User'sGuide
Shop online at
omega.com
e-mail: info@omega.com
For latest product manuals:
www.omega.com
Above items are included with the DBCL130
Dry Block temperature calibrator. Not shown
is the calibration certificate and operator manual
Model DBCL130
Dry Block Temperature Calibrator
Advertisement
Related Manuals for Spectris Omega DBCL130
Summary of Contents for Spectris Omega DBCL130
- Page 1 User’sGuide Shop online at omega.com e-mail: info@omega.com For latest product manuals: www.omega.com Above items are included with the DBCL130 Dry Block temperature calibrator. Not shown is the calibration certificate and operator manual Model DBCL130 Dry Block Temperature Calibrator...
- Page 2 P a g e DBCL130 Dry Block Temperature Calibrator Introduction The DBCL130 calibrator provides a safe, dry, constant temperature source for checking and calibrating a wide range of temperature sensors, systems, indicators and thermometers. It is fast and economical and can be used either on a bench top or as a portable field unit.
- Page 3 P a g e Working environment The calibrator units are designed to work safely under the following conditions: Ambient temperature range: 5°C/9°F to 40°C/104°F Humidity: Up to 95% relative humidity, non-condensing Warning Warning: HIGH TEMPERATURES ARE DANGEROUS HIGH TEMPERATURES ARE DANGEROUS: They can cause serious burns to operators and ignite combustible material.
- Page 4 P a g e OPERATION Preparation The heater design, temperature sensor and control circuit give good temperature control and uniformity, but make sure that there is a close fit of the probes in the block to allow efficient heat transfer. Contact us about an insert that more closely fits your probe or device being calibrated.
- Page 5 P a g e Operation near ambient For best results, to calibrate at a set point near ambient when cooling down from a higher temperature set parameter (AL-1) 3 °C/5 °F higher than you room ambient. When heating up from a lower temperature set (AL-1) 3 °C/5 °F lower than ambient.
- Page 6 P a g e Accessories The following parts may be obtained from Omega Engineering if replacements or alternatives are required: Part Number Description 4163 UK 240 volt power cable with 13amp UK plug (5 amp fuse) 4164 Euro style 240 volt power cable with R/A Schuko plug 4150 US style 120 volt power cable 4168...
- Page 7 P a g e EU Declaration of Conformity (No. DC18-DBCL) In accordance with European Parliament and Council Decision No 768/2008/EC Annex III 1. Product model / product: Product Dry Block Temperature Calibrator Model/type DBCL400 & DBCL130 Batch/serial no. S/N: 619-2993 & onward 2.
- Page 8 omega.com info@omega.com Servicing North America: U.S.A. Omega Engineering, Inc. Headquarters: Toll-Free: 1-800-826-6342 (USA & Canada only) Customer Service: 1-800-622-2378 (USA & Canada only) Engineering Service: 1-800-872-9436 (USA & Canada only) Tel: (203) 359-1660 Fax: (203) 359-7700 e-mail: info@omega.com For Other Locations Visit omega.com/worldwide The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.
- Page 9 WARRANTY/DISCLAIMER OMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a period of 13 months from date of purchase. OMEGA’s WARRANTY adds an additional one (1) month grace period to the normal one (1) year product warranty to cover handling and shipping time. This ensures that OMEGA’s customers receive maximum coverage on each product.
- Page 10 Where Do I Find Everything I Need for Process Measurement and Control? OMEGA…Of Course! Shop online at omega.com TEMPERATURE M U Thermocouple, RTD & Thermistor Probes, Connectors, Panels & Assemblies M U Wire: Thermocouple, RTD & Thermistor M U Calibrators & Ice Point References M U Recorders, Controllers &...
