Manual de instalación, operación y mantenimiento
Installations-, Betriebs- und Wartungsanleitung
Installation, operation and manteinance manual
Manuel d'installation, d'exploitation et maintenance
Manuale di installazione, operativo e manutenzione
Manual de instalação, operação e manutenção
66577 Wind Control Sensor
66578 Wind Control Unit
Made in
SPAIN
EQUIPOS PARA FUENTES
FOUNTAIN UNITS
Wind Control Sensor
Advertisement
Table of Contents
Related Manuals for Astralpool 66577
Summary of Contents for Astralpool 66577
- Page 1 Installations-, Betriebs- und Wartungsanleitung Installation, operation and manteinance manual Manuel d'installation, d'exploitation et maintenance Manuale di installazione, operativo e manutenzione Manual de instalação, operação e manutenção 66577 Wind Control Sensor 66578 Wind Control Unit Made in SPAIN EQUIPOS PARA FUENTES...
- Page 2 Fig. 1 Fig. 2...
-
Page 3: Table Of Contents
Fountain units [en] INSTALATION, OPERATION AND MAINTENANCE MANUAL Wind Control Sensor ÍNDICE GENERAL SAFETY ....................................4 ELECTRICAL SAFETY ..................................4 ...................................... 4 SAFETY IN USE OPERATION AND MAINTENANCE SAFETY ............................ 4 INSTALATION AND ASSEMBLY ................................4 SENSOR ..............................4 FASTNING AND LEVELLING .................................. -
Page 4: General Safety
GENERAL SAFETY ELECTRICAL SAFETY Disconnect the unit from the power supply before doing any assembly or maintenance job. Do not touch the water or get into the water while the unit is connected to the power supply. Connect the unit to a power supply with an earth connection, protected by the following components: ... -
Page 5: Control Unit Fastening
Fountain units Wire Wire Plastic strap Bracket support Plastic strap Bracket support Support profile Support profile Fig. 3 IMPORTANT: Prevent any friction or oxide slags that could damage the wire cover. CONTROL UNIT FASTENING IMPORTANT: Risck of damage. Fix the control unit out of the fountain within a enclosure or electrical cabinet. The protection class of the control unit is IP-20. -
Page 6: Settings
SETTINGS The control unit has a display to visualize the values of wind speed, as well as a set up menu for the output activations in function of the wind detected by the anemometer. NAVIGATION BY MENUS To navigate by the menus and realize the set up, the control unit has three keys: ▲▼Keys to navigate through menus and modify values. - Page 7 Fountain units SET UP MIN/MAX WIND SPEED VALUES SET UP DELAY ON DETECTION AND/OR ON RELEASE...
- Page 8 A practical example of control unit setting is given below. Let us assume that there is an installation where our objective is to decrease the pump flow when the wind is between 10 Km/h and 20 Km/h and for winds faster than 20km/h, switching the unit off to prevent equipment damage and for safety reason. For this, there is one anemometer and one control unit, that unit will be set following below control parameters: Relay 1 will be disabled if wind is faster than 10km/h during 5 seconds of detection time.
- Page 9 Fountain units How to change the anemometer release set point in explained below. Relay 1 (Strong wind) This relay´s role is to detect strong gusts of wind. It will be set this way: Press the key with a circle. Press the arrows to reach Relay 1 and press the circle´s key. Press the arrows until Definition working mode and press the circle´s key.
- Page 10 Press the arrows to reach Wind speed release minimum and press the circle´s key. Type 0.1 and validate. Press the arrows to reach Definition working mode and press the circle´s key. Press the arrows to reach Wind speed minimum and press the circle´s key. Press the arrows to reach Non operative and press the circle´s key.
-
Page 11: Control Unit Operation Diagram
Fountain units CONTROL UNIT OPERATION DIAGRAM td: Detection timer tr: Release timer Looking at our practical case explained above, our Relays, past a concrete Tr previously set up in the control unit, are set to 1. Once the wind speed reaches MAX2 = 10 km/h, our Relay 1, after a Td, is deactivated. Arrived to MAX3 = 20 km/h, and passed again a Td, our Relay 2 will be deactivated. -
Page 12: Operation And Maintenance
OPERATION AND MAINTENANCE WARNING: A very dense pollution may could arrive to deposit a solid layer of particles between the mobile sensor part and the fixed part, preventing the correct working of this. The slit that separates both parts must keep always clean. SAFE MANAGEMENT OF WASTE At the end of the useful time of this equipment, remember to correctly manage the different components according to the current regulations of waste management in your country.
