- Page 1 Wireless Presentation and Collaboration System USER MANUAL Article No: RGB-RD-UM- E001 Revision No: V1.0...
-
Page 2: Table Of Contents
CONTENTS CONTENTS............................1 Declarations............................2 FCC/Warranty..........................2 Operators Safety Summary......................3 Installation Safety Summary......................3 Chapter 1 Your Product........................5 1.1 In the Box..........................5 1.2 Product Overview........................5 1.2.1 Interface........................7 Chapter 2 Install Your Product......................9 Chapter 3 Use Your Product.......................11 3.1 MENU...........................11 3.2 Streaming from Smart-phone to ASK RX................15 3.3 Screen Mode........................ -
Page 3: Declarations
30 days after the transfer of risks. In the event of justified notice of compliant, RGBlink can repair the fault or provide a replacement at its own discretion within an appropriate period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a reduction in the purchase price or cancellation of the contract. -
Page 4: Operators Safety Summary
Normal wear as well as normal maintenance are not subject to the guarantee provided by RGBlink either. The environmental conditions as well as the servicing and maintenance regulations specified in this manual must be complied with by the customer. - Page 5 listed components are present, visually inspect the system to ensure there was no damage during shipping. If there is damage, notify the shipping carrier immediately for all claims adjustments. Site Preparation The environment in which you install your ASK should be clean, properly lit, free from static, and have adequate power, ventilation, and space for all components.
-
Page 6: Chapter 1 Your Product
Chapter 1 Your Product 1.1 In the Box 1*USBCable 1*DC 5V 2A Power Adapter For PC without HDMI port but with Type C port, we suggest using Type C-HDMI convertor, but please noted that the Type C has to be USB 3.1 at least. Power adapter is subject to the destionation market. - Page 7 no need IT support, with our powerful and simplicity solution, everyone can immediately know how to use it for collaborative presentations. ASK System Connection Diagram Product features Features Description Simple connect the transmitter with your PC USB and HDMI ports, then Plug and play touch the finger print to start the streaming.
-
Page 8: Interface
with touch panel. Share the images and audio from smart-phone camera or to the large Wireless Camera display simultaneous. Up to 128 user’s presentation at one time Four Screen Split Support up to 4 users on-screen simultaneously Beside one to one streaming mode, ASK also support Multicast, which is Multicast/ group communication, where video transmission from one transmitter is Display Group... - Page 9 TX Illumination Fingerprint key Tourch and it HDMI cable connect computer or other vibrate press to devices with HDMI start presenting USB cable connect to a LED indicator to display different statue computer or other on present key devices for power RX Illumination reset the device if the Micro USB Power DC 5V...
-
Page 10: Chapter 2 Install Your Product
Chapter 2 Install Your Product Devices Requirement Please ensure the devices meets the following requirements: iOS 9.0 or above Android 5.0 or above LED indicators LED indicator on TX Description Static Green Transmitter is booting on Flashing Purple Waiting for connection Static Purple Connection successful, casting done... - Page 11 Transmitter Installation Connect the ASK TX’s HDMI and USB jacks to the laptop USB/HDMI inputs. The LED indicator of the ASK TX will light on in green when it’s booting up. The LED indicator become purple and flashing when ASK is ready to stream. Touch the finger print to start presenting and the LED indicator become stastic Purple, meaning the casting is successful.
-
Page 12: Chapter 3 Use Your Product
Chapter 3 Use Your Product 3.1 MENU After RX is connect to big screen, the screen enters homepage, click the triangle icon on the middle right boader,menu column will be open up. Homepage Menu column Here is a list of menu items. Close menu Homepage... - Page 13 Homepage When the RX is connected to the big screen it will enter homepage which is also the standby page. IP list of devices on screen Here showing the IP address of each device which is ready to cast on the screen.
- Page 14 File can be saved to Google drive or One drive, or if there are files saved in Google drive or One drive, users can recall the file. Save or recall screen shot picture here Save or recall EWB file here Setting-Common Setup User Manual...
- Page 15 Setting-Display Group Setup Setting-Whiteboard Setup Setting-Advanced Setup-Power off reset Setting-Advanced Setup-Reset Plan-Shedule daily User Manual...
-
Page 16: Streaming From Smart-Phone To Ask Rx
Setup-Reset Plan-After idle of 3.2 Streaming from Smart-phone to ASK RX Step 1: Search in WLAN setting the hotspot of ASK with name of RGBlink-XXXX and connect, Password: 12345678 Step 2: Stream the content from your iOS/Android devices via screen mirroring. - Page 17 2. Multiple Screen Split Mode: Please touch the ASK TX finger print above 2 seconds and there are interval vibrations on TX, then multiple screens can be cast and split to the large display automatically. If you use smartphone, please ensure that your smart-phone and receiver are connected in the same subnet, click the smart-phone, multiple screens can be cast and split to the large display automatically.
-
Page 18: Multicast Or Display Group Setup
3.4 Multicast or Display Group Setup Step 1: Make sure the different receivers in the same subnet. Step 2: open up the menu on the homepage and click Setting icon Display Group and open Setup Step 3: Turn the “Turn on/off Display Group” button on the display group, then other receiver which in the same subnet will be listed, please select the receiver which you want to join the display group, click confirm. -
Page 19: Chapter 4 Order Codes
Chapter 4 Order Codes Product Code Item 450-0001-01-0 ASK Mini (RX) 450-0101-01-0 ASK Me (TX) 450-1001-01-0 ASK Set (TX*2+ RX*1) User Manual... -
Page 20: Chapter 4 Support
Chapter 4 Support 4.1 Contact Us User Manual... -
Page 21: Chapter 5 Appendix
Chapter 5 Appendix 5.1 Specification Receiver Connectors Output HDMI 2.0 1×HDMI-A Communication 1×RJ45 2×USB-A Power 1×micro USB Subject to native resolution of display Performance Output Resolutions HDMI connected VESA 1280×720@60 | 1920×1080@60 | 3840×2160@60 Supported HDMI Standards Power Input Voltage DC 5V 2A Max Power RX ≤10W... - Page 22 Transmitter Connectors Input HDMI 1.3 (on cable) 1×HDMI-A Power USB (on cable) 1×USB-A Performance Output HDMI Resolutions VESA 800×600@60 |1024×768@60 |1280×720@60 |1280×800@60 |1280×960@60 | 1280×1024@60 | 1400×1050@60 |1600×1200@60 | 1920×1080@60 Supported HDMI Standards Power Input Voltage DC 5V 2A Max Power RX ≤2.5W Environment Temperature...
-
Page 23: Terms & Definitions
5.2Terms & Definitions ●RCA：Connector used primarily in consumer AV equipment for both audio and video. The RCA connector was developed by the Radio Corporation of America. ●BNC: Stands for Bayonet Neill-Concelman. A cable connector used extensively in television (named for its inventors). A cylindrical bayonet connector that operates with a twist-locking motion . ●CVBS：CVBS or Composite video, is an analog video signal without audio. - Page 24 ●HDMI ： High Definition Multimedia Interface: An interface used for the transmission of uncompressed high definition video, up to 8 channels of audio, and control signals, over a single cable. ●HDMI 1.3: released on June 22 2006, and increased the maximum TMDS clock to 340 MHz (10.2 Gbit/s).
- Page 25 ●SFP：small form-factor pluggable , is a compact, hot-pluggable network interface module used for both telecommunication and data communications applications. ●optical fiber connector: terminates the end of an optical fiber, and enables quicker connection and disconnection than splicing. The connectors mechanically couple and align the cores of fibers so light can pass.
- Page 26 USB 3.0 USB 3.1&3.2 ●NTSC : The colour video standard used in North America and some other parts of the world created by the National Television Standards Committee in the 1950s. NTSC utilizes an interlaced video signals. ●PAL: Phase Alternate Line. A television standard in which the phase of the colour carrier is alternated from line to line.
- Page 27 video-compatible products to communicate, deliver,and receive broadcast quality video in a high quality, low latency manner that is frame-accurate and suitable for switching in a live production environment over TCP (UDP) Ethernet based networks. NDI is commonly found in broadcast applications. ●RTMP: Real-Time Messaging Protocol (RTMP) was initially a proprietary protocol developed by Macromedia (now Adobe) for streaming audio, video and data over the Internet, between a Flash player and a server.
- Page 28 ●OSC: The principle of Open Sound Control (OSC) protocol is for networking sound synthesizers, computers, and multimedia devices for musical performance or show control. As with XML and JSON, the OSC protocol allows sharing data. OSC is transported via UDP packets between devices connected on an Ethernet.
- Page 29 ●Seamless Switching: A feature found on many video switchers. This feature causes the switcher to wait until the vertical interval to switch. This avoids a glitch (temporary scrambling) which often is seen when switching between sources. ●Scaling: A conversion of a video or computer graphic signal from a starting resolution to a new resolution.
-
Page 30: Revision History
Release Fanny All information herein is Xiamen RGBlink Science & Technology Co Ltd. excepting noted. RGBlink is a registered trademark of Xiamen RGBlink Science & Technology Co Ltd. While all efforts are made for accuracy at time of printing, we reserve the right to alter otherwise make change without notice.
