND Checking the brake fluid level..8-33...
  • Page 9 Battery ........... 8-42 Jump-starting ........ 8-46 Fuse replacement ......8-48 Replacing a headlight bulb ... 8-50 Headlight beam adjustment ..8-53 Tail/brake light bulb replacement ........ 8-53 Troubleshooting ......8-55 Troubleshooting charts ....8-57 CLEANING AND STORAGE.... 9-1 Cleaning .......... 9-1 Storage..........

  • Page 10: Location Of The Warning And Specification Labels

    EVU00060 L OCATION OF THE WARNING AND SPECIFICATION LABELS...
  • Page 11 Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a re- placement label is available from your Yamaha dealer.
  • Page 12 1 For Europe 4 For Europe AVERTISSEMENT YXM700E 2013 35.0 kW WARNING WARNING YAMAHA MOTOR CO.,LTD. 623 kg 2500 SHINGAI,IWATA,JAPAN 1XD-F155A-00 Any part of your Any part of your Toute partie du corps body (arms, legs, body (arms, legs, (bras, jambes, tête) se...
  • Page 13 7 For Europe WARNING Do not rest hands or arms on door or shoulder bolster. To avoid Injury, keep hands and arms completely Inside the vehicle by holding the steering wheel or handhold. YAMAHA 1XD-K8483-00 6 For Europe WARNING AVERTISSEMENT Ne pas appuyer les mains ni les bras sur la portiè...
  • Page 14 (if applicable) du passager, des accessoires, de l’équipement, et trailer tongue weight. (le cas échéant) du timon. YAMAHA 1XD-F1696-10 YAMAHA 1XD-F1696-20...
  • Page 15 • When loaded with cargo or towing a trailer: • Reduce speed and allow more room to stop. • Turn gradually and slowly. • Avoid hills and rough terrain. • Read Owner’s Manual before loading, towing, or pulling objects. YAMAHA 1XD-F4897-00...
  • Page 16 Lors du transport d’une charge ou lors du remorquage : – Réduire la vitesse et prévoir une distance de freinage accrue. YAMAHA 1XD-K7762-10 – Négocier les virages progressivement et lentement. – Éviter les pentes et les terrains accidentés.
  • Page 17 MAX 7.3 INCH accidents. • Secure load to prevent it (185MM) from shifting. YAMAHA 5UG-F151J-00 • Never load more than 490 N (50 kgf)/110 lbf tongue weight on towing bracket. • Do not tow more than...
  • Page 18 6664 N(680 kgf)/1500 lbf 1XD-F1558-00 (remorque plus chargement). • N’attacher charge ou remorque qu’au support de fixation d’attelage. • Lire le manuel du propriétaire avant de charger le véhicule et de remorquer ou tirer une charge. YAMAHA 1XD-F151K-10...
  • Page 19 R ea d T ip s Gu id e fo r th e Re crea tio na l Off-H ig hway Veh icle Dr i ve r Fol low Al l Instr u cti on a nd Wa r ni ng s YAMAHA 1XD-F1568-00 B e P r e p a r e d A d j u s t , l o c k a n d n eve r r e m o ve h a n d h o l d .
  • Page 20 Ne jamais permettre à plus de deux occupants à prendre place dans le véhicule. Lire le Manuel du propriétaire. Lire le Guide de conseils à l’intention du conducteur du véhicule récréatif hors route. Suivre toutes les directives et tous les avertissements. YAMAHA 1XD-F1568-10 1-11...

  • Page 21: Safety Information

    SAFETY INFORMATION Be a responsible owner As the vehicle’s owner, you are responsible for the safe and proper operation of your Yamaha Viking. While understanding all parts of this manual are important for vehicle ownership, be sure to read this chapter and the instructions in Chapter 7 before operating your Yamaha Viking. Also use these two chapters and the labels on the vehicle to instruct new operators and passengers.
  • Page 22 Before you operate your Yamaha Viking ● Prepare yourself and your passengers: • This vehicle is intended for use only by an operator 16 or older with a valid motor vehicle li- cense. Check country laws for minimum age requirements.
  • Page 23 Prepare your vehicle Perform the pre-operation checks each time you use the vehicle to make sure it is in safe operat- ing condition. Failure to inspect or maintain the vehicle properly increases the possibility of an ac- cident or equipment damage. See page 5-1 for a list of pre-operation checks. Prepare your load or trailer Carrying loads, towing a trailer, or pulling objects can affect handling, stability, and cause the risk of overturns or other accidents.
  • Page 24 While using your Yamaha Viking ● Keep your body completely inside the vehicle at all times. Keep both hands on the steering wheel. Be sure the passengers are seated, belted, and holding onto the passenger handhold. Close doors before driving. Any part of your body (arms, legs, and head) outside the vehicle can be struck by objects your vehicle is passing or crushed by the vehicle cage/frame in a roll- over accident.
  • Page 25 ● Avoid rollovers: • Use care when turning: • Turning the steering wheel too far or too fast can result in a rollover. • Avoid sideways sliding, skidding, or back-wheel sliding, and never do donuts. • Slow down before entering a turn and avoid hard braking in a turn. •...
  • Page 26 ● If you think or feel that the vehicle may tip or roll, keep your body completely inside the protec- tive structure of the vehicle: • Brace yourself by pressing your feet firmly on the floorboards and keep a firm grip on the steering wheel or passenger handhold.
  • Page 27 Avoid carbon monoxide poisoning All engine exhaust contains carbon monoxide, a deadly gas. Breathing carbon monoxide can cause headaches, dizziness, drowsiness, nausea, confusion, and eventually death. Carbon monoxide is a colorless, odorless, tasteless gas which may be present even if you do not see or smell any engine exhaust.
  • Page 28 Many companies with no connection to Yamaha manufacture parts and accessories or offer other modifications for Yamaha vehicles. Yamaha is not in a position to test the products that these af- termarket companies produce. Therefore, Yamaha can neither endorse nor recommend the use of accessories not sold by Yamaha or modifications not specifically recommended by Yamaha, even if sold and installed by a Yamaha dealer.
  • Page 29 Aftermarket tires and rims The tires and rims that came with your Viking were designed to match the performance capabili- ties and to provide the best combination of handling, braking, and comfort. Other tires, rims, sizes, and combinations may not be appropriate. Refer to page 8-40 for tire specifications and more in- formation on replacing your tires.

  • Page 30: Description

    EVU00080 D ESCRIPTION 1 2 3 I J K 1. Headlight 14. Engine oil dipstick 2. Front shock absorber assembly 15. Passenger seat belt 3. Brake fluid reservoir 16. Passenger seat 4. Driver seat 17. Sun top (for sun top models) 5.
  • Page 31 26. Light switch 37. Multi-function meter unit 27. On-Command drive knob 38. Passenger handhold 28. Steering wheel 39. Grove compartment 29. Main switch 40. Storage compartment 30. Parking brake lever 31. Helmet indicator light The vehicle you have purchased may differ 32.

  • Page 32: Instrument And Control Functions

    EVU00130 I NSTRUMENT AND CONTROL Functions of the respective switch positions FUNCTIONS are as follows: “ ” (on): EVU00140 All electrical circuits are supplied with power. Main switch The key cannot be removed. The helmet indicator light comes on and stays on while the key is turned to “...

  • Page 33: Indicator Lights And Warning Lights

    EVU00150 Indicator lights and warning lights 1. Helmet indicator light “ ” 2. Seat belt indicator light “ ” 1. On-Command differential gear lock indicator light “DIFF. LOCK” EVU01140 2. Low-range indicator light “L” Low-range indicator light “L” 3. High-range indicator light “H” This indicator light comes on when the drive 4.
  • Page 34 EVU00170 Neutral indicator light “N” The On-Command differential gear lock indi- This indicator light comes on when the drive cator “ ” and the On-Command differential DIFF. LOCK select lever is in the “N” position. gear lock indicator light “DIFF. LOCK” come on when the On-Command drive knob “2WD/ 4WD/DIFF LOCK”...
  • Page 35 “ ” (on). If the warning light does not come on initially when the key is turned to “ ” (on), or if the warning light remains on, have a Yamaha dealer check the electrical circuit.
  • Page 36 When this occurs, turned to “ ” (on), and then goes off once have a Yamaha dealer check the self-diagno- the engine is started. If the warning light re- sis system. (See page 4-11 for an explanation mains on or comes on after the engine is of the self-diagnosis device.)

  • Page 37: Multi-Function Meter Unit

    ” (on) to remind the occupants to always wear a helmet. If the indicator light does not come on when the key is turned to “ ” (on), have a Yamaha dealer check the electrical circuit. Seat belt indicator light “ ”...
  • Page 38 ● an hour meter (which shows the total time Odometer and tripmeter modes the engine has been running) a voltage display (which shows the battery ● voltage) a fuel meter ● a self-diagnosis device ● 1. “SELECT” button 2. “RESET” button 3.
  • Page 39 To reset a tripmeter, select it by pushing the Clock, hour meter and voltage display “SELECT” button, and then push the “RE- modes SET” button for at least three seconds. The tripmeters can be used to estimate the dis- tance that can be traveled with a full tank of fu- el.
  • Page 40 To set the clock Voltage display mode 1. Set the display to the clock mode. 2. Push the “SELECT” button and “RESET” button together for at least three sec- onds. 3. When the hour digits start flashing, push the “RESET” button to set the hours. 4.
  • Page 41 If the voltage display indicates “LO” or “HI”, there may be trouble with the battery charging circuit or the battery may be faulty. If this occurs, have a Yamaha dealer check or repair the vehicle. 1. Fuel level warning indicator 2.
  • Page 42 If a problem is detected in an elec- trical circuit, all the display segments and fuel level warning indicator start flashing. If this oc- curs, have a Yamaha dealer check the electri- cal circuit. 1. Error code display 2.

  • Page 43: Light Switch

    EVU00240 Light switch “ ” NOTICE If the multi-function display indicates an error code, the vehicle should be checked as soon as possible in order to avoid en- gine damage. 1. Light switch “ ” Set the switch to “ ”...
  • Page 44 EVU01183 On-Command drive knob “2WD/4WD/ NOTICE DIFF LOCK” Do not use the headlights with the engine turned off for an extended period of time. The battery may discharge to the point that the starter motor will not operate properly. If this should happen, remove the battery and recharge it.

  • Page 45: Horn Switch

    ● “4WD” (four-wheel drive): Power is sup- Horn switch “ ” plied to the rear and front wheels. Press the switch to sound the horn. “DIFF LOCK” (four-wheel drive with the dif- ● ferential gear locked): Power is supplied to the rear and front wheels with the differen- tial gear locked.

  • Page 46: Accelerator Pedal

    EVU00260 EVU00270 Accelerator pedal Brake pedal Press the accelerator pedal down to increase Press the brake pedal to slow or stop the ve- engine speed. Spring tension returns the ped- hicle. al to the rest position when released. Always check that the accelerator pedal returns nor- mally before starting the engine.

  • Page 47: Parking Brake Lever

    EVU00280 EVU00290 Parking brake lever Drive select lever The parking brake lever is located at the right The drive select lever is used to shift the vehi- side of the steering wheel. Setting the parking cle into the low, high, neutral, and reverse po- brake lever will help keep the vehicle from sitions.

  • Page 48: Fuel Tank Cap

    EVU00300 Fuel tank cap Doors To open a door, pull the latch outward. To close a door, push or pull the door inward until it is securely latched. Be sure the door is SE- CURELY LATCHED AFTER CLOSING IT. 1. Fuel tank cap To open Remove the fuel tank cap by turning it coun- terclockwise.

  • Page 49: Seats

    EVU00330 Seats To install a seat cushion, insert the projections To remove a seat cushion, lift the front of the on the rear of the seat cushion under the seat cushion, and then pull the cushion off. frame, and then insert the projection on the front of the cushion into the grommet while pushing the cushion downward.

  • Page 50: Adjusting The Driver Seat Position

    Adjusting the driver seat position 2. Remove the bolts. The driver seat can be adjusted to one of three positions to suit the driver’s preference. 1. Bolt (× 4) Adjust the driver seat position as follows. 1. Remove the driver seat cushion. (see the previous section “Seats”.) 4-19...

  • Page 51: Seat Belts

    EVU00340 3. Move the seat frame to the desired posi- Seat belts tion and align the bolt holes in the seat This vehicle is equipped with three-point seat frame with the bolt holes in the vehicle belts for the operator and passengers. Always frame.

  • Page 52: Glove Compartment

    EVU01191 Glove compartment Storage compartments The storage compartments are located under NOTICE the multi-function meter and under the right To protect from damage, do not put metal passenger seat. items, like tools, or sharply edged items, NOTICE directly in the glove compartment. If they must be stored, wrap them in appropriate To protect from damage, do not put metal cushioning material.

  • Page 53: Cup Holders

    5B410005 Cup holders Be sure to tightly close the cap of any plastic bottle before placing it in a cup holder. Some plastic bottles may not fit into the cup holders depending on their size and shape. WARNING Never ride with any open or glass con- ●...

  • Page 54: Cargo Bed

    EVU00351 Cargo bed WARNING Never carry passengers in the cargo ● bed. ● Do not exceed the specified maximum load limits. Heavier cargo could cause loss of control because of improper weight balance. 1. Cup holder (× 4) 1. Tailgate 2.
  • Page 55 To close Maximum load limit: 272 kg (600 lb) Lift the tailgate to the original position, and then hook the latches. For additional loading information, see page 6-8. NOTICE The tailgate is not designed to hold heavy Opening and closing the tailgate loads when open.
  • Page 56 Lifting and lowering the cargo bed To lower With hands and fingers clear of pinch points, lower the cargo bed slowly to its original posi- tion and be sure it is locked into place. WARNING! Keep hands, body, and other people away from pinch points when low- ering bed.

  • Page 57: The Front And Rear Shock Absorber Assemblies

    Do not dispose of a damaged or worn assemblies out shock absorber assembly your- self. Take the shock absorber assem- WARNING bly to a Yamaha dealer for any These shock absorber assemblies contain service. highly pressurized nitrogen gas. Read and understand the following information be- fore handling the shock absorber assem- blies.

  • Page 58: Trailer Hitch Bracket And Receiver

    Trailer towing equipment multi-function meter. The auxiliary DC jack can be obtained at a Yamaha dealer. (See can be used for suitable work lights, radios, page 6-8 for precaution information.) etc.
  • Page 59 4. Open the auxiliary DC jack cap, and then NOTICE insert the accessory power plug into the Do not use accessories requiring ● jack. more than the maximum capacity stat- ed above. This may overload the cir- cuit and cause the fuse to blow. ●...

  • Page 60: For Your Safety - Pre-Operation Checks

    Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have the vehicle inspect- ed by a Yamaha dealer. Before using this vehicle, check the following points:...
  • Page 61 ITEM ROUTINE PAGE Final gear oil/ • Check for leakage. 5-7, 8-15, 8-17 Differential gear oil Accelerator pedal • Check for proper accelerator pedal operation. Seat belts • Check for proper operation and belt wear. Passenger handhold • Check for stability and proper fastening. 5-8, 7-9 Steering •...

  • Page 62: Front And Rear Brakes

    Check that there is no free play in the brake ply the brakes firmly for one minute. If there is pedal. If there is free play, have a Yamaha any leakage, have the vehicle inspected by a dealer check the brake system. (See page Yamaha dealer.

  • Page 63: Fuel

    Your Yamaha engine has been designed to lights of water heaters and clothes dry- use regular unleaded gasoline with a re- ers.
  • Page 64 Recommended fuel: If you carry a portable fuel container in the bed Regular unleaded gasoline only of your Yamaha Viking, be sure to secure it For Europe: with the cap tightened before driving the vehi- Regular unleaded gasoline only with a re- cle.

  • Page 65: Engine Oil

    EVU00410 EVU00420 Engine oil Coolant Make sure the engine oil is at the specified Check the coolant level in the coolant reser- level. Add oil as necessary. (See page 8-9.) voir when the engine is cold (the coolant level will vary with engine temperature). NOTICE In order to prevent clutch slippage ●...

  • Page 66: Final Gear Oil

    Add oil as necessary. (See page 8-15 ates correctly. It must operate smoothly and for details.) spring back to the idle position fully when re- leased. Have a Yamaha dealer repair as nec- Recommended oil: essary for proper operation. SAE 80 API GL-4 Hypoid gear oil...

  • Page 67: Passenger Handhold

    Take the vehicle resulting in serious injury or death in a crash. to a Yamaha dealer or refer to the Service To help make sure your restraint systems are Manual for correct tightening torque.
  • Page 68 EVU00510 Recommended tire pressure: Tire pressure Vehicle load: Use the tire pressure gauges to check and ad- 0 – 300 kg (0 – 661 lb) just tire pressures when the tires are cold. Tire Front: pressures must be equal on both sides. 75 kPa (0.75 kgf/cm , 11 psi) WARNING! Operation of this vehicle with...
  • Page 69 Minimum tire pressure: Two tire pressure gauges are included as Vehicle load: standard equipment. Use the lower range tire 0 – 300 kg (0 – 661 lb) pressure gauge for the front wheels and the Front: higher range tire pressure gauge for the rear 70 kPa (0.70 kgf/cm , 10 psi) wheels.
  • Page 70 EVU00520 Tire wear limit When the tire groove decreases to 3 mm (0.12 in) due to wear, replace the tire. a. Tire wear limit 5-11...

  • Page 71: Operation

    If there is a and 20 hours. control or function you do not understand, ask your Yamaha dealer. For this reason, we ask that you read the fol- lowing material carefully. Because the engine WARNING...

  • Page 72: Starting The Engine

    The coolant temperature warning light and build-up of heat. If any abnormality is noticed engine trouble warning light should come during this period, consult a Yamaha dealer. on, then go off. The EPS warning light should come on, 0–10 hours: then go off when the engine is started.
  • Page 73 ● The engine can be started in any gear For maximum engine life, never accelerate if the brake pedal is applied. However, it is recommended to shift into neutral hard when the engine is cold! before starting the engine. 4. With your foot off the accelerator pedal, start the engine by turning the key to “...

  • Page 74: Drive Select Lever Operation And Reverse Driving

    Drive select lever operation and 2. Apply the brake pedal, then shift by mov- reverse driving ing the drive select lever along the shift guide. Make sure that the drive select le- NOTICE ver is completely shifted into position. Do not shift without coming to a complete stop and waiting for the engine to return to normal idle speed.
  • Page 75 When in reverse, the reverse indicator pedal. light should be on. If the light does not 6. Press the accelerator pedal gradually come on, ask a Yamaha dealer to in- and continue to watch to the rear while spect the reverse indicator light elec- backing.

  • Page 76: On-Command Drive Knob

    5B410009 On-Command drive knob The vehicle handles differently in each of the drive modes (“2WD”, “4WD” and “DIFF LOCK”). For example, the vehicle requires more effort to turn in “DIFF LOCK” than in “2WD”. Always stop the vehicle before changing the position of the On-Command drive knob. The meter display changes according to the selected drive mode.
  • Page 77 ● When the knob is set to “DIFF LOCK” or “4WD”, the differential gear lock indicator and indi- cator light will flash until the differential gear is completely locked or unlocked. When the indicator and indicator light are flashing, turning the steering wheel back and forth ●...

  • Page 78: Parking

    EVU01210 EVU00630 Parking Loading When parking, stop the engine and shift the Take extra precautions when driving with a drive select lever into the neutral position. Ap- load or trailer. Follow these instructions and ply the parking brake to help prevent the vehi- always use common sense and good judg- cle from rolling.
  • Page 79 Prepare your load or trailer ● Tie down cargo in the trailer securely. Make sure cargo in the trailer cannot WARNING move around. A shifting load can Improper loading or towing can increase cause an accident. the risk of loss of control, an overturn, or Use the hooks equipped on the cargo bed to other accident: tie down loads.
  • Page 80 You can measure tongue weight with a bath- Operating when loaded with cargo or tow- room scale. Put the tongue of the loaded trail- ing a trailer er on the scale with the tongue at hitch height. Drive more slowly than you would without a Adjust the load in the trailer, if necessary, to load.
  • Page 81 Pulling something other than a trailer Yamaha recommends that loads be transport- ed in the bed or in a trailer. If you need to move an object a short distance use a winch and follow the winch manufacturer’s instruc- tions.

  • Page 82: Basic Guide For Safe Use

    5B410010 BASIC GUIDE FOR SAFE KNOW YOUR VEHICLE This off-road vehicle will handle and maneu- ver differently from cars, ATVs, go-carts, golf- As a Viking owner you are responsible for the cars and grounds-keeping vehicles. The safe and proper operation of this vehicle. Viking has higher ground clearance and other Read this chapter and review the safety in- features to handle rugged terrain, and, as a...
  • Page 83 Doing things with a Viking that some people do for thrills in other vehicles (such as side- ways sliding, skidding, back-wheel sliding, or donuts) have led to side rollovers. These roll- overs can result in crushed limbs and other serious injuries or death to drivers or passen- gers.

  • Page 84: Driver Requirements

    Driver requirements Parents: ● This vehicle is intended for use only by an Many countries have implemented new motor operator 16 or older with a valid motor vehi- vehicle licensing requirements for young driv- cle license. Check country laws for mini- ers.

  • Page 85: Passenger Requirements

    Passenger requirements Occupant protection system This vehicle is designed for the operator and WARNING two passengers. Allowing passengers to ride Do not make changes to the occupant pro- improperly can lead to serious injury or death. tection system. If you install aftermarket As the operator, you are responsible for your products or have your vehicle modified, passengers.

  • Page 86: Protective Structure

    Protective structure The vehicle cage/frame provides a protective structure that helps limit intrusions by branch- es or other objects and may reduce your risk of injury in accidents. The protective structure will not protect occupants in all rollovers or ac- cidents.

  • Page 87: Seat Belts

    Seat belts An unbelted occupant may strike the interior Seat belts should be worn by the driver and of the vehicle, the protective structure, or oth- passengers. The driver must be sure that the er objects in an accident or during operation. passengers are belted before driving.
  • Page 88 2. If the latch plate is not positioned in the correct location along the seat belt, squeeze the latch plate ends together along its long edges in order to more eas- ily adjust its location up or down along the length of the belt.
  • Page 89 6. Check if the seat belt shoulder position suits the size of the driver and passen- gers. To lower the belt, insert the belt into the seat belt height adjuster slot as shown. To raise the belt, remove the belt from the height adjuster slot.

  • Page 90: Doors

    Doors Passenger handhold The doors are designed to reduce the likeli- The passenger handhold is provided to grip hood that you will stick your leg out to stop the during operation to maintain proper position vehicle from tipping over or for any other rea- and balance.
  • Page 91 Adjusting the handhold position 1. Remove the locking pins. The handhold can be adjusted to one of three positions to suit the passengers’ preference. 1. Passenger handhold 2. Locking pin (× 2) Adjust the handhold position as follows. 7-10...
  • Page 92 2. Slide the handhold to the desired position and align the holes in the handhold bar with the holes in the handhold supports. 1. Wire loop 1. Handhold bar 2. Handhold support 3. Insert the pins into the holes and secure them with the wire loops.

  • Page 93: Seat And Shoulder Bolsters

    Seat and shoulder bolsters Floorboard The seats and shoulder bolsters are designed The floorboard allows you to brace your feet, to help keep you in the vehicle. Do not put which helps you keep your body in the vehicle your hand or arm on or outside of the shoulder in the event of an accident or rollover.

  • Page 94: Steering Wheel

    Steering wheel CORRECT GRIP EXAMPLE Keep both hands on the steering wheel. Do not hold the steering wheel with your thumbs inside the rim. Keep your palms on the out- side of the steering wheel. Similar to other off- road vehicles, if the Viking hits a deep rut or large obstacle, the steering wheel could brief- ly jerk in one direction or back and forth as the tires and vehicle respond to the obstacle.

  • Page 95: Learning To Operate Your Vehicle

    LEARNING TO OPERATE YOUR The driver and passengers should wear the VEHICLE following to reduce risk of injury in an acci- dent: Personal protective equipment Approved motorcycle helmet that fits prop- ● erly Eye protection (goggles, helmet face ● shield, or protective eyewear) ●...

  • Page 96: Practice For New Yamaha Viking Users

    Practice for new Yamaha Viking users You should become familiar with the perfor- mance characteristics of the vehicle in a large,...

  • Page 97: Getting Ready To Ride

    Getting ready to ride Turning Perform the Pre-Operation Checks on page Use care in turns – turning the steering wheel 5-1. Follow the instructions starting on page too far or too fast can result in loss of control 6-2 to start the engine. or a rollover.

  • Page 98: Accelerating

    If you think or feel that the vehicle may tip or Accelerating roll, keep your body completely inside the pro- With the engine idling in neutral and your foot tective structure of the vehicle: on the brake, shift the drive select lever into Brace yourself by pressing your feet firmly low or high.

  • Page 99: Braking

    Braking Engine braking When slowing down or stopping, take your Engine compression braking is designed to foot off the accelerator pedal and press the assist you when operating your Viking off- brake pedal smoothly. Improper use of the road. With this feature, the engine helps slow brakes can cause the tires to lose traction, re- the vehicle down after you take your foot off ducing control of the vehicle and increasing...

  • Page 100: Leaving The Vehicle

    Leaving the vehicle Parking on a flat area Do not get out of the vehicle while the engine When parking on a flat area, stop the engine is running and the drive select lever is in any and shift the drive select lever into the neutral gear.

  • Page 101: Loading

    See “Loading” on page 6-8. the vehicle. Your Yamaha Viking has higher ground clear- ance and other features to handle rugged ter- rain, and as a result, can overturn in situations where some vehicles may not. Abrupt maneu- vers or aggressive driving can cause loss of control, including rollovers –...

  • Page 102: Hills

    Hills Choose carefully which hills you attempt to climb or descend. Avoid hills with slippery sur- faces or those where you will not be able to see far enough ahead of you. Use common sense and remember that some hills are too steep for you to climb or descend.

  • Page 103: Uphill

    Uphill Slow down when you reach the crest of the hill Do not attempt to climb hills until you have if you cannot see clearly what is on the other mastered basic maneuvers on flat ground. side – there could be another person, an ob- Drive straight up hills, and avoid crossing the stacle, or a sharp drop-off.

  • Page 104: Downhill

    Downhill If you are sliding or skidding, try to steer in the Check the terrain carefully before going direction the vehicle is sliding, to regain con- downhill. When possible, choose a path that trol. For example, if you feel the back of the lets you drive your vehicle straight downhill.

  • Page 105: Rough Terrain

    Rough terrain Water Operation over rough terrain should be done If you must cross shallow, slow-moving water with caution. up to the depth of the vehicle’s floorboards, Look for and avoid obstacles that could choose your path carefully to avoid sharp ●...

  • Page 106: Loose Terrain/Slippery Terrain

    Loose terrain/slippery terrain NOTICE When driving on slippery terrain, including After driving your vehicle in water, be sure wet, muddy, or icy conditions, as well as loose to drain the trapped water by removing the gravel, be aware that you could begin skid- check hoses at the bottom of the air filter ding or sliding.

  • Page 107: Brush Or Wooded Areas

    Brush or wooded areas Encountering obstacles When operating in areas with brush or trees, If you cannot go around an obstacle, such as watch carefully on both sides and above the a fallen tree or a ditch, stop the vehicle where vehicle for obstacles such as branches that it is safe to do so.

  • Page 108: Periodic Maintenance And Adjustment

    WARNING hicle. If you are not familiar with vehicle Brake discs, calipers, drums, and linings service, have a Yamaha dealer perform can become very hot during use. To avoid service. possible burns, let brake components cool...

  • Page 109: Owner's Manual And Tool Kit

    EVU00660 Owner’s manual and tool kit You are recommended to put this owner’s manual in the vinyl bag and always carry it in the glove compartment as shown. Put the owner’s tool kit and tire pressure gauges un- der the right passenger seat. 1.
  • Page 110 If you do not have a torque wrench available during a service operation requiring one, take your vehicle to a Yamaha dealer to check the torque settings and adjust them as necessary.

  • Page 111: Periodic Maintenance Chart For The Emission Control System

    However, keep in mind that if the vehicle isn’t used for a long period of time, the month maintenance intervals should still be followed. ● Items marked with an asterisk should be performed by a Yamaha dealer as they require spe- cial tools, data and technical skills. INITIAL...

  • Page 112: General Maintenance And Lubrication Chart

    EVU01650 General maintenance and lubrication chart INITIAL EVERY month Whichever ITEM ROUTINE comes first 1200 2400 2400 4800 (mi) (200) (750) (1500) (1500) (3000) hours • Check coolant leakage. Cooling system* • Repair if necessary. • Replace coolant every 24 months. •...
  • Page 113 INITIAL EVERY month Whichever ITEM ROUTINE comes first 1200 2400 2400 4800 (mi) (200) (750) (1500) (1500) (3000) hours Rear upper and lower • Lubricate with lithium-soap-based grease. knuckle pivots* Drive shaft universal joint* • Lubricate with lithium-soap-based grease. • Check for cracks or damage. Engine mount* •...

  • Page 114: Hood

    EVU00680 Hood 2. Remove the hood. To remove 1. Pull the tab on each hood lock up, and then turn the hood locks 1/4 turn clock- wise. 1. Hood 1. Tab 2. Hood lock (× 2)
  • Page 115 To install NOTICE 1. Insert the projections on the hood into the Do not drive the vehicle with the hood slots in the front grill, and then place the open, unlatched, or removed. hood in the original position. 2. Turn the hood locks 1/4 turn counter- clockwise, and then push the tab on each hood lock down so that it is pointing rear- ward.

  • Page 116: Engine Oil And Oil Filter Cartridge

    5B410012 Engine oil and oil filter cartridge Check engine oil level before each operation. In addition, change the oil and the oil filter car- tridge at the intervals specified in the periodic maintenance and lubrication chart. To check the engine oil level 1.
  • Page 117 5. Insert the dipstick completely into the oil 6. If the engine oil is at or below the mini- filler hole, and then remove it again to mum level mark, remove the right rear check the oil level. panel by removing the quick fastener screws and bolts, and then add sufficient oil of the recommended type to raise it to The engine oil should be between the mini-...
  • Page 118 To change the engine oil (with or without oil filter cartridge replacement) 1. Park the vehicle on a level surface. 2. Lift the cargo bed up. (See page 4-25 for cargo bed lifting and lowering proce- dures.) 3. Start the engine, warm it up for several minutes, and then turn it off.
  • Page 119 If the O-ring remains attached to the crankcase, oil leakage may occur. An oil filter wrench is available from a Yamaha dealer. 1. O-ring 8. Install the new oil filter cartridge with an oil filter wrench, and then tighten it to the specified torque with a torque wrench.
  • Page 120 1. Torque wrench 1. Right rear panel 2. Quick fastener screw (× 4) 3. Bolt (× 2) 9. Install the engine oil drain bolt and its 11. Refill with the specified amount of recom- new gasket, and then tighten the bolt to mended engine oil, and then insert the the specified torque.
  • Page 121 13. Turn the engine off, wait at least 10 min- Be sure to wipe off spilled oil on any parts af- utes, and then check the oil level and cor- ter the engine and exhaust system have rect it if necessary. cooled down.

  • Page 122: Final Gear Oil

    5B410013 Final gear oil 3. If the oil is below the brim of the filler hole, add sufficient oil of the recommended Checking the final gear oil level type to raise it to the correct level. 1. Park the vehicle on a level surface. NOTICE: Be sure no foreign material 2.
  • Page 123 Changing the final gear oil Tightening torque: 1. Park the vehicle on a level surface. Final gear oil drain bolt: 2. Place an oil pan under the final gear case 22 Nm (2.2 m·kgf, 16 ft·lbf) to collect the used oil. 3.

  • Page 124: Differential Gear Oil

    5B410014 Differential gear oil Tightening torque: Final gear oil filler bolt: Checking the differential gear oil level 23 Nm (2.3 m·kgf, 17 ft·lbf) 1. Park the vehicle on a level surface. 2. Remove the differential gear oil filler bolt 8. Check for oil leakage. If oil leakage is and its gasket, and then check the oil lev- found, check for the cause.
  • Page 125 Changing the differential gear oil 1. Park the vehicle on a level surface. 2. Place an oil pan under the differential gear case to collect the used oil. 3. Remove the differential gear oil filler bolt, the differential gear oil drain bolt and their gasket to drain the oil.
  • Page 126 4. Install the differential gear oil drain bolt 7. Install the differential gear oil filler bolt and its new gasket, and then tighten the and its gasket, and then tighten the bolt bolt to the specified torque. to the specified torque. Tightening torque: Tightening torque: Differential gear oil drain bolt:...

  • Page 127: Coolant

    5B410015 Coolant The coolant level should be checked before each ride. Checking the coolant level 1. Park the vehicle on a level surface. 2. Check the coolant level in the coolant reservoir when the engine is cold as the coolant level varies with engine tempera- ture.

  • Page 128: Axle Boots

    EVU00740 Changing the coolant Axle boots The coolant must be changed by a Yamaha Check the axle boots for holes or tears. dealer at the intervals specified in the periodic If any damage is found, have them replaced maintenance and lubrication chart.

  • Page 129: Spark Plug Inspection

    EVU00750 Spark plug inspection Removal 1. Lift the cargo bed up. (See page 4-25 for cargo bed lifting and lowering proce- dures.) 2. Remove the spark plug cap. 1. Rear axle boot (× 2 each side) 1. Spark plug cap 3.
  • Page 130 Inspection The spark plug is an important engine compo- nent and is easy to inspect. The condition of the spark plug can indicate the condition of the engine. The ideal color of the porcelain insulator around the center electrode is a medium-to- light tan for a vehicle that is being ridden nor- mally.
  • Page 131 Measure the spark plug gap with a wire thick- Installation ness gauge and, if necessary, adjust the gap 1. Clean the surface of the spark plug gas- to specification. ket and its mating surface, and then wipe off any grime from the spark plug threads.

  • Page 132: Cleaning The Air Filter Element

    5B410016 Cleaning the air filter element There is a check hose at the bottom of the air filter case and under the center passenger seat. If dust or water collects in a check hose, empty the hose and clean the air filter element and air filter case.
  • Page 133 1. Remove the center passenger seat cush- 3. Remove the air filter element. ion. (See page 4-18 for seat cushion re- moval and installation procedures.) 2. Remove the air filter case cover by un- hooking the holders. 1. Air filter element 1.
  • Page 134 4. While pushing the projections on the air 5. Remove the sponge material from the air filter frame inward, remove the air filter el- filter frame. ement holder. 1. Air filter element holder 2. Sponge material 3. Air filter frame 1.
  • Page 135 NOTICE: Do not twist replace it if damaged. the sponge material when squeezing 11. Thoroughly apply Yamaha foam air filter oil or other quality liquid foam air filter oil (not spray type) to the sponge material. The sponge material should be wet but not dripping.
  • Page 136 15. Fit the holders on the air filter case cover The air filter element should be cleaned every onto the projections on the air filter case, 20–40 hours. It should be cleaned and lubri- and then install the air filter case cover by cated more often if the vehicle is operated in hooking the holders onto the cover.

  • Page 137: V-Belt Case Drain Plug

    If water drains from the V-belt case after re- haust system. moving the drain plug, have a Yamaha dealer inspect the vehicle, as the water may affect 1. Remove the tailpipe bolts.

  • Page 138: Valve Clearance

    To prevent this, the valve clear- ance must be adjusted regularly. This adjust- ment however, should be left to a professional Yamaha service technician. 1. Gasket 2. Spark arrester 3. Tailpipe 4.

  • Page 139: Brakes

    To check the brake pad wear, check the wear indicator grooves. If a brake pad has worn to the point that the wear indica- tor grooves have almost disappeared, have a Yamaha dealer replace the brake pads as a set. 8-32...

  • Page 140: Checking The Parking Brake Pads

    If a brake pad has worn to the level. Replenish the brake fluid if necessary. point that the wear indicator groove has al- most disappeared, have a Yamaha dealer re- place the brake pads as a set. 1. Minimum level mark Specified brake fluid: DOT 4 1.

  • Page 141: Brake Fluid Replacement

    If the brake fluid Use only the specified brake fluid; ● level goes down suddenly, have a Yamaha otherwise, the rubber seals may dete- dealer check the cause before further riding. riorate, causing leakage.

  • Page 142: Checking The Brake Pedal

    EVU00870 Checking the brake pedal Parking brake lever free play adjustment Have a Yamaha dealer check the brakes at the intervals specified in the periodic mainte- Periodically check the parking brake lever free nance and lubrication chart. There should be play and adjust it if necessary.

  • Page 143: Brake Light Switch Adjustment

    EVU00880 3. Release the parking brake lever. Brake light switch adjustment 4. Slide the rubber cover back on the park- The brake light switch, which is activated by ing brake cable. the brake pedal, is properly adjusted when the 5. Loosen the locknut. brake light comes on just before braking takes effect.

  • Page 144: Cable Inspection And Lubrication

    Cables can also become frayed or kinked. Lubricate the cable ends. If the cables do not operate smoothly, ask a Yamaha dealer to re- place them. Recommended lubricant: Yamaha cable lubricant or other suitable...

  • Page 145: Checking The Stabilizer Bushes

    Lubricate the knuckle upper and lower pivots the periodic maintenance and lubrication with a grease gun. chart. Have a Yamaha dealer replace the stabilizer bushes if necessary. Recommended lubricant: Lithium-soap-based grease 8-38...

  • Page 146: Steering Shaft Lubrication

    EVU00920 EVU00930 Steering shaft lubrication Wheel removal Lubricate the pivot points. 1. Loosen the wheel nuts. 2. Elevate the vehicle and place a suitable Recommended lubricant: stand under the frame. Lithium-soap-based grease 3. Remove the nuts from the wheel. 4. Remove the wheel. 1.

  • Page 147: Tire Replacement

    Always use the same size and type of tires Yamaha Motor Manufacturing Corporation of recommended in this owner’s manual. The America for this model. tires that came with your Yamaha Viking were Front tire: designed to match the performance capabili- Size: ties and to provide the best combination of 25 ×...

  • Page 148: Wheel Installation

    Wheel installation WARNING 1. Install the wheel and the nuts. Do not reverse the rims on your Yamaha Viking to widen the track width. Installing Tapered nuts are used for both the front and wheels improperly increases the risk of rear wheels.

  • Page 149: Battery

    EVU00950 Battery WARNING The battery is located under the hood. (See Avoid battery contact with skin, eyes, or page 8-7 for hood removal and installation clothing. Shield eyes when working near procedures.) batteries. Keep out of reach of children. This model is equipped with a VRLA (Valve You could be poisoned or severely burned Regulated Lead Acid) battery.
  • Page 150 To remove the battery 5. Disconnect the negative battery lead first, 1. Turn the key to “ ” (off). then the positive battery lead by remov- 2. Remove the hood. (See page 8-7 for ing their bolt. NOTICE: When removing hood removal and installation proce- the battery, the main switch must be dures.)
  • Page 151 To charge the battery NOTICE Have a Yamaha dealer charge the battery as Always keep the battery charged. Storing soon as possible if it seems to have dis- a discharged battery can cause permanent charged. Keep in mind that the battery tends battery damage.
  • Page 152 To install the battery 3. Hook the battery bands. 4. Install the air intake duct panel by install- ing the quick fastener screws. Be sure the battery is fully charged. 5. Install the hood. 1. Place the battery in its compartment. 2.

  • Page 153: Jump-Starting

    5B410022 Jump-starting However, if the vehicle must be jump-started, Jump-starting the vehicle should be avoided. proceed as follows. The battery should be removed and charged 1. Turn the key to “ ” (off). instead. 2. Remove the hood. (See page 8-7 for hood removal and installation proce- WARNING dures.)
  • Page 154 1. Jumper cable positive lead 1. Jumper cable negative lead 4. Connect the negative lead of the jumper 5. Start the engine. (Refer to “Starting the cable to the negative terminal of the engine” on page 6-2.) charged battery and the other end of the 6.

  • Page 155: Fuse Replacement

    5B410023 Fuse replacement The main fuse, the fuel injection system fuse, the EPS fuse, and the fuse box are located under the hood. 1 2 3 4 5 6 1. Backup fuse “BACK UP” (for clock) 2. Ignition fuse “IGNITION” 3.
  • Page 156 If the fuse blows again may lead to a fire. immediately, have a Yamaha dealer check the electrical system. 5. Install the hood. 8-49...

  • Page 157: Replacing A Headlight Bulb

    EVU01670 Replacing a headlight bulb 2. Remove the headlight bulb cover by pull- If a headlight bulb burns out, replace it as fol- ing it off. lows. 1. Remove the cover at the rear of the headlight by pulling it off. 1.
  • Page 158 3. Disconnect the headlight coupler. 4. Unhook the headlight bulb holder. 1. Headlight coupler 1. Headlight bulb holder 8-51...
  • Page 159 5. Wait for the headlight bulb to cool before touching or removing it. Remove the burnt-out bulb by pulling it out. 6. Place a new headlight bulb into position, and then secure it with the bulb holder. NOTICE: Do not touch the glass part of the headlight bulb to keep it free from oil, otherwise the transparency of the glass, the luminosity of the...

  • Page 160: Headlight Beam Adjustment

    If a tail/brake light bulb burns out, replace it as NOTICE follows: It is advisable to have a Yamaha dealer 1. Remove panel A (if replacing the left tail/ make this adjustment. brake light bulb) or panel B (if replacing...
  • Page 161 2. Remove the tail/brake light bulb holder (together with the bulb) by turning it coun- terclockwise. 1. Panel B 1. Tail/brake light bulb holder 3. Push the burnt-out bulb in and turn it counterclockwise to remove it from the bulb holder. 4.

  • Page 162: Troubleshooting

    7 Nm (0.7 m·kgf, 5.1 ft·lbf) troubleshooting chart describes a quick, easy procedure for making checks. If your vehicle requires any repair, take it to a Yamaha deal- The skilled technicians at a Yamaha dealer- ship have the tools, experience, and know- how to properly service your vehicle.
  • Page 163 WARNING When checking the fuel system, do not smoke and make sure there are no open flames or sparks in the area, including pi- lot lights from water heaters or furnaces. Gasoline or gasoline vapors can ignite or explode, causing severe injury or property damage.

  • Page 164: Troubleshooting Charts

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 165 Restart the engine. If the engine overheats again, ask a Level is OK. Yamaha dealer to inspect and/or repair the cooling system. If it is difficult to get the recommended coolant, tap water can be used temporarily, provided that it is changed to the recommended coolant as soon as possible.

  • Page 166: Cleaning And Storage

    EVU01030 C LEANING AND STORAGE 3. Rinse the dirt and degreaser off with a garden hose. Use only enough pressure Cleaning to do the job. WARNING! Test the Frequent, thorough cleaning of your vehicle brakes after washing. Apply the will not only enhance its appearance but will brakes several times at slow speeds improve its general performance and extend to let friction dry out the linings.

  • Page 167: Storage

    1. Fill the fuel tank with fresh fuel and add 6. Clean the seats with a vinyl upholstery the specified amount of Yamaha Fuel cleaner to keep the covers pliable and Stabilizer and Conditioner or equivalent glossy.
  • Page 168 4. Block up the frame to raise all wheels off nates the need to drain the fuel system. Con- the ground. sult a Yamaha dealer if the fuel system needs 5. Tie a plastic bag over the exhaust pipe to be drained.

  • Page 169: Specifications

    EBU25960 S PECIFICATIONS Dimensions: Vibration on seat (EN1032, ISO5008): YXM700PE Will not exceed 0.5 m/s² (EUR)(FRA)(GBR) Overall length: YXM700PHE Will not exceed 0.5 m/s² 3100 mm (122.0 in) Vibration on handle (EN1032, ISO5008): Overall width: YXM700PE Will not exceed 2.5 m/s² (EUR)(FRA)(GBR) 1570 mm (61.8 in) YXM700PHE Will not exceed 2.5 m/s²...
  • Page 170 Engine oil: Differential gear oil: Recommended brand: Type: YAMALUBE SAE 80 API GL-4 Hypoid gear oil Type: Quantity: SAE 5W-30, 10W-30, 10W-40, 15W-40, 20W-40 or 20W- 0.18 L (0.19 US qt, 0.16 Imp.qt) Cooling system: Coolant reservoir capacity (up to the maximum level mark): 130 ˚F 0.28 L (0.30 US qt, 0.25 Imp.qt) Radiator capacity (including all routes):...
  • Page 171 Transmission: Rear tire: Primary reduction system: Type: V-belt Tubeless Secondary reduction system: Size: 25 × 10-12NHS Shaft drive Secondary reduction ratio: Manufacturer/model: 41/21 × 17/12 × 33/9 (10.142) MAXXIS/MU10 Loading: Transmission type: V-belt automatic Maximum loading limit: Operation: 445 kg (981 lb) Right hand operation (Total weight of rider, passengers, cargo, accessories, Reverse gear:...
  • Page 172 Front suspension: Vehicle load: 300 kg - maximum (661 lb - maximum): Type: Front: Double wishbone 70.0 kPa (0.700 kgf/cm , 10 psi) Spring/shock absorber type: Rear: Coil spring/gas-oil damper 120.0 kPa (1.200 kgf/cm , 17 psi) Wheel travel: Front wheel: 205 mm (8.1 in) Rear suspension: Wheel type:...
  • Page 173 Neutral indicator light: Signaling system fuse: 10.0 A Reverse indicator light: Ignition fuse: 10.0 A Coolant temperature warning light: Auxiliary DC jack fuse: 10.0 A Engine trouble warning light: Backup fuse: 10.0 A Parking brake indicator light: Four-wheel-drive motor fuse: 10.0 A On-Command four-wheel-drive/differential gear lock indica- Radiator fan fuse:...
  • Page 174 from country. This information, however, will enable the user of the machine to make a bet- ter evaluation of the hazard and risk. 10-6...

  • Page 175: Consumer Information

    The vehicle identification number is stamped model label information in the spaces provid- into the frame. ed for assistance when ordering spare parts from a Yamaha dealer or for reference, in case the vehicle is stolen. 1. VEHICLE IDENTIFICATION NUMBER: ACA-02E 2.
  • Page 176 Model label The model label is affixed to the frame under the driver seat. Record the information on this label in the space provided. This information will be needed to order spare parts from your Yamaha dealer. 1. Model label 11-2...
  • Page 178 Original instructions PRINTED IN USA 2013.06-0.3×1 CR...

This manual is also suitable for:

Viking yxm700phe

Table of Contents
