READ THIS MANUAL CAREFULLY!
It contains important safety information.
OWNER'S MANUAL
YXM70VPAN
YXM70VPHN
YXM70VPRN
LIT-11626-35-48
BHF-F8199-11

Advertisement

Table of Contents
loading

Related Manuals for Yamaha VIKING 2021

Summary of Contents for Yamaha VIKING 2021

  • Page 1 READ THIS MANUAL CAREFULLY! It contains important safety information. OWNER’S MANUAL YXM70VPAN YXM70VPHN YXM70VPRN LIT-11626-35-48 BHF-F8199-11...
  • Page 2 EBU31032 Operating, servicing and maintaining a passenger vehicle or off-road vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your...
  • Page 3 Congratulations on your purchase of the Yamaha YXM70VPAN / YXM70VPHN / YXM70VPRN. It represents the result of many years of Yamaha experience in the production of fine sporting, touring, and pace-setting racing vehicles. With the purchase of this Yamaha, you can now ap- preciate the high degree of craftsmanship and reliability that have made Yamaha a leader in these fields.
  • Page 4 EBU31080 IMPORTANT MANUAL INFORMATION EBU31070 FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SERI- OUS INJURY OR DEATH. Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to poten- tial personal injury hazards.
  • Page 5  This vehicle complies with all state off-highway noise level and spark arrester laws and regulations. EBU31111 YXM70VPAN / YXM70VPHN / YXM70VPRN OWNER’S MANUAL ©2022 by Yamaha Motor Corporation, U.S.A. 1st edition, September 2021 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A.

  • Page 6: Table Of Contents

    Accelerator pedal ....... 5-12 EBU31120 CONTENTS Brake pedal ........5-13 Parking brake lever ......5-13 VEHICLE IDENTIFICATION ..... 1-1 Drive select lever ........ 5-14 Identification numbers......1-1 Fuel tank cap........5-14 Doors..........5-14 LOCATION OF THE WARNING AND Seats ..........5-15 SPECIFICATION LABELS .......
  • Page 7 Coolant ..........6-6 LEARNING TO OPERATE YOUR Final gear..........6-6 VEHICLE ...........8-12 Differential gear ........6-6 PERIODIC MAINTENANCE AND Accelerator pedal ......... 6-6 ADJUSTMENT .........9-1 Seat belts ..........6-6 Owner’s Manual........9-2 Passenger handhold ......6-7 Maintenance charts ......9-3 Steering ..........6-7 Hood .............9-9 Fittings and fasteners ......6-7 Engine oil and oil filter cartridge ..9-10...
  • Page 8 Rear knuckle upper and lower pivot NOISE REGULATION (for USA) ..12-2 lubrication (left and right)....9-39 MAINTENANCE RECORD ....12-3 Steering shaft lubrication ....9-40 YAMAHA MOTOR CORPORATION, Wheel removal........9-40 U.S.A. 2020 AND LATER MODEL Tire replacement ........ 9-41 SIDE-BY-SIDE LIMITED Wheel installation .......

  • Page 9: Vehicle Identification

    EBU38890 VEHICLE IDENTIFICATION EBU32781 EBU32800 Vehicle identification number Identification numbers The vehicle identification number is stamped Record the vehicle identification number, into the frame. model label information and key identification number in the spaces provided below. VEHICLE IDENTIFICATION NUMBER: MODEL LABEL INFORMATION: 1.
  • Page 10 * * * * - * * * 1. Model type code 2. Production code 1. Model label 3. Color code Your specific model can be identified by EBU32790 Key identification number checking the model type code found on the The key identification number is stamped on model label.
  • Page 11 1. Key identification number...

  • Page 12: Location Of The Warning And Specification Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 14 (70 kPa) REAR: 17 psi (120 kPa) YAMAHA MOTOR CORPORATION U.S.A. certifies this ROV * Vehicle load is weight of operator, passengers, complies with the American National Standard for Recreational accessories, cargo, and (if applicable) trailer tongue Off-Highway Vehicles, ANSI/ROHVA-1-2016 Standard.
  • Page 15 WARNING Improper use of cargo bed or cage/frame can result Never carry in severe injury or passengers death from loss of in cargo bed. control, overturn or other accidents. Maximum Load in Cargo Bed: 600 lbs (272 kg) Maximum Vehicle Load: 906 lbs (411 kg) •Load or trailer may affect handling and stability.
  • Page 16 US OSHA and ISO 3471 requirements for rollover protection structures Improperly loading a trailer m=700Kg for ISO3471 or pulling an object can YAMAHA MOTOR CORPORATION U.S.A. affect handling, stability, and 6555 Katella Avenue, Cypress, California 90630-5101, U.S.A. risk of overturn or other BHF-F4164-00 accidents.
  • Page 17 MAX 7.3 INCH (185MM) B4J-F151J-00 B H F - F 1 5 6 8 - 0 0...

  • Page 18: Safety Information

    EBU32934 Be a responsible owner As the vehicle’s owner, you are responsible for the safe and proper operation of your Yamaha Viking. While understanding all parts of this manual are important for vehicle ownership, be sure to read this chapter and the instructions in Chapter 8 before operating your Yamaha Viking. Also use these two chapters and the labels on the vehicle to instruct new operators and passengers.
  • Page 19 DRIVER UNDER • This vehicle is designed to carry the driver and two passengers. Never carry passengers in the cargo bed. • The driver and passengers should wear seat belts properly. • The driver and passengers must be able to put both feet flat on the floorboard while seated upright with their backs against the backrests.
  • Page 20  Secure cargo so that it will not shift – a loose load could change handling unexpectedly or be thrown forward and strike occupants. While using your Yamaha Viking  Keep your body completely inside the vehicle at all times. Keep both hands on the steering wheel.
  • Page 21  Abrupt maneuvers or aggressive driving, even on flat, open areas, can cause loss of control, including rollovers. The Viking has higher ground clearance and other features to handle rug- ged terrain, and, as a result, can overturn in situations where some other vehicles may not. ...
  • Page 22  If you think or feel that the vehicle may tip or roll, keep your body completely inside the protec- tive structure of the vehicle: • Brace yourself by pressing your feet firmly on the floorboard and keep a firm grip on the steering wheel or passenger handhold.
  • Page 23 Many companies with no connection to Yamaha manufacture parts and accessories or offer oth- er modifications for Yamaha vehicles. Yamaha is not in a position to test the products that these aftermarket companies produce. Therefore, Yamaha can neither endorse nor recommend the use of accessories not sold by Yamaha or modifications not specifically recommended by Yamaha, even if sold and installed by a Yamaha dealer.
  • Page 24 Aftermarket parts, accessories, and modifications While you may find aftermarket products similar in design and quality to genuine Yamaha Acces- sories, recognize that some aftermarket accessories or modifications are not suitable because of potential safety hazards to you or others. Installing aftermarket products or having other mod- ifications performed to your Viking that change any of the vehicle’s design or operation charac-...

  • Page 25: Description

    EBU31170 DESCRIPTION EBU31180 Left view 14 13 1. Front shock absorber 8. Brake/tail light 2. Radiator cap 9. Spark arrester 3. Brake fluid reservoir 10.Rear shock absorber 4. Driver seat 11.Spark plug 5. Shoulder bolster 12.Cargo bed release lever 6. Seat belt 13.Storage compartment (for YXM70VPRN) 7.

  • Page 26: Right View

    EBU31190 Right view 1. Engine oil dipstick 2. Seat belt 3. Passenger seat 4. Air filter 5. Battery 6. Fuses 7. Headlight 8. Coolant reservoir 9. Storage compartment 10.Fuel tank cap 11.Oil filter cartridge...

  • Page 27: Controls And Instruments

    EBU31200 Controls and instruments 5 6,7 1. Light switch 9. Accelerator pedal 2. On-Command drive knob 10.Brake pedal 3. Steering wheel 11.Multi-function meter unit 4. Main switch 12.Passenger handhold 5. Parking brake lever 13.Glove compartment 6. Helmet reminder light 14.Auxiliary DC jack 7.

  • Page 28: Instrument And Control Functions

    EBU3121D INSTRUMENT AND CONTROL The operation of the indicator and warning FUNCTIONS lights, and the multi-function meter can be EBU31221 confirmed at this time. Main switch EBU31241 Off position “ ” All electrical circuits are switched off. The key can be removed. EBU31251 Start position “...

  • Page 29: Indicator Lights And Warning Lights

    EBU31269 Indicator lights and warning lights 1. Helmet reminder light “ ” 2. Seat belt reminder light “ ” 1. Differential gear lock indicator light “DIFF. LOCK” EBU31270 2. Low-range indicator light “L” Low-range indicator light “L” 3. High-range indicator light “H” This indicator light comes on when the drive 4.
  • Page 30 EBU31290 Neutral indicator light “N” When the On–Command drive knob is set to This indicator light comes on when the drive “DIFF. LOCK”, the indicator light will flash un- select lever is in the “N” position. til the differential is locked. Turn the steering EBU31300 wheel back and forth or drive slowly to help Reverse indicator light “R”...
  • Page 31 If the light comes on display will indicate an error code (see page during operation, stop the vehicle as soon as 5-10). Have a Yamaha dealer check the self- it is safe to do so and allow the engine to cool diagnostic system.
  • Page 32 If the steering load is too heavy (e.g., exces- the reminder light remains on after the driver sive steering use at slow speed or when op- seat belt is properly latched, have a Yamaha erating in deep mud, sand, or snow), the dealer check the electrical circuit.

  • Page 33: Multi-Function Meter Unit

     hour meter EBU31389 Multi-function meter unit  voltage display  fuel gauge  error code display Speedometer The speedometer shows the vehicle’s travel- ing speed. The speedometer can be set to “mph” or “km/h”. This also changes the odometer and tripmeter units between miles and kilometers.
  • Page 34 Odometer and tripmeters Push the “SELECT” button to switch between the odometer “ODO” and the tripmeters “TRIP A” and “TRIP B” in the following order: ODO → TRIP A → TRIP B → ODO To reset a tripmeter, set the display to the tripmeter you want to reset, then push the “RESET”...
  • Page 35 Clock, hour meter and voltage display To set the clock 1. Set the display to the clock. 2. Push both the “SELECT” button and “RESET” button until the hour digits start flashing. 3. Use the “RESET” button to set the hours. 4.
  • Page 36 The display segments of the fuel charging circuit or the battery may be gauge disappear from “F” (full) towards “E” faulty. If this occurs, have a Yamaha dealer (empty) as the fuel level decreases. When the check or repair the vehicle.
  • Page 37 “ ” will flash repeatedly. Have a Yamaha If the display indicates an error code, note the dealer check the vehicle. code number and have a Yamaha dealer check the vehicle.

  • Page 38: Light Switch

    that the electric starter will not have EBU31391 Light switch “ ” enough power to crank the engine. If this should happen, remove the battery and re- charge it. EBU39121 On–Command drive knob “2WD/4WD/DIFF. LOCK” 1. Light switch “ ” Set the switch to “...

  • Page 39: Accelerator Pedal

    drive with differential lock. Select the appro- EBU31413 Accelerator pedal priate drive according to the terrain and driv- ing conditions.  “2WD” (two–wheel drive): Power is sup- plied to the rear wheels only.  “4WD” (four–wheel drive): Power is sup- plied to the front and rear wheels.

  • Page 40: Brake Pedal

    EBU31421 EBU35642 Brake pedal Parking brake lever 1. Brake pedal 1. Parking brake lever 2. Release button Press the brake pedal to slow or stop the ve- 3. Pull to set. hicle. Setting the parking brake lever will help keep the vehicle from moving while parked.

  • Page 41: Drive Select Lever

    EBU31451 Fuel tank cap  Spring tension helps return the lever to its original position.  If you drive the vehicle with the parking brake engaged, a buzzer will sound. EBU31441 Drive select lever 1. Fuel tank cap Remove the fuel tank cap when refueling. To open, turn counterclockwise.

  • Page 42: Seats

    1. Latch 1. Seat cushion 2. Door To install a seat cushion, insert the hooks on the rear of the seat cushion under the seat EBU31472 Seats frame, and then insert the projection on the Certain models have under-seat storage front of the cushion into the grommet by compartments.

  • Page 43: Adjusting The Driver Seat Position

    1. Remove the driver seat cushion. 2. Remove the bolts. EBU31481 Adjusting the driver seat position 1. Bolt The driver seat can be installed to one of three 3. Move the seat frame to the desired posi- positions. tion and align the bolt holes in the seat frame with the bolt holes in the vehicle frame.

  • Page 44: Seat Belts

    EBU36184 Seat belts 4. Install the bolts. 5. Tighten to the specified torque. Always wear the seat belts properly while rid- ing in the vehicle. (See page 8-5.) Tightening torque: Driver seat bolt: 23 N·m (2.3 kgf·m, 17 lb·ft)  If the vehicle is driven without the driver seat belt fastened, a buzzer will sound.

  • Page 45: Glove Compartment

    EBU31503 ECB02071 NOTICE Glove compartment To protect from damage, do not put metal items, like tools, or sharply edged items di- rectly in the glove compartment. If they must be stored, wrap them in appropriate cushioning material. EBU34763 Storage compartments There are storage compartments located in the dashboard, under the right passenger 1.
  • Page 46 ECB02241 NOTICE To protect from damage, do not put metal items, like tools, or sharply edged items di- rectly in the storage compartment. If these items must be stored, wrap them in appro- priate cushioning material. 1. Storage compartment Maximum load limit: Center console storage compartment: 5.0 kg (11 lb) Storage compartment under right passen-...

  • Page 47: Cup Holders

    never store fuel or flammable liquids in this A drain plug is fitted at the bottom of this stor- NOTICE: Do storage compartment. age compartment. If any water collects in the [EWB03230] not exceed the specified maximum load storage compartment, remove the drain plug, limit for this storage compartment.

  • Page 48: Cargo Bed

    EWB03240 WARNING  Never ride with any open or glass con- tainers in the cup holders; otherwise, the contents may spill and the glass contain- ers may be thrown about and break, and possibly injure people in the vehicle dur- ing sudden braking or an accident.
  • Page 49 Opening and closing the tailgate 1. Tailgate 2. Cargo hook 1. Tailgate 3. Cargo bed 2. Latch ECB02100 Maximum load limit: 272.0 kg (600 lb) NOTICE The tailgate is not designed to hold heavy For additional loading information, see page loads when open.

  • Page 50: The Front And Rear Shock Absorber Assemblies

    To close To lower Lift the tailgate to the original position, and With hands and fingers clear of pinch points, then hook the latches. lower the cargo bed slowly to its original po- sition and be sure it is locked into place. Lifting and lowering the cargo bed WARNING! Keep hands, body, and other people away from pinch points when low-...

  • Page 51: Trailer Hitch Bracket And Receiver

    2. Receiver This vehicle is equipped with a trailer hitch bracket and a 2" (5 cm) receiver for a stan- dard trailer hitch. Trailer towing equipment can be obtained at a Yamaha dealer. See page 7-8 for loading information. 5-24...

  • Page 52: Auxiliary Dc Jack

    3. Open the auxiliary DC jack cap. EBU32955 Auxiliary DC jack 4. Make sure the accessory is powered off. 5. Insert the accessory power plug. 6. Turn the accessory on.  Turn off the accessory before plugging in- to/unplugging from the jack. ...
  • Page 53  Do not use an automotive cigarette light- er or other accessories with a plug that gets hot, because the jack can be dam- aged. 5-26...

  • Page 54: For Your Safety - Pre-Operation Checks

    Failure to inspect or maintain the vehicle properly increases the possibility of an accident or equipment damage. Do not operate the vehicle if you find any problem. If a problem can- not be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Pre-operation checklist ITEM...
  • Page 55 ITEM ROUTINE PAGE • Check coolant level in reservoir. Coolant 6-6, 9-20 • Fill with coolant if necessary. Final gear oil/Differen- • Check for leakage. 6-6, 6-6, 9-16, 9-18 tial gear oil Accelerator pedal • Check free play and for proper operation. Seat belts •...

  • Page 56: Front And Rear Brakes

    Apply the brakes firmly for one minute. If there  Check that there is no free play in the brake is any leakage, have the vehicle inspected by pedal. If there is free play, have a Yamaha a Yamaha dealer. dealer check the brake system. (See page 9-36.)
  • Page 57 EWB02522 EWB02532 WARNING WARNING Gasoline and gasoline vapors are ex- Gasoline is poisonous and can cause inju- tremely flammable. To avoid fires and ex- ry or death. Handle gasoline with care. plosions and to reduce the risk of injury Never siphon gasoline by mouth. If you when refueling, follow these instructions.

  • Page 58: Engine Oil

    If you carry a portable fuel container in the  In order to prevent clutch slippage (since bed of your Yamaha Viking, be sure to secure the engine oil also lubricates the clutch), it with the cap tightened before driving the ve- do not mix any chemical additives.

  • Page 59: Coolant

    EBU36030 pushed firmly. Wash off any dirt or mud that Differential gear could affect operation. Have a Yamaha dealer Make sure there is no oil leaking from the dif- repair as necessary for proper operation. ferential gear case.

  • Page 60: Passenger Handhold

    Check tires for wear and damage. EBU31832 Fittings and fasteners Always check the tightness of chassis fittings and fasteners before starting off. Take the ve- hicle to a Yamaha dealer or refer to the Ser- vice Manual for correct tightening torque.
  • Page 61 Tire pressure injury or death from loss of control or roll- over. Tire pressure below the minimum specified could also cause the tire to dis- lodge from the rim under severe driving conditions. [EWB04120] 1. Tire pressure gauge Make two measurements of the tire pressure and use the second reading.
  • Page 62 Tire inspection OPERATING TIRE PRESSURE (cold): VEHICLE LOAD of 0.0–300.0 kg (0–661 lb) FRONT: (Recommended) 75.0 kPa (0.750 kgf/cm², 11 psi) REAR: (Recommended) 100.0 kPa (1.000 kgf/cm², 15 psi) Front: (Minimum) 70.0 kPa (0.700 kgf/cm², 10 psi) Rear: (Minimum) 95.0 kPa (0.950 kgf/cm², 14 psi) VEHICLE LOAD of 300.0–411.0 kg (661–...

  • Page 63: Operation

    If any abnormality is noticed EBU31891 during this period, consult a Yamaha dealer. Engine break-in There is never a more important period in the 0–8 hours:...

  • Page 64: Starting The Engine

    If the neutral indi- cator light does not come on, ask a After break-in: Yamaha dealer to inspect the electric The vehicle may now be operated normally. circuit.  The engine can be started in any gear if...

  • Page 65: Drive Select Lever Operation And Reverse Driving

    Do not turn the key to the “ ” (start) position 2. Apply the brake pedal, then shift by mov- with the engine running; otherwise, damage ing the drive select lever along the shift to the electric starter may result. guide.
  • Page 66  When in reverse, the reverse indicator light should be on. If the light does not Use “L” (low-range) when traveling at slow come on, ask a Yamaha dealer to in- speed. This includes when crossing difficult spect the reverse indicator light electri- terrain such as rocky surfaces, deep mud, cal circuit.
  • Page 67 5. Check behind the vehicle for people or obstacles, and then release the brake pedal. 6. Press the accelerator pedal gradually and continue to watch to the rear while back- ing.

  • Page 68: On-Command Drive Knob

    EBU39141 On-Command drive knob The vehicle handles differently in each of the drive modes (“2WD”, “4WD” and “DIFF. LOCK”). For example, the vehicle requires more effort to turn in “DIFF. LOCK” than in “2WD”. Always stop the vehicle before changing the position of the On-Command drive knob. The meter display changes according to the selected drive mode.
  • Page 69  When using the differential gear lock (“DIFF. LOCK”), the differential gear lock indicator light and the drive train icon will flash until the differential gear lock properly engages/disengages.  When the differential gear lock indicator light and the drive train icon are flashing, turning the steering wheel back and forth will help the differential gear lock to engage or disengage.

  • Page 70: Parking

    EBU31930 EWB04260 Parking WARNING When parking, stop the engine and shift the Improper loading or towing can increase drive select lever into the neutral position. Ap- the risk of loss of control, an overturn, or ply the parking brake to help prevent the ve- other accident: hicle from rolling.
  • Page 71 Operating when loaded with cargo or tow- MAXIMUM LOAD LIMITS ing a trailer Cargo bed: Drive more slowly than you would without a 272.0 kg (600 lb) Pulling load (gross trailer weight): load. The more weight you carry, the slower 6664 N (680 kgf, 1500 lbf) you should go.
  • Page 72 Pulling something other than a trailer Yamaha recommends that loads be trans- ported in the bed or in a trailer. If you need to move an object a short distance use a winch and follow the winch manufacturer’s instruc- tions.

  • Page 73: Basic Guide For Safe Use

    EBU31950 EBU32974 KNOW YOUR VEHICLE BASIC GUIDE FOR SAFE USE This off-road vehicle will handle and maneu- ver differently from cars, ATVs, go-carts, golf- EBU31962 cars and grounds-keeping vehicles. The Vi- As a Viking owner you are responsible for the king has higher ground clearance and other safe and proper operation of this vehicle.
  • Page 74 As the owner/operator, it is your responsibility to protect yourself and your passengers from accidents, including rollovers. The Viking has DRIVER many features, including a protective struc- ture and seat belts, to help protect occu- UNDER pants, but the best way to avoid injuries is to avoid accidents.
  • Page 75  Do not allow someone to ride as a passen- tomobiles, to promote safe driving behaviors, you should supervise younger drivers and ger who has been using drugs or alcohol.  Do not allow children who need child safety consider setting rules and putting limits on how, when, and where the Viking can be seats or booster seats in the Viking.
  • Page 76 Occupant protection system EWB03350 WARNING Do not make changes to the occupant pro- tection system. If you install aftermarket products or have your vehicle modified, you may put yourself and others at greater risk of serious injury or death. You are re- sponsible for any such changes to the ve- hicle.
  • Page 77 Protective structure Seat belts The vehicle cage/frame provides a protective Seat belts should be worn by the driver and structure that helps limit intrusions by branch- passengers. The driver must be sure that the es or other objects and may reduce your risk passengers are belted before driving.
  • Page 78 main in the vehicle – the doors and passenger To wear the seat belt properly, do the follow- handhold are not a substitute for using a seat ing: belt. 1. Hold the latch plate as you pull the belt A crash can damage the restraint systems in across your lap and chest.
  • Page 79 3. Push the latch plate into the buckle until it 5. Position the shoulder belt over your clicks. Pull up on the latch plate to make shoulder and across your chest. The sure it is secure. shoulder belt should fit against your chest.
  • Page 80 hand on the door during operation. Your hand or arm may be struck by objects or crushed against outside objects or the ground during a rollover. 1. Seat belt height adjuster 2. Seat belt 3. Slot 7. To release the buckle, firmly press the re- lease button.
  • Page 81 The driver should make sure the passengers are holding onto the handhold with both hands before operating the vehicle. Adjust the handhold position as follows. 1. Remove the locking pins. Adjusting the handhold position The handhold can be adjusted to one of three positions to suit the passengers’...
  • Page 82 2. Slide the handhold to the desired position and align the holes in the handhold bar with the holes in the handhold supports. 1. Wire loop Seat and shoulder bolsters The seats and shoulder bolsters are designed 1. Handhold bar to help keep you in the vehicle.
  • Page 83 ly jerk in one direction or back and forth as the tires and vehicle respond to the obstacle. This quick motion could injure your thumbs or wrist if your thumbs or hand(s) are inside the steering wheel. Grip the steering wheel so that your thumbs will not be hit by the spokes.

  • Page 84: Learning To Operate Your Vehicle

    EBU31984 LEARNING TO OPERATE YOUR VEHI- CORRECT GRIP EXAMPLE Personal protective equipment INCORRECT GRIP EXAMPLE 1. Approved motorcycle helmet 2. Eye protection 3. Long-sleeved shirt or jacket 4. Gloves 5. Long pants 6. Over-the-ankle boots The driver and passengers should wear the following to reduce risk of injury in an acci- dent: 8-12...
  • Page 85  Approved motorcycle helmet that fits prop- Practice for new Yamaha Viking users erly You should become familiar with the perfor-  Eye protection (goggles, helmet face shield, mance characteristics of the vehicle in a or protective eyewear) large, flat area that is free of obstacles and ...
  • Page 86 Getting ready to ride Perform the Pre-Operation Checks on page 6-1. Follow the instructions starting on page 7-2 to start the engine. Turning Use care in turns – turning the steering wheel too far or too fast can result in loss of control or a rollover.
  • Page 87 If you think or feel that the vehicle may tip or Avoid higher speeds and sudden or hard ac- roll, keep your body completely inside the celeration until you are thoroughly familiar protective structure of the vehicle: with the operation of your vehicle. Avoid sud- ...
  • Page 88 the vehicle down after you take your foot off Parking on a flat area the accelerator. Engine braking is more no- When parking on a flat area, stop the engine ticeable in four-wheel drive. Application of ve- and shift the drive select lever into the neutral hicle brakes provides additional stopping position.
  • Page 89 5. Block the front and rear wheels with Your Yamaha Viking has higher ground clear- rocks or other objects. ance and other features to handle rugged ter- rain, and as a result, can overturn in situations Loading where some vehicles may not. Abrupt ma-...
  • Page 90 to see far enough ahead of you. Use common side of a hill, which increases your risk of roll- sense and remember that some hills are too over. Practice first on gentle slopes before at- steep for you to climb or descend. Use proper tempting steeper hills.
  • Page 91 slow your descent. Release the brake and be- If you are sliding or skidding, try to steer in the gin to coast down the hill. Use engine braking direction the vehicle is sliding, to regain con- as much as possible, gently applying the trol.
  • Page 92 Pavement Wet brakes may have reduced effectiveness. This vehicle is designed for off-road use only. After leaving the water, test the brakes. If nec- Avoid paved surfaces. Turn gradually and go essary, apply the brakes several times to let slowly if you must drive on pavement. friction dry them out.
  • Page 93 drive before driving on a slippery surface and the risk of fire during operation or after leaving plan your path to avoid making abrupt ma- the vehicle, do not let brush, grass and other neuvers. materials collect under the vehicle, near the If you feel the vehicle begin to slide sideways muffler or exhaust pipe, or next to other hot or fishtail (rear-wheel sliding), steer into the di-...
  • Page 94 If there is any question about your ability to maneuver safely over the obstacle, you should turn around if the ground is flat and you have the room or back up until you find a less difficult path. 8-22...

  • Page 95: Periodic Maintenance And Adjustment

    To avoid death during service or while using the ve- possible burns, let brake components cool hicle. If you are not familiar with vehicle before touching them. service, have a Yamaha dealer perform the service.

  • Page 96: Owner's Manual

    EBU40370 Owner’s Manual one, take your vehicle to a Yamaha dealer to You are recommended to put this owner’s check the torque settings and adjust them as manual in the vinyl bag and always carry it in necessary.

  • Page 97: Maintenance Charts

    Even if the vehicle isn’t driven for the stated mileage or engine hours, the month maintenance intervals should still be followed. Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. EBU35773...
  • Page 98 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1300 2500 2500 5000 first (mi) (150) (800) (1600) (1600) (3200) hours • Check the air cut-off valve, reed valve, and Air induction sys- √ √ √ √ √ hose for damage. •...
  • Page 99 EBU35804 General maintenance and lubrication chart INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1300 2500 2500 5000 first (mi) (150) (800) (1600) (1600) (3200) hours • Check coolant leakage. √ √ √ √ √ • Repair if necessary. Cooling system •...
  • Page 100 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1300 2500 2500 5000 first (mi) (150) (800) (1600) (1600) (3200) hours • Check operation/brake pad wear/fluid leak- age. √ √ √ √ √ Rear brake • Correct if necessary. Replace pads if worn to the limit.
  • Page 101 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1300 2500 2500 5000 first (mi) (150) (800) (1600) (1600) (3200) hours • Check operation and for looseness. Replace √ √ √ √ √ 16 * Steering system if damaged. • Check toe-in. Adjust if necessary. •...
  • Page 102 EBU32331  Some maintenance items need more frequent service if you drive in unusually wet, dusty, san- dy or muddy areas, or at full throttle.  Hydraulic brake service • Regularly check and, if necessary, correct the brake fluid level. •...

  • Page 103: Hood

    EBU32340 Hood To remove 1. Pull the tab on each hood lock up, and then turn the hood locks 1/4 turn clock- wise. 1. Tab 2. Hood lock 2. Remove the hood. 1. Tab 1. Hood...

  • Page 104: Engine Oil And Oil Filter Cartridge

    To install EBU33023 Engine oil and oil filter cartridge 1. Insert the projections on the hood into the Check the engine oil level before each opera- slots in the front grill, and then place the tion. In addition, change the oil and the oil fil- hood in the original position.
  • Page 105 Recommended engine oil: See page 11-1. Oil quantity: Without oil filter cartridge replacement: 2.20 L (2.33 US qt, 1.94 Imp.qt) With oil filter cartridge replacement: 2.30 L (2.43 US qt, 2.02 Imp.qt) To check the engine oil level 1. Park the vehicle on a level surface. 1.
  • Page 106 1. Maximum level mark 1. Right rear panel 2. Minimum level mark 2. Quick fastener screw 3. Oil filler hole 3. Bolt 6. If the engine oil is at or below the mini- mum level mark, remove the right rear Add oil a little at a time so as not to overfill be- panel by removing the quick fastener yond the maximum level mark.
  • Page 107 3. Bolt 6. Place an oil pan under the engine to col-  An oil filter wrench is available from a lect the used oil. Yamaha dealer. 7. Remove the engine oil drain bolt. Discard the used gasket. 9-13...
  • Page 108  Make sure the old O-ring is not stuck to the crankcase. 1. O-ring 10. Install the new oil filter cartridge with an oil filter wrench, and then tighten it to the 1. Oil filter cartridge specified torque with a torque wrench. 2.

  • Page 109: Why Yamalube

    Engine oil drain bolt: Why Yamalube 33 N·m (3.3 kgf·m, 24 lb·ft) YAMALUBE oil is a Genuine YAMAHA Part born of the engineers’ passion and belief that 12. Pour the specified amount of engine oil engine oil is an important liquid engine com- into the oil filler hole, and then install the ponent.

  • Page 110: Final Gear Oil

    Yamalube mineral, semisynthetic and syn- area. thetic oils have their own distinct characters and value. Yamaha’s experience gained over Recommended oil: many years of research and development into YAMALUBE oil since the 1960’s helps make Yamalube the SAE 80W-90 API GL-5 Hypoid gear oil best choice for your Yamaha engine.
  • Page 111 Tightening torque: Final gear oil filler bolt: 22 N·m (2.2 kgf·m, 16 lb·ft) Changing the final gear oil 1. Park the vehicle on a level surface. 2. Place an oil pan under the final gear case to collect the used oil. 3.

  • Page 112: Differential Gear Oil

    4. Install the drain bolt and its new gasket, EBU36065 Differential gear oil and then tighten the bolt to the specified Check the oil level and change the differential torque. gear oil at the intervals specified in the period- ic maintenance chart. Tightening torque: ECB03600 Final gear oil drain bolt:...
  • Page 113 2. Remove the differential gear oil filler bolt 5. Install the differential gear oil filler bolt and its gasket, and then check the oil lev- and its gasket, and then tighten the bolt el. It should be up to the brim of the filler to the specified torque.

  • Page 114: Coolant

    7. Install the differential gear oil filler bolt and its gasket, and then tighten the bolt to the specified torque. Tightening torque: Differential gear oil filler bolt: 23 N·m (2.3 kgf·m, 17 lb·ft) 8. Check for oil leakage. If oil leakage is found, check for the cause.
  • Page 115 If genuine Yamaha coolant is not available, use an ethylene glycol antifreeze containing corrosion inhibitors for aluminum engines and mix with distilled water at a 1:1 ratio. ECB02190 NOTICE Mix antifreeze with distilled water only. However, if distilled water is not available, 1.

  • Page 116: Axle Boots

    To change the coolant The coolant must be changed at the intervals specified in the periodic maintenance chart. Have a Yamaha dealer change the coolant. WARNING! Never attempt to remove the radiator cap when the engine is hot. [EWB04250] EBU32400 Axle boots Check the axle boots for holes or tears.
  • Page 117 Inspection The spark plug is an important engine com- ponent and is easy to inspect. The condition of the spark plug can indicate the condition of the engine. The ideal color of the porcelain insulator around the center electrode is a medium-to- light tan for a vehicle that is being ridden nor- mally.

  • Page 118: Cleaning The Air Filter Element

    rect torque is one-quarter to one-half turn past finger tight. Have the spark plug tightened to the specified torque as soon as possible. Tightening torque: Spark plug: 13 N·m (1.3 kgf·m, 9.6 lb·ft) 3. Install the spark plug cap. 4. Lower the cargo bed. 1.
  • Page 119 fittings for an airtight seal. Tighten all fittings securely to avoid the possibility of unfiltered air entering the engine. ECB02270 NOTICE Never operate the engine with the air filter element removed. Doing so would allow unfiltered air to enter, causing rapid en- gine wear and possible engine damage.
  • Page 120 1. Quick fastener screw 1. Snap holder 2. Cover A 2. Air filter case cover 3. Cover B 3. Pivot holder 4. Remove the air filter case cover by un- 5. Remove the air filter element. hooking the snap holders, and then rotat- ing the cover up and pulling it away from the pivot holders in the back.
  • Page 121 1. Air filter element 1. Air filter element holder 2. Projection 6. While pushing the projections on the air 7. Remove the sponge material from the air filter frame inward, remove the air filter el- filter frame. ement holder. 9-27...
  • Page 122 1. Air filter element holder 10. Wash the sponge material in warm soapy 2. Sponge material water to remove remaining solvent, then 3. Air filter frame rinse thoroughly with plain warm water. 8. Wash the sponge material gently but 11. Squeeze excess water out of the sponge thoroughly in parts cleaning solvent.
  • Page 123 13. Thoroughly apply Yamaha foam air filter 18. Install cover A, then cover B in their orig- oil or other quality liquid foam air filter oil inal positions by installing the quick fas- (not spray type) to the sponge material.

  • Page 124: Air Filter Check Hoses

    EBU32431 Air filter check hoses There is a check hose at the bottom of the air filter case (under the cargo bed) and a check hose at the bottom of the air intake duct (un- der the vehicle). If dust or water collects in a check hose, the air filter element may be soiled.

  • Page 125: V-Belt Case Drain Plug

    If water drains from the V-belt case after re- haust system. moving the drain plug, have a Yamaha dealer inspect the vehicle, as the water may affect 1. Remove the tailpipe bolts.
  • Page 126 1. Tailpipe bolt 1. Gasket 2. Spark arrester 2. Remove the tailpipe by pulling it out of 3. Tailpipe the muffler, and then remove the gasket. 4. Install the gasket, and then insert the tail- 3. Tap the tailpipe lightly, and then use a pipe into the muffler and align the bolt wire brush to remove any carbon depos- holes.

  • Page 127: Valve Clearance

    Yamaha service technician. pad has worn to the point that the wear indi- cator grooves have almost disappeared, have EBU32470 a Yamaha dealer replace the brake pads as a Brakes set. Replacement of brake components requires The wheels need to be removed to check the professional knowledge.

  • Page 128: Checking The Parking Brake Pads

    If a brake pad has worn to the level. Replenish the brake fluid if necessary. point that the wear indicator groove has al- most disappeared, have a Yamaha dealer re- place the brake pads as a set. 9-34...
  • Page 129  Clean the filler cap before removing. Use only DOT 4 brake fluid from a sealed container.  Use only the specified brake fluid; other- wise, the rubber seals may deteriorate, causing leakage.  Refill with the same type of brake fluid. Adding a brake fluid other than DOT 4 may result in a harmful chemical reac- tion.

  • Page 130: Brake Fluid Replacement

    EBU32531 Checking the brake pedal brake fluid level to gradually go down. A low Have a Yamaha dealer check the brakes at brake fluid level may indicate worn brake the intervals specified in the periodic mainte- pads and/or brake system leakage; therefore, nance chart.

  • Page 131: Parking Brake Lever Free Play Adjustment

    4. Slide the rubber cover back on the park- EBU40380 Parking brake lever free play adjust- ing brake cable. ment 5. Loosen the locknut. Periodically check the parking brake lever free play and adjust it if necessary. 1. Shift the drive select lever into low gear “L”.

  • Page 132: Brake Light Switch Adjustment

    Cables can also become frayed or kinked. Lubricate the cable ends. If the cables do not operate smoothly, ask a Yamaha dealer to re- place them. Recommended lubricant: 1. Brake light switch Yamalube LubezAll 2.

  • Page 133: Checking The Stabilizer Bushes

    Lubricate the knuckle upper and lower pivots EBU32583 Checking the stabilizer bushes with a grease gun. The stabilizer bushes must be checked for cracks or damage at the intervals specified in the periodic maintenance chart. Have a Yamaha dealer replace the stabilizer bushes if necessary. 9-39...

  • Page 134: Steering Shaft Lubrication

    EBU32610 Recommended lubricant: Wheel removal Lithium-soap-based grease 1. Loosen the wheel nuts. 2. Elevate the vehicle and place a suitable EBU32600 Steering shaft lubrication stand under the frame. Lubricate the pivot points. 3. Remove the nuts from the wheel. 4. Remove the wheel. Recommended lubricant: Lithium-soap-based grease 9-40...

  • Page 135: Tire Replacement

    Always use the same size and type of tires Size: recommended in this owner’s manual. The 25x8-12NHS tires that came with your Yamaha Viking were Manufacturer/model: designed to match the performance capabili- MAXXIS/MU09 ties and to provide the best combination of Rear tire: handling, braking, and comfort.

  • Page 136: Wheel Installation

    Wheel installation WARNING 1. Install the wheel and the nuts. Do not reverse the rims on your Yamaha Viking to widen the track width. Installing wheels improperly increases the risk of For BHF9: be sure to install the nuts with their wheel failure and accidents.
  • Page 137 EWB03410 EWB03420 WARNING WARNING Avoid battery contact with skin, eyes, or Batteries may produce explosive gases. clothing. Shield eyes when working near Ventilate when charging or using in a batteries. Keep out of reach of children. closed space. Keep batteries away from You could be poisoned or severely burned sparks, flames, cigarettes, or other sourc- by the sulfuric acid in battery electrolyte.
  • Page 138  Remove it from vehicle and confirm the rec- positive lead. [ECB01002] ommended charging rate as specified on the battery itself.  Select a suitable charger and follow the manufacturer’s instructions, or have a Yamaha dealer charge it for you. 9-44...
  • Page 139  Keep in mind that the battery tends to dis- ECB00942 NOTICE charge more quickly if the vehicle is  Always keep the battery charged. Stor- equipped with optional electrical accesso- ing the battery in a discharged state for ries. an extended period of time will cause ECB00933 NOTICE...

  • Page 140: Jump-Starting

    EBU32651 Jump-starting Jump-starting the vehicle should be avoided. The battery should be removed and charged instead. However, if the vehicle must be jump-started, proceed as follows. EWB03430 WARNING To avoid battery explosion and/or serious damage to the electrical system: 1. Positive battery lead (red) ...
  • Page 141 vehicle and the other end of the positive lead to the positive terminal of the charged battery. 1. Jumper cable negative lead 5. Start the engine. (See page 7-2.) 6. After the engine starts, disconnect the 1. Jumper cable positive lead negative lead of the jumper cable from 4.

  • Page 142: Fuse Replacement

    Fuse box EBU32665 Fuse replacement The fuses are located under the hood. If an electrical problem is suspected, check the fuses and replace if necessary. General layout 1 2 3 4 5 6 1. Backup fuse “BACK UP” (for clock) 2.
  • Page 143 1. Turn off all electrical systems. (See page Specified fuses: 5-1.) Main fuse: 2. Remove the hood. (See page 9-9.) 40.0 A Fuel injection system fuse: 3. Remove the blown fuse, and then install a 10.0 A new fuse of the specified amperage. Headlight fuse: WARNING! Always use a fuse of the 15.0 A...

  • Page 144: Replacing A Headlight Bulb

    Yamaha dealer check the electrical sys- tem. 5. Install the hood. EBU32671 Replacing a headlight bulb If a headlight bulb burns out, replace it as fol- lows. 1. Remove the cover at the rear of the head- light by pulling it off.
  • Page 145 clean off any dirt and fingerprints us- ing a cloth moistened with alcohol or thinner. [ECB00653] 1. Headlight bulb holder 5. Wait for the headlight bulb to cool before touching or removing it. Remove the 1. Do not touch the glass part of the bulb. burnt-out bulb by pulling it out.

  • Page 146: Headlight Beam Adjustment

    ECB00691 If a brake/tail light bulb burns out, replace it as NOTICE follows: It is advisable to have a Yamaha dealer 1. Remove panel A (if replacing the left make this adjustment. brake/tail light bulb) or panel B (if replac-...
  • Page 147 2. Remove the brake/tail light bulb holder (together with the bulb) by turning it counterclockwise. 1. Panel B 1. Brake/tail light bulb holder 3. Push the burnt-out bulb in and turn it counterclockwise to remove it from the bulb holder. 4.

  • Page 148: Troubleshooting

    The troubleshooting chart describes a quick, easy procedure for making checks. If your vehicle requires any repair, take it to a Yamaha deal- 9-54...

  • Page 149: Troubleshooting Charts

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 150 Restart the engine. If the engine overheats again, ask a Level is OK. Yamaha dealer to inspect and/or repair the cooling system.  Tap water can be used in an emergency. Change to the recommended coolant as soon as possible.

  • Page 151: Cleaning And Storage

    may have reduced stopping ability, in- EBU32720 CLEANING AND STORAGE creasing the chance of an accident. NOTICE: Excessive water pres- EBU32732 [EWB03471] Cleaning sure may cause water seepage and Frequent, thorough cleaning of your vehicle deterioration wheel bearings, will not only enhance its appearance but will brakes, transmission seals and electri- improve its general performance and extend cal devices.

  • Page 152: Storage

    Avoid combination cleaner-waxes. Many the specified amount of Fuel Med Rx, contain abrasives which may scratch the available from your Yamaha dealer, or paint or protective finish. When finished, equivalent product. Follow the instruc- start the engine and let it idle for several tions on the product label.
  • Page 153 30 °C [90 °F] or less than 0 °C [32 °F]). Use of Fuel Med Rx or another high-quality fuel stabilizer eliminates the need to drain the fuel system. Consult a Yamaha dealer if the fuel system needs to be drained. 10-3...

  • Page 154: Specifications

    EBU32751 SPECIFICATIONS Engine: EBU38811 Combustion cycle: 4-stroke Cooling system: The 4-digit model type code can be con- Liquid cooled Valve train: firmed by checking the model label. (See SOHC page 1-1.) Number of cylinders: Single cylinder Displacement: Dimensions: 686 cm³ Overall length: Bore ×...
  • Page 155 Recommended engine oil grade: Coolant quantity: API service SG type or higher, JASO standard MA Coolant reservoir (up to the maximum level mark): 0.28 L (0.30 US qt, 0.25 Imp.qt) 130 ˚F Radiator (including all routes): 2.74 L (2.90 US qt, 2.41 Imp.qt) SAE 5W-30 Fuel: Recommended fuel:...
  • Page 156 Loading: Maximum load: 411.0 kg (906 lb) (Total weight of all occupants, cargo, accessories, and tongue) Front brake: Type: Hydraulic disc brake Rear brake: Type: Hydraulic disc brake Front suspension: Type: Double wishbone Rear suspension: Type: Double wishbone Electrical system: System voltage: 12 V Battery:...

  • Page 157: Consumer Information

    EBU32775 CONSUMER INFORMATION EBU32820 Vehicle Emission Control Information label The Vehicle Emission Control Information la- bel is affixed at the location in the illustration. This label shows specifications related to ex- haust emissions as required by federal law, state law and Environment Canada. 1.

  • Page 158: Noise Regulation (For Usa)

    EBU32831 NOISE REGULATION (for USA) TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering in- operative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.

  • Page 159: Maintenance Record

    EBU35843 MAINTENANCE RECORD Copies of work orders and/or receipts for parts you purchase and install will be required to doc- ument maintenance done in accordance with the warranty. The chart below is printed only as a reminder to you that the maintenance work is required. It is not acceptable proof of maintenance work.

  • Page 160: Yamaha Motor Corporation

    EBU32856 YAMAHA MOTOR CORPORATION, U.S.A. 2020 AND LATER MODEL SIDE-BY- SIDE LIMITED WARRANTY (for USA) Yamaha Motor Corporation, U.S.A. hereby warrants THE CUSTOMER’S RESPONSIBILITY under this YAMAHA MOTOR CORPORATION, U.S.A. MAKES that new Yamaha Side-by-Side models purchased warranty shall be to:...

  • Page 161: Warranty (For Usa)

    Attention: Warranty Department 3. Each Yamaha Side x Side dealer is held responsible for his setup, service and war-ranty repair work. This will ensure that Yamaha Motor Corporation, U.S.A. has an up-to-date registration record in accordance with federal law.

  • Page 162: Yamaha Extended Service (Y.e.s.) (For Usa)

    This excellent Y.E.S. plan coverage is only available to dealer to see how comfor ting uninterr upted factor y- Yamaha owners like you, and only while your Yamaha is still backed protection can be. within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts.
  • Page 163 Yamaha. See your dealer today! A special note: YAMAHA EXTENDED SERVICE If visiting your dealer isn’t convenient, contact Yamaha with your Vehicle Identification Number. We’ll be happy to help you get the Y.E.S. coverage you need. Yamaha Service Marketing P.O. Box 6555...

  • Page 164: Index

    INDEX Differential gear lock indicator light ....... 5-3 Differential gear oil, Periodic maintenance ....9-18 Differential gear, Pre-operation check ......6-6 Accelerator pedal ............5-12 Doors ................5-14 Accelerator pedal, Pre-operation check ......6-6 Driver seat position ............5-16 Air filter check hoses ............9-30 Drive select lever ............
  • Page 165 Helmet reminder light ............ 5-5 High-range indicator light ..........5-2 Parking ................7-8 Hood ................9-9 Parking brake indicator light .......... 5-3 Parking brake lever ............5-13 Identification numbers ........... 1-1 Parking brake lever free play, adjusting ...... 9-37 Indicator lights and warning lights ......... 5-2 Parking brake pads, checking ........
  • Page 166 Valve clearance ............9-33 V-belt case drain plug ..........9-31 Vehicle Emission Control Information label ....12-1 Vehicle identification number .........1-1 Warranty, extended (for USA) ........12-6 Warranty, limited (for USA) ...........12-4 Wheel installation ............9-42 Wheel removal .............9-40 Yamalube ..............9-15 13-3...
  • Page 167 EBU32880 For your best ownership experience, think Genuine Yamaha! Genuine Yamaha Parts – Genuine Yamaha replacement parts are the exact same parts as the ones originally equipped on your vehicle, providing you with the performance and durability you have come to expect.
  • Page 168 PRINTED IN USA 2021.10-0.7×1 CR (E)

This manual is also suitable for:

Yxm70vpan 2021Yxm70vphn 2021Yxm70vprn 2021

Table of Contents
