Intruder alarm system
Used for the [B] key. If selected, then the keypad will skip the PIN entering procedure and will automatically enter
Security Settings
the 1st user's PIN.
3 Bypass with PIN Yes
This settings allows to enable or disable access to System summary menu.
Security Settings
Sys. summary PIN req. Yes
4
This setting allows to enable or to disable access to the special user menu, where installer with his PIN can
Security Settings
restore 1st user's PIN to default and the 1st user with his PIN can restore all enabled user PINs to default.
5 PIN resetting Disabled
This feature is intended for situations where the user is forced to disarm or arm the system under a threat. This
Security Settings
setting enables or disables this feature. Duress code is individual for every system user. Duress code = X1, X2,
6 Duress code Disabled
X3, X4 when X4 = X4 + 1 (X1, X2, X3, X4 are digits). Example: user PIN is 1234, duress code will be 1235.
Note: if certain system user's A duress code matches with another system user's B PIN code, then the system will use user's B PIN instead
of the duress code of user A to complete the control action. It is recommended to test duress code availability before using the system. The
event of duress code use will be generated in the event log.

WIRELESS SETTINGS

Service Mode }System Setup }Wireless Subsystem
How often the detector should send a supervision signal and what supervisory window will be in the system
Wireless Subsystem
depends upon the setting Security grade.
1 Security grade Grade 1
Wireless d
Wireless Subsystem
Mode:
Mode LR (Long Range)
2
The default frequency is 868,30 MHz. Depending on country of distribution the wireless devices (detectors,
Wireless Subsystem
PGM outputs and remote control) can be programmed at factory to operate on different frequency. Receiver can
Frequency 868,30 MHz
3
receive a signal from transmitter when operating frequency matches.
Due to the fact that there may be changes in the passive environment after installation, it is possible to
Wireless Subsystem
temporarily for 3dB attenuate the radio frequency link during installation or maintenance. If the system will
4 Attenuation 0 dB
continue receiving signal from the detector with an attenuated radio frequency link, then it will work for sure
under normal conditions. New setting will be applied in 20 min or 1 hour time (depends on supervisory signal
sending frequency).
DO NOT FORGET to change the Attenuation setting's value to 0dB when installation or maintenance works are
finished.

USER PROGRAMMING

Each installation typically accommodates unique user PIN codes of up to 4 digits. The Edit Users menu provides access to submenus and
their related parameters that enable you to maintain user PIN codes in the system. The first user's PIN code is used by the system's owner
or chief user. This user has access to all the menus (except Service mode) and it can't be disabled.
Main menu }Settings }Users } Edit Users
It is recommended to give an appropriate name to a user. The system will use it to send SMS or for display on
U01 User 01
keypad's LCD screen.
1 Name User 01
All users that have the status mode Enabled can control the system or its partitions.
U01 User 01
2 Status Enabled
The Assigned partitions menu enables you to assign the partition(s) in which the user (except for the 1st system
U01 User 01
user) will operate.
Assigned partitions [ENT]
3
Used to allow users to control the system during predefined time periods. Note: if the timer is not assigned, the
U01 User 01
user will be able to control the system without time limitations.
4 Timers [ENT]
This option allows to restore current user PIN to default. Factory default user PIN depends on user's number in
U01 User 01
the system. System user number is shown next to letter U on top-left corner of the keypad's LCD. For example
5 Reset PIN to default Yes
U01 means the 1st system user, U02 means the 2nd user, and so on. Default PIN code used by U01 (1st user ) -
0001, U02 (2nd user) default PIN - 0002, ..., U63 (63th user) default PIN - 0063. Default PIN code is temporary
and should be changed as soon as possible to a new one. It is recommended to change the old PIN code to one
that will not be used as default for other users (default PIN range 0000 to 0063).
Grade 1 – supervision signal is sent every 1 hour, supervisory window is 1 hour.
Custom – supervision signal is sent every 1 hour, supervisory window is 0 - 24 hour (0 - disables
supervision).
Grade 2 – supervision signal is sent every 20 minutes, supervisory window is 20 minutes.
evices , starting from version
LR – long range mode – distance is bigger, but due to the longer data packet the battery last shorter.
ES – energy save mode – the distance is shorter, but due to the shorter data packet the battery last longer.
System with KM24, KM24A, KM24G keypads
Short programming manual - basic information
2.000 support new communication mode, that can be selected in menu
