PAGE 03 PAGE CONTENT Quick Operation Guide Safety Instructions Operation Instruction Prior to Using for the First Time Loading the Dishwasher Baskets Starting a Washing Program Maintenance & Cleaning Installation Instructions Troubleshooting Tips Technical Data Purchase Details Warranty...
USER MANUAL PAGE 04 Quick Operation Guide Quick Operation Guide For detailed operating method read the corresponding content on the instruction manual. Switch on the appliance Open the door, press the On/Off button to switch on the appliance. Compartment A: For each wash cycle.
PAGE 05 Safety Instructions 1.IMPORTANT SAFETY INFORMATION READ ALL OF THE INSTRUCTIONS BEFORE USING WARNING! When using your dishwasher, follow the precautions listed below: GROUNDING INSTRUCTIONS WARNING! This appliance must be grounded. In the event of a Improper connection of the equipment-grounding malfunction or breakdown, grounding will reduce conductor can result in the risk of an electric shock.
USER MANUAL PAGE 06 2.Operation Instruction IMPORTANT To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Control Panel 1. On/Off Button: to switch On/Off the appliance; 2.Half-load function Button: To select Half-load function. (With this Half-load function you can only use it when 10.ECO(program) indicators;...
PAGE 7 Prior using for the first time Before using your dishwasher for the first time: Fill the rinse aid dispenser Fill in detergent A. Rinse Aid Dispenser Rinse Aid Dispenser The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks.
Page 8
USER MANUAL PAGE 8 NOTE: Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming during the next wash. Don't forget to replace the cap before you close dishwasher door. Adjusting Rinse Aid Dispenser The rinse aid dispenser has six or four settings.
USER MANUAL PAGE 10 4.Loading the Dishwasher Baskets Recommendation Consider buying utensils which are identified as dishwasher-proof. Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further information from the detergent manufacturers. For particular items, select a program with as low temperature as possible. To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the program has ended.
Page 11
PAGE 1 1 The Method Loading Normal Dishware Loading the Lower Basket Loading the Upper Basket The upper basket is designed to hold more delicate We suggest that you place large items and the most and lighter dishware such as glasses, coffee and difficult to clean items are to be placed into the lower tea cups and saucers, as well as plates, small bowls basket: such as pots, pans, lids, serving dishes and...
Page 13
PAGE 13 NOTE: When you press the Start/Pause button to pause during washing, the LED display window will stop blinking and the dishwasher will mooing every minute unless you press the Start/Pause button to start. Change the Program Premise: A cycle that is underway can only be modified if it has only been running for a short time. Otherwise, the detergent may have already been released, and the appliance may have already drained the wash water.
USER MANUAL PAGE 14 6.Maintenance and Cleaning Filtering System The filter prevents larger remnants of food or other objects from getting inside the pum. The residues may block the filter, in this case they must be removed. The filter system consists of a coarse filter, a flat (Main filter) and a microfilter(Fine filter).
Page 15
PAGE 15 Notes: - Inspect the filters for blocking after every time the dishwasher has been used. - By unscrewing the coarse filter, you can remove the filter system. Remove any food remnants and clean the filters under running water. NOTE: The entire filter assembly should be cleaned once a week.
USER MANUAL PAGE 16 How to Keep Your Dishwasher in Shape After Every Wash When not in Use for a LongTime It is recommend that you run a wash cycle with the After every wash, turn off the water supply to the dishwasher empty and then remove the plug from the appliance and leave the door slightly open so that socket, turn off the water supply and leave the door of...
Page 17
PAGE 17 Improper connection of the equipment earthing conductor can result in the risk of an WARNING! for personal safety: electric shock. DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG WITH THIS APPLIANCE. Check with a qualified electrician or service representative if you are in doubt whether the DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE EARTHING appliance is properly earthed.
Page 18
USER MANUAL PAGE 18 How to Drain Excess Water From Hoses If the sink is more than 1000mm higher than the floor, the excess water in hoses cannot be drained directly into the sink. It will be necessary to drain excess water from hoses into a bowl or suitable container that is held outside and lower than the sink.
PAGE 19 8.Troubleshooting Tips Before Calling for Service Review the charts on the following pages may save you from calling for service. Problem Possible Causes What To Do Dishwasher doesn't Fuse blown, or the Replace fuse or reset circuit breaker. Remove any other start circuit breaker acted appliances sharing the same circuit with the dishwasher...
Page 20
USER MANUAL PAGE 20 Problem Possible Causes What To Do Problem Problem Possible Causes Possible Causes What To Do What To Do The dishes The dishes were not See notes in " Loading the Dishwasher Baskets ". The dishes The dishes The dishes were not The dishes were not See notes in "...
Page 21
PAGE 21 If overflow occurs, turn off the main water supply before calling a service. If there is water in the base pan because of an overfill or small leaks, WARNING! the water should be removed before restarting the dishwasher. If overflow occurs, turn off the main water supply before calling a service.
PAGE 25 Receipt Purchase Details For your records, please record details of your purchase below and staple your receipt to this page. STORE DETAILS STORE NAME ADDRESS TELEPHONE PURCHASE DATE PRODUCT DETAILS MODEL NO. SERIAL NO.* * Note. Your serial number can be found on the inside panel of the dishwasher.
Page 26
USER MANUAL PAGE 26 Warranty Information WARRANTY TERMS & CONDITIONS In this warranty DISHWASHERS (FREESTANDING, INTEGRATED) ‘acceptable quality’ as referred to in clause 10 of this warranty has the same meaning referred to This document sets out the terms and conditions of the in the ACL;...
Page 27
PAGE 27 You will bear the cost of transportation, travel and To the extent permitted by law, Residentia Group delivery of the Appliance to and from Residentia excludes all warranties and liabilities (other than as Group or its ASR. If you reside outside of the service contained in this document) including liability for any area, you will bear the cost of: loss or damage whether direct or indirect arising from...
