- Page 1 U S E R M A N U A L I N A L T O . C O M . A U 60cm Integrated Dishwasher — M O D E L C O D E / S D W I 6 2 C S A H I G H E R L E V E L O F C O O K I N G...
- Page 2 Quick Operation Guide Quick Operation Guide For detailed operating method read the corresponding content on the instruction manual. Switch on the appliance Open the door, press the On/Off button to switch on the appliance. Compartment A: Compartment A: For each wash cycle. Compartment B: Fill the detergent dispenser For programs with pre-wash only.
-
Page 4: Grounding Instructions
1.IMPORTANT SAFETY INFORMATION 1.IMPORTANT SAFETY INFORMATION READ ALL OF THE INSTRUCTIONS BEFORE USING READ ALL OF THE INSTRUCTIONS BEFORE USING WARNING! WARNING! When using your dishwasher, follow the precautions listed below: GROUNDING INSTRUCTIONS WARNING! This appliance must be grounded. In the event of a Improper connection of the equipment-grounding malfunction or breakdown, grounding will reduce conductor can result in the risk of an electric shock. - Page 5 2.Operation Instruction 2.Operation Instruction IMPORTANT IMPORTANT To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Control Panel Control Panel 6.Program icons. 1.On/off Button: 7.Program Button :To press the button to select a To turn on/off the power supply.
-
Page 6: Rinse Aid Dispenser
Prior Prior using for the first time using for the first time Before using your dishwasher for the first time: Fill the rinse aid dispenser Fill in detergent A. Rinse Aid Dispenser A. Rinse Aid Dispenser Rinse Aid Dispenser The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. -
Page 7: Adjusting Rinse Aid Dispenser
NOTE: NOTE: Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming during the next wash. Don't forget to replace the cap before you close dishwasher door. Adjusting Rinse Aid Dispenser The rinse aid dispenser has six or four settings. Always start with the dispenser Adjust lever Adjust lever set on "4". -
Page 8: Amount Of Detergent To Use
Amount of Detergent to Use Detergent powder Detergent tablet NOTE: NOTE: If the lid is closed: press release button. The lid will spring open. Always add the detergent just before starting each wash cycle. Only use branded detergent aid for dishwasher. Dishwasher detergent is corrosive! WARNING! WARNING! - Page 9 4.Loading the Dishwasher Baskets 4.Loading the Dishwasher Baskets Recommendation Recommendation Consider buying utensils which are identified as dishwasher-proof. Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further information from the detergent manufacturers. For particular items, select a program with as low temperature as possible. To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the program has ended.
-
Page 10: Folding Back The Cup Shelves
The Method Loading Normal Dishware The Method Loading Normal Dishware Loading the Lower Basket Loading the Lower Basket Loading the Upper Basket Loading the Upper Basket The upper basket is designed to hold more delicate We suggest that you place large items and the most and lighter dishware such as glasses, coffee and difficult to clean items are to be placed into the lower tea cups and saucers, as well as plates, small bowls... - Page 11 5.Starting a washing program 5.Starting a washing program Wash Cycle Table Wash Cycle Table Means: need to fill rinse aid into the Rinse-Aid Dispenser. NOTE: NOTE: Detergent Detergent Description Description Cycle Selection Cycle Selection Running Running Energy Energy Rinse Rinse Water Water Program...
-
Page 12: Unloading The Dishwasher
Change the Program Change the Program Premise: A cycle that is underway can only be modified if it has only been running for a short time. Otherwise, the detergent may have already been released, and the appliance may have already drained the wash water. If this is the case, the detergent dispenser must be refilled (see the section entitled "... -
Page 13: Filter Assembly
6.Maintenance and Cleaning 6.Maintenance and Cleaning Filtering System Filtering System The filter prevents larger remnants of food or other objects from getting inside the pum. The residues may block the filter, in this case they must be removed. The filter system consists of a coarse filter, a flat (Main filter) and a microfilter(Fine filter). -
Page 14: Cleaning The Filter
Notes: - Inspect the filters for blocking after every time the dishwasher has been used. - By unscrewing the coarse filter, you can remove the filter system. Remove any food remnants and clean the filters under running water. NOTE: NOTE: The entire filter assembly should be cleaned once a week. -
Page 15: How To Keep Your Dishwasher In Shape
How to Keep Your Dishwasher in Shape When not in Use for a LongTime After Every Wash It is recommend that you run a wash cycle with the After every wash, turn off the water supply to the dishwasher empty and then remove the plug from the appliance and leave the door slightly open so that socket, turn off the water supply and leave the door of moisture and odours are not trapped inside. -
Page 16: Please Carefully Read The Installation Instruction
Please carefully read the installation instruction. Illustrations of cabinet dimensions and installation position of the dishwasher Preparations should be made before moving the dishwasher to the installation place. Choose a place near the sink to facilitate the installation of inlet and drain hoses (see figure 1). - Page 17 2 Install the hook on the aesthetic wooden panel and put the hook into the slot of the outer door of dishwasher(see figure 4a). After positioning of the panel , fix the panel onto the outer door by screws and bolts(See figure 4b) . Figure4a Installation of aesthetic panel Figure4b...
-
Page 18: Tension Adjustment Of The Door Spring
Tension adjustment of the door spring The door springs are set at the factory to the proper tension for the outer door. If aesthetic wooden panel are installed, you will have to adjust the door spring tension. Rotate the adjusting screw to drive the adjustor to strain or relax the steel cable (see figure 5). -
Page 19: Dishwasher Installation Steps
Dishwasher installation steps 1 Install the furniture door to the outer door of the dishwasher using the brackets provided. Refer to the template for positioning of the brackets. 2 Adjust the tension of the door springs by using an Allen key turning in a clockwise motion to tighten the left and right door springs. -
Page 20: Electrical Requirements
Dishwasher must be level for proper dish rack operation and wash performance. Place a spirit level on door and rack track inside the tub as shown to check that the dishwasher is level. level the dishwasher by adjusting the three levelling legs individually. When level the dishwasher, please pay attention not to let the dishwasher tip over. -
Page 21: Cold Water Connection
How to Connect the safety supply hose The appliance must be connected to the water mains using new hose-sets. The old hose-sets should not be reused. Water pressure must be between 0,04 MPa and 1 MPa. If the pressure is below the minimum consult our Service Department for advice. - Page 22 8.Troubleshooting Tips 8.Troubleshooting Tips Before Calling for Service Before Calling for Service Review the charts on the following pages may save you from calling for service. Problem Possible CausesWhat To Do Dishwasher doesn't Fuse blown, or the Replace fuse or reset circuit breaker. Remove any other circuit breaker acted appliances sharing the same circuit with the dishwasher start...
- Page 23 Problem Possible Causes What To Do The dishes The dishes were not See notes in " Loading the Dishwasher Baskets ". loaded correctly. are not clean The program was Select a more intensive programme. not powerful enough. See" Wash Cycle Table ". Not enough detergent Use more detergent, or change your detergent.
- Page 24 Technical Information Technical Information Height : 815mm Width : 598m m Depth : 550mm (with the door closed) Water pressure: 0.04-1.0MPa Power supply: see rating label Capacity: 14 place settings...
-
Page 26: Warranty Information
WARR ANT Y Warranty Information WARRANTY TERMS & CONDITIONS IN THIS WARRANTY DISHWASHERS (INTEGRATED, BUILT-IN) ‘acceptable quality’ as referred to in clause 10 of this warranty has the same meaning referred to in the This document sets out the terms and conditions of ACL;... - Page 27 WARR ANT Y INALTO.COM.AU You will bear the cost of transportation, travel and 10. For Appliances and services provided by Residentia delivery of the Appliance to and from Residentia Group in Australia, the Appliances come with a Group or its ASR. If you reside outside of the service...
- Page 28 A H I G H E R L E V E L O F C O O K I N G — W W W . R E S I D E N T I A . G R O U P...
