AQUA-QUIP POOL LIGHTS

ASTRAL VIRON CONNECT 10 CONTROLLER (VC10-SLX)

Aqua-Quip's VC10-SLX compatible pool lights

(marked "SUITS ASTRAL VIRON CONNECT" on the rear of the

pool light) can also be operated from a standard Wall Switch.

See attached sheet "Wall Switch Procedure".

When operated from an Astral Viron Connect 10 Controller, follow the setup and

operating instructions below.

From the MAIN MENU Screen

Press SET UP.

Press INSTALLATION SET UP.

Press CHANGE.

A S T R A L

P O O L

–

V C 1 0 - S L X

SET-UP AND

OPERATION MANUAL

Press RIGHT ARROW.

Enter PASSWORD 1234

Press DONE.

Press SET UP WIZARD.

S E T - U P

O P E R A T I O N

M A N U A L

Need help?

Do you have a question about the ASTRAL VIRON CONNECT 10 and is the answer not in the manual?

Page 1 (marked “SUITS ASTRAL VIRON CONNECT” on the rear of the pool light) can also be operated from a standard Wall Switch. See attached sheet “Wall Switch Procedure”. When operated from an Astral Viron Connect 10 Controller, follow the setup and operating instructions below. From the MAIN MENU Screen Press RIGHT ARROW.
Page 2 AQUA-QUIP POOL LIGHTS SET-UP AND OPERATION MANUAL If you want to control lighting zones independently (example: the pool is Blue and the spa is Green) then you will need a separate transformer per zone. Each transformer will plug into an available (unused) Channel on the Viron Connect 10.
Page 3 AQUA-QUIP POOL LIGHTS SET-UP AND OPERATION MANUAL In this case, Channel 3 is available Select whether the transformer and pool (unused), so Press LIGHTING. lights plugged into Channel 3 will be for Press NEXT. Pool or Spa. Press NEXT. Select whether you are using fixed-colour From the Main Menu screen, press or multi-colour lights on Channel 3.
Page 4 AQUA-QUIP POOL LIGHTS SET-UP AND OPERATION MANUAL Press the Colour Box for the Pool Lighting Then Press BLUE for all other Lighting Zone, and an array of Fixed Colours and Zones. The Viron Connect 10 relays will Colour Show options will appear. start switching the lights on/off.
