Figure 3-8. Enabling and Disabling Devices (1 of 3)
3. Press the center button.
4. See 3-9. Highlight Enable and press the
Figure
center button.
PWRcell 2P Inv.
Enable
Mod. Settings
Calibrate CTs
RCPn: 000100073212
< EXIT SCROLL > NEXT • SELECT
Figure 3-9. Enabling and Disabling Devices (2 of 3)
5. See
Figure 3-10. Arrow right and press the center
button to select Confirm.
PWRcell 2P Inv.
Enable
Enable
Mod. Settings
Calibrate CTs
Cancel
RCPn: 00010003XXXX
< EXIT SCROLL > NEXT • SELECT
Figure 3-10. Enabling and Disabling Devices (3 of 3)
NOTE: Per UL1741, the PWRcell inverter may wait five
minutes or longer before beginning to export power after
the inverter has been enabled.
Owner's Manual for Generac PWRCell Inverter
-02
0W
248V
2.4kWh
009970
Menu
009971
Menu
Confirm
009972

Mod. Settings Menu

Most REbus devices have user-adjustable parameters,
such as setpoints for charge, startup voltage, or PLM
channel. See Table 3-4 for available settings.
To access user-adjustable parameters:
1. Use the left and right arrows to navigate to the
desired device page.
2. See
Figure 3-11. Highlight Mod. Settings and
press the center button to select
PWRcell 2P Inv.
Disable
Mod. Settings
Calibrate CTs
RCPn: 000100073212
< EXIT SCROLL > NEXT • SELECT
Figure 3-11. Internet Device Page
NOTE: After selecting Mod. Settings it may take a
moment for the settings to load.
3. See Figure 3-12. Use the up and down arrows to
scroll through available settings.
4. Highlight the desired setting and press the center
button to select.
5. Use the up and down arrow keys to adjust the
value of the setting.
NOTE: Press the center button to deselect a setting at
any time and resume scrolling.
PLM_Channel:
TargMaxImprtP:
TargMinImprtP:
EnaIslanding:
Cancel
Figure 3-12. Mod. Settings Menu (1 of 3)
6. To save the settings, highlight Commit and press
the center button.
Operation
Menu
010234
1
off
off
on
Save
009975
15
