SECOLink BK1 Installation Manual

Intruder alarm system
The Bx series detectors (BK1, BK2, BK3, BV3, BK and BT1) provide the mo
and versatile enough to help solve even the toughest, most labor intensive installations. All Bx series detectors are compatible with wireless extension modules EXT116S or with
built-in virtual modules EXT116SVM in P series control panels P16, P32 and P64.
Built-in reed switch (used in
Model
conjunction with a magnet)
BK1
BT1
BK2
BK3
BV3
BK4
Dimensions (W x H x D)
27 mm x 75 mm x 23,6 mm
1
1
2
4
4
Tamper Tamper
Non-flat surface
Flat surface
The detector includes a built-in tamper that can be
activated if the detector is mounted on a non-flat surface.
2
1
4
SECOLINK WIRELESS DETECTORS
Built-in temperature
sensor
Ambient temperature Ambient humidity
o o
-10 C - +55 C 0% - 70%
2
Magnet (BK1, BK4)
3
5
3
2
BK2:
C - COM
1 - input 1
2 - input 2
3 - output (+3,6V)
BV3, BK3, BK4:
C - COM
1 - input 1
2 - input 2
3 - input 3
Caution: make sure that loop wires do not short any
components on circuit board.
BATTERY INSTALLATION/REPLACEMENT
Battery life of wireless detectors depends on the environment, usage, and the specific wireless devices being used.
Factors such as humidity, high or low temperatures, as well as large swings in temperature may all reduce the actual
battery life in a given installation. When the battery is nearly dead (low battery threshold voltage < 2,45V), the detector
will send a low battery signal to the alarm system for the user to replace it before it discharges completely.
1. Unscrew the self-tapping screw.
2. Remove the detector's top cover.
3. Observe correct polarity and insert the battery into the battery holder.
4. Close the top cover and secure it with a self-tapping screw.
5. Dispose of used batteries as per local regulations.
Caution: the detector will send a tamper message to the receiver when housing is opened - the alarm can be
triggered.
BK1, BK2, BK3, BV3, BK4 and BT1 Wireless detectors
st reliable, convenient and cost effective solutions for security
Input loops (zones) for Supports wired normally
wired applications closed circuit contact loops
2
3
3
3

SPECIFICATIONS

Operating frequency
Depends on firmware version of the detector:
1 = 868,30 MHz (EU)
9 = 915,30 MHz (AU)
* calculated battery life expecting that there will be 12 events and 12 restores

INSTALLATION

> 0,5 cm
Wire entry hole
Reed switch
location
Tamper
Magnet alignment
marks
Top cover
1
COM
Thin "breakout"
area for cable
up to 2 m
Cable
To input
COM To input
+3,6V
COM
C NC C NC
Detector Detector
External detector, Magnetic contact /
powered from BK2 Roller / Vibration
(current < 20uA)
Installation manual
protection. These
Supports wired Roller
detectors
Battery
Lithium battery BK1, BT1: ~3 years
½ AA, 3,6V BK3, BV3, BK4: ~2 years
BK2: ~1,5 years (with extra
load of 20 uA on terminal 3)
3
Approach/make: 28mm Approach/make: 10mm
Removal/break: 30mm Removal/break: 12mm
Approach/make: 28mm Approach/make: 5mm
Removal/break: 33mm Removal/break: 7mm
Approach/make: 50mm Approach/make: 34mm
Removal/break: 55mm Removal/break: 38mm
Non-ferromagnetic Ferromagnetic surfaces
surfaces
Recommended maximum gap separation for insta-
llations on non-ferromagnetic surfaces is 25 mm and for
ferromagnetic surfaces is 5 mm.
6
Pull the
plastic tab
Remove the plastic tab. Follow the instructions on the
2nd page and enroll the detector into the alarm system.
After a successful detector's enrollment close the top
cover. Use the supplied self-tapping screw to secure the
top cover to the mounting base.
devices are powerful
Supports wired
Vibration detectors
Battery life*
