Interface
TX Illumination
1
3
RX Illumination
1
3
Indicator light
TX
Light Red
Flash Blue
Static Blue
RX
Flash Blue
HDMI interface, connect
computer or other
devices with HDMI
Indicator light
HDMI interface,connect
display or projector
Indicator light
2
Projection key
4
Micro USB Power interface
2
4
Illumination
TX is on open
Waiting for the connection
Successful connection and projection
Illumination
RX is power on and ready for projection
2
Mode switch key，switch
TX/DLNA/AirPlay Mode and
Miracast Mode
Micro USB power interface
