Install Your Product
Pairing of TX and RX
Before delivery, each ASK nano set has been paired , but when extra TX are required, following steps are the
method for users to finish TX/RX pairing.
(1) If you want to determine whether TX and RX have been paired:
① Powered on RX and TX(power RX up firstly),connect RX to HDMI port of the display;
② TX and RX will be pairing automatically and the indicator will turn into purple after 5 seconds.
(2) If you want to re-pair the paired ones:
① Powered on RX and TX(power RX up firstly),connect RX to HDMI port of the display;
② Press the TX button for 5 seconds to clear the previous pairing information;
③ Re-plug TX and wait for 2 seconds,the indicator of TX will turn from red to blue,and the corresponding screen
on the RX will display "TX paired OK";
④ After successful pairing, the indicator light on the TX will turn into static purple.
Note:TX will auto pair to the closest RX,so once you will do the pairs,please make sure the dedicated RX to be
closed to be paired TX.
Receiver Installation（RX）
1.Power on the RX via microUSB to USB cable and power
adapter
2.Connect HDMI port of RX to display, TV or projector.
Note: RX must be Powered on.Power adapter should be
supported by users.
Transmitter Installation（TX）
1. Connect the TX's HDMI to the PC's HDMI
2. The red light is on, and then the blue light turns flashing when
TX is ready to stream.
3. Touch the projection key to start projecting and the LED
indicator become static blue, meaning the casting is successful.
Note:If projection is unsuccessful,unplug the TX, and supply power to TX's HDMI port via microUSB-USB cable
and power adapter,then connect TX's HDMI port to the PC's HDMI port again,touch the projection key to project.
