Astralpool IGNIA LIGHT DMX pro Quick Start Manual

SLESA-UE7
OnDMX Pro I0835
Sunlite Easy Stand Alone USB-DMX controller
DMX live control and stand alone controller
Key Features
• 3 DMX512 universes in live mode (computer)
• 2 DMX512 universes in stand alone
• Network synchronisation for hundreds of universes
• Multi-zone microSD memory
• 250 scenes across 5 areas
• USB & Ethernet connectivity for programming/control
• 8 dry contact trigger ports via HE10 connector
• Clock and calendar with Sunrise/Sunset triggering
• Network communication. Control lighting remotely
• OEM customization
• Windows/Mac software to set dynamic colors/effects
• iPhone/iPad/Android remote and programming apps
Optional Accessories
POWER1_EU/UK/US 5V ACDC power supply with EU/UK/US plug
© Nicolaudie-Sunlite 1989-2015. All rights reserved. We reserve the right without notice to amend the technical information and specifications.
Overview
The Stand Alone DMX controller can be used
to control a wide variety of different DMX
systems- from RGB/RGBW to more advanced
moving and color mixing luminaires, DMX
audio players and fountains. The controller
comes with a variety of features including 1024
DMX channels, clock/calendar, iPhone/iPad/
Android remote control, Ethernet facilities, dry
contact port triggering and multi-zone SD card
memory.
The lighting levels, colors and effects can be
programmed from a PC, Mac, Android, iPad or
iPhone using the included software.
http://www.nicolaudie.com/slesa-ue7.htm
Technical Data
Input Power
Output Protocol
Programmability
Available Colors
Connections
Memory
Environment
Buttons
Dimentions
Complete Package
OS Requirements
Standards
5-5.5V DC 0.6A
DMX512 (x2)
PC, Mac, Tablet, Smart-
phone
Blue, Orange, Gray, Green,
Marine, White, Red
Mini USB, XLR3, XLR5,
Ethernet, 2x HE10, battery
microSD card
IP20. 0°C - 50°C
2 buttons to change scene
+ 1 button to change area
79x92x43mm 120g
140x135x50mm 340g
Mac OS X 10.7-10.10.
Windows XP/VISTA/7/8
EC, EMC, ROHS, ETL, UL
(some are in progress)
