Summary of Contents for Inalto Classique IDW604W
- Page 1 60CM FREESTANDING MODEL/S DISHWASHER IDW604W IDW604S USER MANUAL V 2.1 1221...
-
Page 2: Welcome
— Head Office At InAlto, we are customer obsessed and our Support Teams are there to ensure you get 165 Barkly Avenue the most out of your appliance. Should you want to learn more about your dishwasher... -
Page 3: Table Of Contents
Your Receipt Warranty Customer Care InAlto recommends the use of original spare parts. When contacting our customer service team on 1300 11 4357, please ensure that you have the following information at hand (which can be found on your appliances’ rating plate). -
Page 4: Important Safety Instructions
PAGE 4 Important Safety Instructions GENERAL SAFETY INSTRUCTIONS WARNING! When using your dishwasher, always follow the precautions listed below. Failure to do so can cause injury or damages. You may then not be covered by warranty for this damage. Only plug this appliance directly into an AC power supply which is properly earthed and had the correct voltage. Refer to the appliance rating plate (located on the rear of your clothes dryer) for the voltage information. - Page 5 PAGE 5 INALTO.HOUSE GENERAL SAFETY INSTRUCTIONS CONTINUED • During installation, the power supply must not be excessively or dangerously bent or flattened. • Do not tamper with controls. • The appliance needs to be connected to the main water valve using new hose sets. Old sets should not be reused.
-
Page 6: Your Dishwasher
PAGE 6 Your Dishwasher THE MAIN COMPONENTS Note: The images may differ slightly to your model and are for general reference only. Figure 1- Front view Figure 2- Back view... -
Page 7: Control Panel
PAGE 7 INALTO.HOUSE Control Panel Figure 3- Control panel On/Off button: switches the dishwasher On and Off. 2. Program button: Press this button to cycle through the program options (i.e. Intensive, Glass, Eco, etc) 3. Intensive Program indicator: LED indicates whether this program is selected or not. -
Page 8: Technical Information
PAGE 8 Technical Information Height: 845mm Width: 598mm Depth: 600mm (with door closed), 1175mm (with door opened 90°) Water Pressure: 0.04-1.0MPa=0.4-10 bar Power Supply: AC 220-240V/50Hz Power Consumption: 1760-2100W Capacity: 12 Place Settings... -
Page 9: Installation Instructions
PAGE 9 INALTO.HOUSE Installation Instructions WARNING! Electrical shock hazard Disconnect electrical power before installing the dishwasher. Failure to do so could result in death or electrical shock. Important! The installation of the dishwasher, plumbing and electrical outlets should be completed by licenced tradespeople. - Page 10 PAGE 10 Installation Instructions (Continued) WATER SUPPLY AND DRAIN CONNECTION Cold Water Connection Important! Your dishwasher should only be connected to the cold water outlet. It has an in-built heating element to heat up the water to the required temperatures depending on the selected wash program. Connect the cold water supply hose to a threaded ¾...
- Page 11 PAGE 1 1 INALTO.HOUSE WATER SUPPLY AND DRAIN CONNECTION CONTINUED Important! New waste traps typically have the dishwasher spigot sealed off with plastic and requires the plumber or licensed installer to drill out the center of the spigot to allow water to flow. It’s important to ensure this spigot is drilled out before calling our Service team to respond to a dishwasher failure, as there will be a fee payable should we attend and find this non-warranty installation fault.
-
Page 12: Preparing Your Dishwasher
PAGE 12 Preparing Your Dishwasher RINSE AID Rinse aid is released during the dishwasher’s final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher has been designed to use liquid rinse aids. - Page 13 PAGE 13 INALTO.HOUSE FILLING THE RINSE AID DISPENSER CONTINUED Step 3 Re-insert the Rinse-aid cap and screw in a clockwise direction to lock it in place. Refer to Figure 11. Figure 11- Re-fitting the cap onto the Rinse-aid dispenser. ADJUSTING THE RINSE-AID DISPENSER You can increase or decrease the amount of Rinse-aid being dispensed by your dishwasher for each cycle, using the adjustment dial.
- Page 14 PAGE 14 Preparing Your Dishwasher (Continued) FILLING THE DISHWASHER DETERGENT DISPENSER Step 1 Press the release catch on the detergent dispenser, to open the cover. Refer to Figure 13. Figure 13- Release catch to open the detergent dispenser cover. Step 2 Add the detergent (powder or tablet) into the larger cavity (labelled A in figure 14 below) which is used for the main wash cycle.
- Page 15 PAGE 15 INALTO.HOUSE USING THE BASKETS Your dishwasher is supplied with an upper and lower basket, along with a removable plastic cutlery basket which is designed to sit in the lower basket. Adjusting the upper basket height The height positioning of your upper basket can easily be adjusted between two settings, allowing you to accommodate taller dishes in either the upper or lower basket.
- Page 16 PAGE 16 Preparing Your Dishwasher (Continued) USING THE BASKETS CONTINUED Step 4 Push in the upper basket. Figure 19- Sliding in the upper basket after adjusting its height position. FOLDING BACK THE GLASS RACKS To make room for taller items in the upper basket, you can raise the glass rack upwards, allowing you to lean the tall glasses against it (i.e.
- Page 17 PAGE 17 INALTO.HOUSE PREPARING AND LOADING DISHES INTO YOUR BASKET RACKS Caution! Some items are not safe for use in dishwashers and can be damaged or become discoloured when washed within a dishwasher. Always check the care information on your utensils and crockery to ensure they are dishwasher safe.
- Page 18 PAGE 18 Preparing Your Dishwasher (Continued) Loading the upper basket rack The upper basket rack is designed to hold more delicate and lighter dishware such as glass, coffee/tea cups, saucers, small plates and small bowls. Position the dishes so that they will not get moved by the spray of the water.
- Page 19 PAGE 19 INALTO.HOUSE Loading the cutlery basket Cutlery should be placed into the plastic cutlery basket separately from each other to ensure that the utensils do not nest together. When the cutlery (in particular spoons) is stacked in close proximity and nesting together, the washing performance will be impacted.
-
Page 20: Operating Your Dishwasher
PAGE 20 Operating Your Dishwasher TURNING YOUR DISHWASHER ON AND STARTING A WASH CYCLE Step 1 Load your dishwasher according to the guidelines in the Preparing Your Dishwasher section of this manual. Step 2 Load the dishwasher detergent dispenser (refer to section Preparing Your Dishwasher in this manual). Step 3 Close the dishwasher door and press the Power button to turn on your dishwasher, located on the control panel. - Page 21 PAGE 21 INALTO.HOUSE YOUR DISHWASHERS’ WASH PROGRAMS Your dishwasher has the following wash programs. Please refer to the table below to determine which program is most suitable for each load. Program Process of Suggested Running Energy Water use Rinse the cycle...
- Page 22 PAGE 22 Operating Your Dishwasher (Continued) CHANGING THE PROGRAM Once the dishwasher has started a wash cycle program, you can change the selected program within the first minute or so, otherwise the detergent may have been already released. When you start a new program, the dishwasher will drain any residual water, hence you will need to re-fill the detergent dispenser in the event that it’s already dispensed it.
-
Page 23: Maintenance And Cleaning
PAGE 23 INALTO.HOUSE Maintenance and Cleaning Some simple maintenance and cleaning steps must be followed to ensure that your dishwasher continues to operate at its optimum and without issue. Failure to follow these basic maintenance and cleaning steps may void your Manufacturer’s warranty or result in a service fee in the event of a technician attending site under warranty. - Page 24 PAGE 24 Maintenance and Cleaning (Continued) INTERNAL CARE CONTINUED Step 2 With the filter assembly removed from the dishwasher, the fine filter can be pulled off the bottom of the filter assembly (refer to figure 25 below). This fine filter is covered by a fine mesh. Rinse this under running water from your tap and wipe any residual food residue off the filter.
- Page 25 PAGE 25 INALTO.HOUSE WARNING! Do not over tighten the filters. Put the filters back in the correct sequence and securely lock in place, otherwise coarse debris could get into the system and cause a blockage or damage internally. WARNING! Never use the dishwasher without the filters in place. Improper replacement of the filter will reduced the performance level of the dishwasher and may damage your dishes and utensils.
- Page 26 PAGE 26 Maintenance and Cleaning (Continued) INTERNAL CARE CONTINUED Cleaning the interior cabinet Over time, grime can accumulate on the interior walls of the appliance. A quick wipe down will do wonders for removing any dishwasher odour which can develop over time. Step 1 Remove both the upper and lower basket racks and run them under hot water within the kitchen sink.
- Page 27 PAGE 27 INALTO.HOUSE GENERAL CARE ADVICE After every wash After every wash cycle, turn off the water supply to the dishwasher and leave the door slightly ajar to that moisture and odours are not trapped inside. Remove the plug Before undertaking any cleaning or maintenance steps, always remove the dishwasher’s plug from it’s power outlet (power socket).
-
Page 28: Troubleshooting
PAGE 28 Troubleshooting GENERAL TROUBLESHOOTING STEPS Having an issue with your dishwasher? Before contacting our service team, please refer to the troubleshooting table below. Most issues can easily be rectified with some basic troubleshooting. Problem Possible Causes Actions to try My dishwasher Fuse blown, or the circuit Replace fuse or reset circuit breaker. - Page 29 PAGE 29 INALTO.HOUSE Knocking noise in This may be caused by This has no influence on the dishwasher function. If in the water pipes on-site installation or the doubt, contact a qualified plumber. cross-section of the piping. The dishes are not The dishes were not loaded See notes in “Loading &...
-
Page 30: Error Codes
PAGE 30 Error Codes If there is a malfunction the dishwasher will display error codes to identify the fault. Code Indicator Meanings Possible Causes The Rapid program E1- Water entering the Ensure that the water supply hose is un-kinked and that LED indicator dishwasher has exceeded the water supply tap is fully open. -
Page 31: Purchase Details
PAGE 31 INALTO.HOUSE Purchase Details For your records, please record details of your purchase below and staple your receipt on this page so you don’t loose it. Your serial number can be found on the rear of your appliance. STORE DETAIL S... -
Page 32: Warranty
PAGE 32 Warranty AUSTRALIAN WARRANTY TERMS & CONDITIONS 1. IN THIS WARRANTY DISHWASHERS (a) ‘acceptable quality’ as referred to in clause 10 of this warranty has the same meaning referred to in the This document sets out the terms and conditions of the ACL;... - Page 33 PAGE 33 INALTO.HOUSE 6. Proof of purchase is required before you can make a 12. Missing parts are not covered by warranty. claim under this warranty. Residentia Group reserves the right to assess each 7. You may not make a claim under this warranty unless request for missing parts in a case by case basis.
- Page 34 PAGE 34 THIS PAGE IS INTENTIONALLY LEFT BL ANK...
- Page 35 Microwaves are to be delivered to the Simply visit the below website, or ask your retailer for nearest authorised service agent by the customer. help: www.inalto.co.nz/register Please refer to your user manual for any further WARRANTY: conditions that may apply to your specific model.
- Page 36 A N I N I T I AT I V E BY R E S I D E N T I A G R O U P T E L . 1 3 0 0 1 1 4 3 5 7 S U P P O RT @ R E S I D E N T I A G R O U P.
