  • Page 1 USER MANUAL Article No: RGB-RD-UM-D6 E001 Revision No: V1.0...

  • Page 2: Table Of Contents

    1.2.3 Dimension.......................... 12 Chapter 2 Installing Your Product......................13 2.1 Plugging in Signals........................13 2.2 Plugging in Main Power......................13 2.3 Turning on Your D6........................13 Chapter 3 Using Your Product........................14 3.1 XPOSE Operation........................14 3.1.1 XPOSE Installation......................14 3.2 XPOSE Controls D6........................18 3.2.1 Login in XPOSE........................

  • Page 3: Declarations

    30 days after the transfer of risks. In the event of justified notice of compliant, RGBlink can repair the fault or provide a replacement at its own discretion within an appropriate period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a reduction in the purchase price or cancellation of the contract.

  • Page 4: Operators Safety Summary

    Installation Safety Summary Safety Precautions For all D6 processor installation procedures, please observe the following important safety and handling rules to avoid damage to yourself and the equipment. To protect users from electric shock, ensure that the chassis connects to earth via the ground wire provided in the AC power Cord.
  • Page 5 If there is damage, notify the shipping carrier immediately for all claims adjustments. Site Preparation The environment in which you install your D6 should be clean, properly lit, free from static, and have adequate power, ventilation, and space for all components.

  • Page 6: In The Box

    Chapter 1 Your Product 1.1 In the Box AC Power HDMI to DVI HDMI Cable SDI Cable Cord Cable DB9 to RJ11 USB Cable DVI Cable Screw Cable Driver Antistatic Certification Note: AC Power Cable supplied as standard according to destination market. USB is contained on the Warranty/Registration Card.

  • Page 7: Product Overview

    D6 is based on fully optional input/output modules structure, with different optional modules to build the different range application. D6 can be set up with the local front panel or by remote controller with its remote control interfaces, including Ethernet, USB and RS 232.

  • Page 8: Front Panel

    1.2.1 Front Panel Button Instruction 1~16 Input signal source button and Number button use for Test pattern button scale, crop, zoom and custom setting OUT1~OUT4 Main Output button SCALE Scale button Multiview presets area Adjust Layer Mask L1~L4 Layer Area Background button DIMME Dimmer button...
  • Page 9 Menu Instruction Input menu Background Output Menu Blending PVW Menu Test Pattern Language Program Menu PST Menu View, including Save & Load Menu Layer Mask System DSK Menu Tech Support Factory Reset LOGO User Manual...
  • Page 10 User Manual...
  • Page 11 User Manual...

  • Page 12: Back Panel

    1.2.2 Back Panel Chassis Module Structure 4 input module slots, support SDI & 4K Input module 4 output module slots, support HDMI and SDI optional module Communication Board 1 preview output card slot, including 2 HDMI output Power module User Manual...

  • Page 13: Dimension

    1.2.3 Dimension Following is the dimension of D6 for your reference: User Manual...

  • Page 14: Chapter 2 Installing Your Product

    Connect signals to the product (ensure all devices are powered off first). Tighten connector screws/locks where provided.Connect to XPOSE software by RS 232. RGBlink provides a USB to RS 232 converter and the RS 232 to RJ11 cable for this connection, as a standard accessories.

  • Page 15: Chapter 3 Using Your Product

    Chapter 3 Using Your Product 3.1 XPOSE Operation 3.1.1 XPOSE Installation Environment Requirements: Processor: 1 GHz or above 32 bit or 64 bit processor Memory: 2 GB or more Graphics: Support DirectX 9 128M or above (open AERO effect) Hard disk space: Above 16G (primary partitions, NTFS format) Monitor: Resolution must be 1280 x720 pixel or above (it can not display normally if the resolution is lower than 1280 x720) Operating system: Windows 7 or above (full version, not Ghost version or compact version)
  • Page 16 Select “Browse...” to select the XPOSE software install location: Note: User should rights “Roles Management” when install the software to disk C if the system is Windows 7 or above. Click “Install”: User Manual...
  • Page 17 During installation, it will pop up the window of Install Shield Wizard for Virtual Com port: If user install the XPOSE software for the first time, click “Next” User Manual...
  • Page 18 Then click “Install", as shown in the figure below: Click “Finish” and complete the installation, as shown in the figure below: Select”Finish”and the device driver is completed installed，： User Manual...

  • Page 19: Xpose Controls D6

    3.2 XPOSE Controls D6 3.2.1 Login in XPOSE Double click the icon on the desktop. Login interface will pop up, the user name is Admin, and there is no password, select “D6”, and enter the XPOSE by clicking “Login”. User Manual...
  • Page 20 If user want to change the language to Chinese, click the drop down arrow after “Language” and select “Chinese”, as shown in the figure below, then click “Login” to enter into the XPOSE. XPOSE management software interface is shown as follows: User Manual...

  • Page 21: Web Links

    3.2.3 Connect with the D6 Firstly, set up the D6 IP, and make sure the IP of the computer and the D6 are on the same network range. Connect the PC which XPOSE software runs on the PC with the CAT5 cable or above to the D6.
  • Page 22 Then, click the shortcut “Search” on the operation interface. Then it will search the device, and show the device name, device number and IP after search, as shown in the figure below: Finally, click the device to connect, as shown in the figure below: Note: Right click the device, user can set tag name, it will display the device name when connect one more devices.

  • Page 23: Output Settings

    The XPOSE will automatically synchronize after connection, as shown in the figure below: 3.2.4 Output Settings Click the “Output Settings”, and enter the interface as follows: User Manual...
  • Page 24 Output Setting, DE Setting, Test Pattern are included in output settings, specific as follows: Output Setting Click the “Output Setting”, and pop-up window as follows: Output: Click the drop down arrows after the formats, and select the output resolution in the pull-down menus according to actual needs.
  • Page 25 horizontal with 2 AUX outputs, and show PIP. Note Content on AUX is set only need once,all operation modes are the same AUX setting. DE Setting Click the “DE Setting”, and pop-up window as follows: (1) Output Port: Select the out put port as requirement. (2) Output Type: Select HDMI or DVI as needed.

  • Page 26: Operation Mode

    Output: User can select any board among the four boards. Color Choose: Signal Source, Colour Bar and Pure Colour can be selected. Color: If select “Pure Colour”, red, green and blue can be adjusted, the adjustment range is between 0~255. 3.2.5 Operation Mode Click the “Operation Mode”, and enter the interface as follows: Preview Mode (4K2K), Split Mode, Presentation Mode(4K2K), Presentation Mode(4K1K) and...
  • Page 27 Click “OK”, and enter the interface as follows: Switch on Backups In the Output Setting: sliding the switch to the left is Backups , and pop-up window as follows: Click the “Operation Mode”, and enter to the interface as follows: User Manual...
  • Page 28 Switch on Aux In the Output Setting: sliding the switch to the right is Aux, and pop-up window as follows: Click the “Operation Mode”, and enter to the interface as follows: User Manual...
  • Page 29 Note Content on AUX is set only need once,all operation modes are the same AUX setting. Signal List The signal list is shown as follows: User Manual...
  • Page 30 It displays the input module type, the quantity of inputs and input format. Right click the input for the following settings: Change Name: Select “New Name”, input the new name, and click “OK” after setting. User Manual...
  • Page 31 Set Input Property: Right click the input and select “Input Property”, and it will enter the interface as follows: Scale: Including X, Y, Width and Height. X means horizontal position ， Y means vertical position.Users can select the corresponding parameter as requirement. Crop: Crop the left, top, width and height.
  • Page 32 Click the “OK”, and pop-up window as follows: Choose “Input Module” and “Work Mode” and Input 1 Type, then click “Set” Layer Split：Click”Layer Split”，choose Layer Split or Layer Merge。 Layer Merge: Select the signal to the PST, Layer Merge as follows： User Manual...
  • Page 33 Layer Split: Select the signal to the PST, Layer Split as follows： Layer Setting New Layer: In output screen zone of controlling software, press the left mouse key and drag on the intended output screen to cover the whole current screen. And the below interface will be displayed.
  • Page 34 Adjust Layer: Two ways can change the size and location of the opened layer: a. Drag the opened layer by mouse. The details are: move the mouse to the brink of the opened layer, when the mouse shows”<—>”, press the left key of the mouse and drag the window to a suitable size and then release the mouse.
  • Page 35 G, and click the layers that to operate, then release the button G, the selected layers will be grouped, which can be moved or scaled easily. Full the layer: Click the icon on the top right corner of the layer to full cell, and click the icon to full screen.
  • Page 36 3D-Mode, it will pop up the preview window for the layer layout, as shown in the figure below: User can preview the layer layout more directly, and switch it to the program output. EDID Click the EDID shortcut “ ”, and pop-up window as follows: The special display project or LED display application would like to require special resolution settings to meet the requirement.
  • Page 37 If select the 4K input card, as shown in the figure below: Click the input port, and set the width, height and frequency. Click “Set” after setting. Select “Reset”, all the setting will be recover to factory setting. Loop Click the loop shortcut “ ”, and pop-up window as follows: Slide the loop switch to enable or disable the loop function for the bank.
  • Page 38 Load Script Click the load script shortcut “ ”, user can load the data from the computer. Save Script Click the save script shortcut “ ”, user can save the data to the computer. Factory Reset Click the factory reset shortcut “ ”...
  • Page 39 If user need to connect to the LED display, or there is deviation in splitting, enter to the advanced setting, and scale or crop the image. Page Set Click the shortcut “ ”, and pop-up window as follows: Save Page: Click any one of page 1~page 16. The button light will be on and then turn to gray if save the scene successfully.
  • Page 40 Click the shortcut “ ”, and pop-up window as follows: Use shortcut key to operate fast and easily. 3.5.2.2 Split Mode Click “Operation Mode” and Choose “Split Mode”, system will pop up a window ” Whether switch working mode, it will clean the data?”as follows: Click “OK”, and enter the interface as follows: Under split mode, all output with the mouse to move the location of each outlet in output operations area, which adjust the output of the signal source location.
  • Page 41 The input signal respectively to output the output of operating area, also can be tensile is full of need to display the output signal source, the main screen will display the output effect. Click “Monitor” shortcut , it will enter the interface as follows: Quick split: Enable or disable the quick split mode by sliding the quick split switch and set H total, V total, Top Border, Bottom Border, Left Border, Righ Border, Row and Column.
  • Page 42 3.5.2.3 Presentation Mode (4K2K) Click “Operation Mode” and Choose “Presentation Mode (4K2K)”, system will pop up a window ” Whether switch working mode, it will clean the data?” and follows: Click “OK”, and enter the interface as follows: The input signal respectively to output the output of operating area, also can be tensile is full of need to display the output signal source, click on "TAKE"...
  • Page 43 3.5.2.4 Presentation Mode(4K1K) Click “Operation Mode” and Choose “Presentation Mode (4K1K)” system will pop up a window ” Whether switch working mode, it will clean the data?” as follows: Click “OK”, and enter the interface as follows: User Manual...
  • Page 44 The input signal respectively to output the output of operating area, also can be tensile is full of need to display the output signal source, click on "TAKE" button at top right corner, and the main screen will display the output result. 3.2.5.5 Presentation Mode (8K1K) Click “Operation Mode”...

  • Page 45: Admin

    The input signal respectively to output the output of operating area, also can be tensile is full of need to display the output signal source, click on "TAKE" button at top right corner, and the main screen will display the output result. 3.2.6 Admin Click the “Admin”, and enter the interface as follows: User Manual...
  • Page 46 Role management and rights management are included in access control, specific as follows: Role Management Click the “Role Management”, and pop-up window as follows: Add: Input the user name and password, and select the user type as “Admin’ or “Users”, click “Add”...

  • Page 47: System Settings

    Select the admin or users in user’s list, then click the rights in “Managements Detail”. Click “OK” after setting. User can operate the rights that selected. User Info: Display all the Admin or Users list, double click it will unfold or fold the list. Management Details: The administrator account can edit management details for all Admin Users and Users .
  • Page 48 Connect Setting, IP Settings, System information, Power On Setting/ Fan control, Factory Reset, and help are included in System Settings, specific as follows: Connect Settings Click the “Connect Setting”, and pop-up window as follows: Setting the Device with XPOSE connecting ways: Serial Connect, Net Connect and Search by this configuration.
  • Page 49 System Information Click the “System Information”, and pop-up window as follows: Display the device version information. Including Model Number, Serial Number, IP Address, firmware version, etc. Power on setting Fan Control Click the “Power On Setting Fan Control”, and pop-up window as follows: Set the time-lapse recall time, Enable or disable the Auto Fan Control, set Fan Speed and click ”Set”, that will load.

  • Page 50: Slave Unit

    Click “OK”, return to factory resetting. Click “OK”, and Restart. 3.2.8 Slave Unit It can control multiple devices of the same type at the same time, and the operation of each device is the same. It can realize a XPOSE to control multiple devices of the same type and operate at the same time.

  • Page 51: Log Out

    Click “Device Nmubers”, the windows can open two index. 3.2.9 Log Out Click the “Log Out”, and pop-up window as follows: Click “OK”, and the software would be enable to log out. User Manual...

  • Page 52: Chapter 4 Ordering Codes

    Chapter 4 Ordering Codes Product 110-0628-01-0 4.2 Options 4.2.1 Input Options 190-1628-06-0 SDI Input Module(Configurable 3G/6G/12G) 190-1628-07-0 4k Input Module（DVI/HDMI/DP） 4.2.2 Output Options 190-1628-21-0 HDMI 2.0 4K Output Module 190-1628-23-0 SDI 12G Output Module 190-1628-30-0 Four Layer Output Module 190-1628-31-0 HDMI 2K Output Module（4 HDMI 1.3）...

  • Page 53: Chapter 5 Support

    Chapter 5 Support 5.1 Contact Us User Manual...

  • Page 54: Chapter 6 Appendix

    Chapter 6 Appendix 6.1 Specification SDI Input Module Interface Appearance Number of Inputs 1 × 12G/6G SDI or 4 × 3G/HD/SD SDI Connector Standard SDI Socket Supported 12G SDI | 6G SDI | 3G SDI | HD SDI | SD SDI Standards 480i | 576i | 720p@25/30/50/60Hz | 1080i@50/59.94/60Hz Input Resolutions...
  • Page 55 Input Resolutions SEPTE : 480i | 576i | 720p@50/60Hz | 1080i@50/60Hz | 1080p@50/60Hz | 2160p@30Hz VESA: 800x600@50/60Hz | 1024x768@50/60Hz |1280x720@50/60Hz | 1280x800@50/60Hz | 1280x960@50/60Hz | 1280x1024@50/60Hz | 1400x1050@50/60Hz | 1600x1200@50/60Hz | 1920x1080@50/60Hz | 2048x1152@50/60Hz | 2560x1600@50/60Hz | 3840x1080@50/60Hz | 3840x2160@24/25/30Hz | HDMI 2.0 Input Module Interface Appearance...
  • Page 56 1920x1080@50/60Hz | 2048x1152@50/60Hz | 2560x1600@50/60Hz | 3840x1080@50/60Hz | 3840x2160@24/25/30/50/60Hz | 4096x2160@50/60Hz SDI Output Module Interface Appearance Number Outputs Connector 1 × 12G/6G SDI or 4 × 3G/HD/SD SDI 480i | 576i | 720p@25/30/50/60Hz | 1080i@50/59.94/60Hz Output 1080p@23.98/24/25/29.97/30/50/59.94/60Hz Resolutions 1080psf@23.98/24/25/29.97/30Hz | 2160p@30/50/60Hz HDMI 1.3 Output Module Interface Appearance...
  • Page 57 1280x800@50/60Hz | 1280x960@50/60Hz | 1280x1024@50/60Hz | 1400x1050@50/60Hz | 1600x1200@50/60Hz | 1920x1080@50/60Hz | 2048x1152@50/60Hz | 2560x1600@50/60Hz | 3840x1080@50/60Hz | 3840x2160@24/25/30/50/60Hz | 4096x2160@50/60Hz PVW Output Module Interface Appearance Number Outputs Connector Standard HDMI -A Socket Supported HDMI 1.3 Standards Output 1080p@60 Resolutions Extras Communication 1 ×...

  • Page 58: D6 Upgrade

    6.2 D6 Upgrade 1. Open XTOOL , If the language of the interface is not English, click the “ ” button to switch language. 2. Click “Connection”button to open the connection setting box. Select the “Serial Comm”, choose the corresponding port, and then click “OK”.If there is no port in the list, or it say “Failed to set serial port!”.
  • Page 59 5. After file loading, it will list the firmware contents. Click “all”, it will select the items that has a different version. 6. Click “Upgrade”. Pop up a confirm box. Click “confirm” to start upgrading. Notice: Don’t turn off the device and keep the wires connecting. 7.

  • Page 60: Installing Options

    6.3 Installing Options D6 supports multiple input or output modules, the user can install according to the specific requirements or replace the optional module. Specific steps are as follows: Installing optional modules: 1. Unscrew the 2 captive screws in input modules block, as shown in figure: 2.

  • Page 61: Terms & Definitions

    6.4 Terms & Definitions The following terms and definitions are used throughout this guide.  “ASCII”: American Standard for Information Interchange. The standard code consisting of 7-bit coded characters (8 bits including parity check) used to exchange information between data processing systems, data communication systems, and associated equipment.
  • Page 62  “Color temperature”: The color quality, expressed in degrees Kelvin(K), of a light source. The higher the color temperature, the bluer the light. The lower the temperature, the redder the light. Benchmark color temperature for the A/V industry include 5000°K, 6500°K, and 9000°K. ...
  • Page 63 degree of compression can be adjusted, allowing a selectable tradeoff between storage size and image quality. JPEG typically achieves 10:1 compression with little perceptible loss in image quality. Produces blocking artifacts.  “MPEG”: Motion Picture Expect Group. A standard committee under the auspices of the International Standards Organization working on algorithm standards that allow digital compression, storage and transmission of moving image information such as motion video, CD-quality audio, and control data at CD-ROM bandwidth.
  • Page 64 a given color in any image is free from white. The less white in a color, the truer the color or the greater its saturation. On a display device, the color control adjusts the saturation. Not to be confused with the brightness, saturation is the amount of pigment in a color, and not the intensity.
  • Page 65  “VGA”: Video Graphics Array. Introduced by IBM in 1987, VGA is an analog signal with TTL level separate horizontal and vertical sync. The video outputs to a 15-pin HD connector and has a horizontal scan frequency of 31.5 kHz and vertical frequency of 70 Hz (Mode 1, 2) and 60 Hz (Mode 3).

  • Page 66: Revision History

    6.5 Revision History The table below lists the changes to the Video Processor User Manual. Format Time ECO# Description Principal V1.0 2018-11-13 0000# Release Sophie User Manual...
